4_Period_MA_w_Regr_STD
Download script
This script is a multi-timeframe technical analysis tool designed to provide traders with a comprehensive visual overview of market trends, volatility, and potential support or resistance levels simultaneously. By aggregating data from four different time periods, it helps identify "confluence"—where multiple timeframes agree on a price movement.
Core Functionalities
1. Multi-Timeframe Moving Averages The script calculates seven different Moving Averages (MAs) across four distinct time periods (specifically 5, 15, 60, and 240 minutes). These averages act as the foundation for the tool, smoothing out price noise to reveal the underlying direction of the market.
2. Dynamic Support and Resistance Zones For each of the four timeframes, the script identifies the highest and lowest moving average values. It then uses these boundaries to plot a series of "Fibonacci-style" shadow levels. These represent potential price zones where the market might react, stall, or reverse. The logic ensures that:
- Levels are automatically calculated based on the spread of the averages.
- Visual lines only appear if there is sufficient space between them (to avoid cluttering the chart).
- Each level is assigned a unique color to differentiate between various support and resistance depths.
3. Real-Time Price Interaction The script provides immediate visual feedback on where the current price sits in relation to the moving averages:
- Green/Red Highlights: Changes the color of the text labels based on whether the price is currently above or below a specific average.
- Yellow Alerts: Specifically highlights when the current market price is "straddling" or touching an average, indicating a potential zone of high interest or transition.
4. Regression and Standard Deviation Channels The tool incorporates two advanced statistical overlays:
- Regression Channel: Provides a visual trend line that attempts to find the "line of best fit" for recent price action.
- Standard Deviation Channel: Creates an "envelope" around the price. This helps traders see how far the current price has deviated from the norm, which is useful for identifying overextended markets that may be due for a correction.
5. Adaptive Visual Layout To ensure the chart remains readable regardless of your screen size or zoom level, the script includes an "Adaptive Coordinate" system. It automatically adjusts the spacing and scale of all objects (lines, text, and rectangles) based on:
- The number of bars visible on your screen.
- The specific timeframe you are currently viewing.
6. Visual Summary Columns At the end of the calculation, the script generates distinct colored rectangles for each of the four timeframes. These serve as a quick-glance summary:
- Red Rectangles: Represent the "downward" price pressure or current bid level.
- Green Rectangles: Represent the "upward" price pressure or current ask level.
Summary for the User
Essentially, this script transforms a standard chart into a sophisticated dashboard. Instead of looking at one timeframe and guessing what is happening on others, it projects the trends, statistical boundaries, and support levels of four different timeframes onto your screen at once, highlighting exactly where the price is interacting with these key historical and mathematical data points.
Indicators Used
9
Views
0
Downloads
0
Favorites
4_Period_MA_w_Regr_STD
//+------------------------------------------------------------------+
//| 4 Period MA.mq4 |
//| Copyright © 2006, tageiger aka fxid10t@yahoo.com |
//| http://www.metatrader.org |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2006, tageiger aka fxid10t@yahoo.com"
#property link "mailto:fxid10t@yahoo.com"
#property indicator_chart_window
//----
extern int p1_ma=5;//Period() in minutes
extern int p2_ma=15;//Period() in minutes
extern int p3_ma=60;//Period() in minutes
extern int p4_ma=240;//Period() in minutes
extern int STD_Rgres_length=56;
extern double STD_width=0.809;
extern int ma_applied_price=1;
/*
Applied price constants. It can be any of the following values:
Constant Value Description
PRICE_CLOSE 0 Close price.
PRICE_OPEN 1 Open price.
PRICE_HIGH 2 High price.
PRICE_LOW 3 Low price.
PRICE_MEDIAN 4 Median price, (high+low)/2.
PRICE_TYPICAL 5 Typical price, (high+low+close)/3.
PRICE_WEIGHTED 6 Weighted close price, (high+low+close+close)/4.
*/
extern int ma_Method=0;
/*
Moving Average Method
Constant Value Description
MODE_SMA 0 Simple moving average,
MODE_EMA 1 Exponential moving average,
MODE_SMMA 2 Smoothed moving average,
MODE_LWMA 3 Linear weighted moving average.
*/
extern int ma1_Length=13;
extern int ma2_Length=21;
extern int ma3_Length=34;
extern int ma4_Length=55;
extern int ma5_Length=89;
extern int ma6_Length=144;
extern int ma7_Length=233;
//----
extern int fib_SR_shadow_1=13;
extern int fib_SR_shadow_2=21;
extern int fib_SR_shadow_3=34;
extern int fib_SR_shadow_4=55;
extern int fib_SR_shadow_5=89;
extern int fib_SR_shadow_6=144;
extern int fib_SR_shadow_7=233;
//----
extern color fib_SR_shadow_1_c=AliceBlue;
extern color fib_SR_shadow_2_c=LightBlue;
extern color fib_SR_shadow_3_c=DodgerBlue;
extern color fib_SR_shadow_4_c=RoyalBlue;
extern color fib_SR_shadow_5_c=Blue;
extern color fib_SR_shadow_6_c=MediumBlue;
extern color fib_SR_shadow_7_c=DarkBlue;
//----
double ma1_p1, ma2_p1, ma3_p1, ma4_p1, ma5_p1, ma6_p1, ma7_p1;
double ma1_p2, ma2_p2, ma3_p2, ma4_p2, ma5_p2, ma6_p2, ma7_p2;
double ma1_p3, ma2_p3, ma3_p3, ma4_p3, ma5_p3, ma6_p3, ma7_p3;
double ma1_p4, ma2_p4, ma3_p4, ma4_p4, ma5_p4, ma6_p4, ma7_p4;
//----
datetime t1_p1, t2_p1, t1_p2, t2_p2, t1_p3, t2_p3, t1_p4, t2_p4;
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
int init()
{ return(0);
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
int deinit()
{
ObjectsDeleteAll(0,OBJ_TEXT);ObjectsDeleteAll(0,OBJ_RECTANGLE);
ObjectsDeleteAll(0,OBJ_ARROW);ObjectsDeleteAll(0,OBJ_TREND);
return(0);
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
int start()
{
ObjectsDeleteAll();
ObjectCreate("regression channel",OBJ_REGRESSION,0,Time[STD_Rgres_length],Bid,Time[0],Ask);
ObjectSet("regression channel",OBJPROP_RAY,true);
ObjectCreate("std channel",OBJ_STDDEVCHANNEL,0,Time[STD_Rgres_length],Bid,Time[0],Ask);
ObjectSet("std channel",OBJPROP_DEVIATION,STD_width);
ObjectSet("std channel",OBJPROP_COLOR,Olive);
ObjectSet("std channel",OBJPROP_RAY,true);
//p1 ma settings
ma1_p1=iMA(Symbol(),p1_ma,ma1_Length,0,ma_Method,ma_applied_price,0);
ma2_p1=iMA(Symbol(),p1_ma,ma2_Length,0,ma_Method,ma_applied_price,0);
ma3_p1=iMA(Symbol(),p1_ma,ma3_Length,0,ma_Method,ma_applied_price,0);
ma4_p1=iMA(Symbol(),p1_ma,ma4_Length,0,ma_Method,ma_applied_price,0);
ma5_p1=iMA(Symbol(),p1_ma,ma5_Length,0,ma_Method,ma_applied_price,0);
ma6_p1=iMA(Symbol(),p1_ma,ma6_Length,0,ma_Method,ma_applied_price,0);
ma7_p1=iMA(Symbol(),p1_ma,ma7_Length,0,ma_Method,ma_applied_price,0);
//--------------
//p2 ma settings
ma1_p2=iMA(Symbol(),p2_ma,ma1_Length,0,ma_Method,ma_applied_price,0);
ma2_p2=iMA(Symbol(),p2_ma,ma2_Length,0,ma_Method,ma_applied_price,0);
ma3_p2=iMA(Symbol(),p2_ma,ma3_Length,0,ma_Method,ma_applied_price,0);
ma4_p2=iMA(Symbol(),p2_ma,ma4_Length,0,ma_Method,ma_applied_price,0);
ma5_p2=iMA(Symbol(),p2_ma,ma5_Length,0,ma_Method,ma_applied_price,0);
ma6_p2=iMA(Symbol(),p2_ma,ma6_Length,0,ma_Method,ma_applied_price,0);
ma7_p2=iMA(Symbol(),p2_ma,ma7_Length,0,ma_Method,ma_applied_price,0);
//--------------
//p3 ma settings
ma1_p3=iMA(Symbol(),p3_ma,ma1_Length,0,ma_Method,ma_applied_price,0);
ma2_p3=iMA(Symbol(),p3_ma,ma2_Length,0,ma_Method,ma_applied_price,0);
ma3_p3=iMA(Symbol(),p3_ma,ma3_Length,0,ma_Method,ma_applied_price,0);
ma4_p3=iMA(Symbol(),p3_ma,ma4_Length,0,ma_Method,ma_applied_price,0);
ma5_p3=iMA(Symbol(),p3_ma,ma5_Length,0,ma_Method,ma_applied_price,0);
ma6_p3=iMA(Symbol(),p3_ma,ma6_Length,0,ma_Method,ma_applied_price,0);
ma7_p3=iMA(Symbol(),p3_ma,ma7_Length,0,ma_Method,ma_applied_price,0);
//--------------
//p4 ma settings
ma1_p4=iMA(Symbol(),p4_ma,ma1_Length,0,ma_Method,ma_applied_price,0);
ma2_p4=iMA(Symbol(),p4_ma,ma2_Length,0,ma_Method,ma_applied_price,0);
ma3_p4=iMA(Symbol(),p4_ma,ma3_Length,0,ma_Method,ma_applied_price,0);
ma4_p4=iMA(Symbol(),p4_ma,ma4_Length,0,ma_Method,ma_applied_price,0);
ma5_p4=iMA(Symbol(),p4_ma,ma5_Length,0,ma_Method,ma_applied_price,0);
ma6_p4=iMA(Symbol(),p4_ma,ma6_Length,0,ma_Method,ma_applied_price,0);
ma7_p4=iMA(Symbol(),p4_ma,ma7_Length,0,ma_Method,ma_applied_price,0);
//--------------
Time_Coordinate_Set();
p1_Fib_Plot();
p2_Fib_Plot();
p3_Fib_Plot();
p4_Fib_Plot();
column();
//--------------
return(0);}
//+------------------------------------------------------------------+
void Time_Coordinate_Set()
{
//....Variable Settings for Object Spatial Placement.....
double zoom_multiplier;int bpw=BarsPerWindow();
if(bpw<25) {zoom_multiplier=0.05;}
if(bpw>25 && bpw<50) {zoom_multiplier=0.07;}
if(bpw>50 && bpw<175) {zoom_multiplier=0.12;}
if(bpw>175 && bpw<375) {zoom_multiplier=0.25;}
if(bpw>375 && bpw<750) {zoom_multiplier=0.5;}
if(bpw>750) {zoom_multiplier=1;}
double time_frame_multiplier;
if(Period()==1) {time_frame_multiplier=0.65;}
if(Period()==5) {time_frame_multiplier=3.25;}
if(Period()==15) {time_frame_multiplier=9.75;}
if(Period()==30) {time_frame_multiplier=19.5;}
if(Period()==60) {time_frame_multiplier=39;}
if(Period()==240) {time_frame_multiplier=156;}
if(Period()==1440) {time_frame_multiplier=936;}
if(Period()==10080) {time_frame_multiplier=6552;}
if(Period()==43200) {time_frame_multiplier=28043;}
//----
t1_p1=Time[0]+(1000*time_frame_multiplier*zoom_multiplier);
t2_p1=Time[0]+(3000*time_frame_multiplier*zoom_multiplier);
//----
t1_p2=Time[0]+(5000*time_frame_multiplier*zoom_multiplier);
t2_p2=Time[0]+(7000*time_frame_multiplier*zoom_multiplier);
//----
t1_p3=Time[0]+(9000*time_frame_multiplier*zoom_multiplier);
t2_p3=Time[0]+(11000*time_frame_multiplier*zoom_multiplier);
//----
t1_p4=Time[0]+(13000*time_frame_multiplier*zoom_multiplier);
t2_p4=Time[0]+(16000*time_frame_multiplier*zoom_multiplier);}//end Time_Coordinate_Set()
//----
void p1_Fib_Plot()
{
//p1 dynamic fibo levels
double lo_ma_p1,hi_ma_p1;
lo_ma_p1=ma1_p1;
if(ma2_p1<lo_ma_p1) {lo_ma_p1=ma2_p1;}
if(ma3_p1<lo_ma_p1) {lo_ma_p1=ma3_p1;}
if(ma4_p1<lo_ma_p1) {lo_ma_p1=ma4_p1;}
if(ma5_p1<lo_ma_p1) {lo_ma_p1=ma5_p1;}
if(ma6_p1<lo_ma_p1) {lo_ma_p1=ma6_p1;}
if(ma7_p1<lo_ma_p1) {lo_ma_p1=ma7_p1;}
lo_ma_p1=NormalizeDouble(lo_ma_p1+(fib_SR_shadow_1*Point),Digits);
//----
hi_ma_p1=ma7_p1;
if(ma6_p1>hi_ma_p1) {hi_ma_p1=ma6_p1;}
if(ma5_p1>hi_ma_p1) {hi_ma_p1=ma5_p1;}
if(ma4_p1>hi_ma_p1) {hi_ma_p1=ma4_p1;}
if(ma3_p1>hi_ma_p1) {hi_ma_p1=ma3_p1;}
if(ma2_p1>hi_ma_p1) {hi_ma_p1=ma2_p1;}
if(ma1_p1>hi_ma_p1) {hi_ma_p1=ma1_p1;}
hi_ma_p1=NormalizeDouble(hi_ma_p1-(fib_SR_shadow_1*Point),Digits);
//p1 center dynamic fib placement
if(lo_ma_p1-hi_ma_p1>Ask-Bid)
{
ObjectCreate("lcf_p1",OBJ_TREND,0,t1_p1, lo_ma_p1, t2_p1, lo_ma_p1);
ObjectSet("lcf_p1",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lcf_p1",OBJPROP_WIDTH,2);
ObjectSet("lcf_p1",OBJPROP_RAY,false);
ObjectSet("lcf_p1",OBJPROP_COLOR,fib_SR_shadow_1_c);
ObjectSetText("lcf_p1",DoubleToStr(lo_ma_p1,Digits),7,"Arial",fib_SR_shadow_1_c);
//----
ObjectCreate("hcf_p1",OBJ_TREND,0,t1_p1, hi_ma_p1, t2_p1, hi_ma_p1);
ObjectSet("hcf_p1",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hcf_p1",OBJPROP_WIDTH,2);
ObjectSet("hcf_p1",OBJPROP_RAY,false);
ObjectSet("hcf_p1",OBJPROP_COLOR,fib_SR_shadow_1_c);
ObjectSetText("hcf_p1",DoubleToStr(hi_ma_p1,Digits),7,"Arial",fib_SR_shadow_1_c);
}
//----
double lo_ma_p1_1, lo_ma_p1_2, lo_ma_p1_3, lo_ma_p1_4, lo_ma_p1_5, lo_ma_p1_6;
lo_ma_p1_1=lo_ma_p1+(fib_SR_shadow_2*Point);
lo_ma_p1_2=lo_ma_p1_1+(fib_SR_shadow_3*Point);
lo_ma_p1_3=lo_ma_p1_2+(fib_SR_shadow_4*Point);
lo_ma_p1_4=lo_ma_p1_3+(fib_SR_shadow_5*Point);
lo_ma_p1_5=lo_ma_p1_4+(fib_SR_shadow_6*Point);
lo_ma_p1_6=lo_ma_p1_5+(fib_SR_shadow_7*Point);
//----
double hi_ma_p1_1, hi_ma_p1_2, hi_ma_p1_3, hi_ma_p1_4, hi_ma_p1_5, hi_ma_p1_6;
hi_ma_p1_1=hi_ma_p1-(fib_SR_shadow_2*Point);
hi_ma_p1_2=hi_ma_p1_1-(fib_SR_shadow_3*Point);
hi_ma_p1_3=hi_ma_p1_2-(fib_SR_shadow_4*Point);
hi_ma_p1_4=hi_ma_p1_3-(fib_SR_shadow_5*Point);
hi_ma_p1_5=hi_ma_p1_4-(fib_SR_shadow_6*Point);
hi_ma_p1_6=hi_ma_p1_5-(fib_SR_shadow_7*Point);
//p1 1st level (hi_1_p1, lo_1_p1)
if(lo_ma_p1_1-hi_ma_p1_1>Ask-Bid)
{
ObjectCreate("lo_1_p1",OBJ_TREND,0,t1_p1, lo_ma_p1_1, t2_p1, lo_ma_p1_1);
ObjectSet("lo_1_p1",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lo_1_p1",OBJPROP_WIDTH,2);
ObjectSet("lo_1_p1",OBJPROP_RAY,false);
ObjectSet("lo_1_p1",OBJPROP_COLOR,fib_SR_shadow_2_c);
ObjectSetText("lo_1_p1",DoubleToStr(lo_ma_p1_1,Digits),7,"Arial",fib_SR_shadow_2_c);
//----
ObjectCreate("hi_1_p1",OBJ_TREND,0,t1_p1, hi_ma_p1_1, t2_p1, hi_ma_p1_1);
ObjectSet("hi_1_p1",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hi_1_p1",OBJPROP_WIDTH,2);
ObjectSet("hi_1_p1",OBJPROP_RAY,false);
ObjectSet("hi_1_p1",OBJPROP_COLOR,fib_SR_shadow_2_c);
ObjectSetText("hi_1_p1",DoubleToStr(hi_ma_p1_1,Digits),7,"Arial",fib_SR_shadow_2_c);
}
// 2st level (hi_2_p1, lo_2_p1)
if(lo_ma_p1_2-hi_ma_p1_2>Ask-Bid)
{
ObjectCreate("lo_2_p1",OBJ_TREND,0,t1_p1, lo_ma_p1_2, t2_p1, lo_ma_p1_2);
ObjectSet("lo_2_p1",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lo_2_p1",OBJPROP_WIDTH,2);
ObjectSet("lo_2_p1",OBJPROP_RAY,false);
ObjectSet("lo_2_p1",OBJPROP_COLOR,fib_SR_shadow_3_c);
ObjectSetText("lo_2_p1",DoubleToStr(lo_ma_p1_2,Digits),7,"Arial",fib_SR_shadow_3_c);
//----
ObjectCreate("hi_2_p1",OBJ_TREND,0,t1_p1, hi_ma_p1_2, t2_p1, hi_ma_p1_2);
ObjectSet("hi_2_p1",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hi_2_p1",OBJPROP_WIDTH,2);
ObjectSet("hi_2_p1",OBJPROP_RAY,false);
ObjectSet("hi_2_p1",OBJPROP_COLOR,fib_SR_shadow_3_c);
ObjectSetText("hi_2_p1",DoubleToStr(hi_ma_p1_2,Digits),7,"Arial",fib_SR_shadow_3_c);
}
// 3rd level (hi_3_p1, lo_3_p1)
if(lo_ma_p1_3-hi_ma_p1_3>Ask-Bid)
{
ObjectCreate("lo_3_p1",OBJ_TREND,0,t1_p1, lo_ma_p1_3, t2_p1, lo_ma_p1_3);
ObjectSet("lo_3_p1",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lo_3_p1",OBJPROP_WIDTH,2);
ObjectSet("lo_3_p1",OBJPROP_RAY,false);
ObjectSet("lo_3_p1",OBJPROP_COLOR,fib_SR_shadow_4_c);
ObjectSetText("lo_3_p1",DoubleToStr(lo_ma_p1_3,Digits),7,"Arial",fib_SR_shadow_4_c);
//----
ObjectCreate("hi_3_p1",OBJ_TREND,0,t1_p1, hi_ma_p1_3, t2_p1, hi_ma_p1_3);
ObjectSet("hi_3_p1",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hi_3_p1",OBJPROP_WIDTH,2);
ObjectSet("hi_3_p1",OBJPROP_RAY,false);
ObjectSet("hi_3_p1",OBJPROP_COLOR,fib_SR_shadow_4_c);
ObjectSetText("hi_3_p1",DoubleToStr(hi_ma_p1_3,Digits),7,"Arial",fib_SR_shadow_4_c);
}
// 4th level (hi_4_p1, lo_4_p1)
if(lo_ma_p1_4-hi_ma_p1_4>Ask-Bid)
{
ObjectCreate("lo_4_p1",OBJ_TREND,0,t1_p1, lo_ma_p1_4, t2_p1, lo_ma_p1_4);
ObjectSet("lo_4_p1",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lo_4_p1",OBJPROP_WIDTH,2);
ObjectSet("lo_4_p1",OBJPROP_RAY,false);
ObjectSet("lo_4_p1",OBJPROP_COLOR,fib_SR_shadow_5_c);
ObjectSetText("lo_4_p1",DoubleToStr(lo_ma_p1_4,Digits),7,"Arial",fib_SR_shadow_5_c);
//----
ObjectCreate("hi_4_p1",OBJ_TREND,0,t1_p1, hi_ma_p1_4, t2_p1, hi_ma_p1_4);
ObjectSet("hi_4_p1",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hi_4_p1",OBJPROP_WIDTH,2);
ObjectSet("hi_4_p1",OBJPROP_RAY,false);
ObjectSet("hi_4_p1",OBJPROP_COLOR,fib_SR_shadow_5_c);
ObjectSetText("hi_4_p1",DoubleToStr(hi_ma_p1_4,Digits),7,"Arial",fib_SR_shadow_5_c);
}
// 5th level (hi_5_p1, lo_5_p1)
if(lo_ma_p1_5-hi_ma_p1_5>Ask-Bid)
{
ObjectCreate("lo_5_p1",OBJ_TREND,0,t1_p1, lo_ma_p1_5, t2_p1, lo_ma_p1_5);
ObjectSet("lo_5_p1",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lo_5_p1",OBJPROP_WIDTH,2);
ObjectSet("lo_5_p1",OBJPROP_RAY,false);
ObjectSet("lo_5_p1",OBJPROP_COLOR,fib_SR_shadow_6_c);
ObjectSetText("lo_5_p1",DoubleToStr(lo_ma_p1_5,Digits),7,"Arial",fib_SR_shadow_6_c);
//----
ObjectCreate("hi_5_p1",OBJ_TREND,0,t1_p1, hi_ma_p1_5, t2_p1, hi_ma_p1_5);
ObjectSet("hi_5_p1",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hi_5_p1",OBJPROP_WIDTH,2);
ObjectSet("hi_5_p1",OBJPROP_RAY,false);
ObjectSet("hi_5_p1",OBJPROP_COLOR,fib_SR_shadow_6_c);
ObjectSetText("hi_5_p1",DoubleToStr(hi_ma_p1_5,Digits),7,"Arial",fib_SR_shadow_6_c);
}
// 6th level (hi_6_p1, lo_6_p1)
if(lo_ma_p1_6-hi_ma_p1_6>Ask-Bid)
{
ObjectCreate("lo_6_p1",OBJ_TREND,0,t1_p1, lo_ma_p1_6, t2_p1, lo_ma_p1_6);
ObjectSet("lo_6_p1",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lo_6_p1",OBJPROP_WIDTH,2);
ObjectSet("lo_6_p1",OBJPROP_RAY,false);
ObjectSet("lo_6_p1",OBJPROP_COLOR,fib_SR_shadow_7_c);
ObjectSetText("lo_6_p1",DoubleToStr(lo_ma_p1_6,Digits),7,"Arial",fib_SR_shadow_7_c);
//----
ObjectCreate("hi_6_p1",OBJ_TREND,0,t1_p1, hi_ma_p1_6, t2_p1, hi_ma_p1_6);
ObjectSet("hi_6_p1",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hi_6_p1",OBJPROP_WIDTH,2);
ObjectSet("hi_6_p1",OBJPROP_RAY,false);
ObjectSet("hi_6_p1",OBJPROP_COLOR,fib_SR_shadow_7_c);
ObjectSetText("hi_6_p1",DoubleToStr(hi_ma_p1_6,Digits),7,"Arial",fib_SR_shadow_7_c);
}
//_______________Moving Average Support & Resistance Levels______________________________
string space=" ";
ObjectCreate("ma1_p1",OBJ_TEXT,0,t1_p1,ma1_p1);//13 ma
ObjectSetText("ma1_p1",space+DoubleToStr(ma1_p1,Digits),8,"Arial",White);
ObjectCreate("ma2_p1",OBJ_TEXT,0,t1_p1,ma2_p1);//21 ma
ObjectSetText("ma2_p1",space+DoubleToStr(ma2_p1,Digits),8,"Arial",White);
ObjectCreate("ma3_p1",OBJ_TEXT,0,t1_p1,ma3_p1);//34 ma
//----
if(Bid>ma3_p1) {ObjectSetText("ma3_p1",space+DoubleToStr(ma3_p1,Digits),8,"Arial",LightGreen);}
if(Ask<ma3_p1) {ObjectSetText("ma3_p1",space+DoubleToStr(ma3_p1,Digits),8,"Arial",Pink);}
if(Bid<=ma3_p1 && Ask>=ma3_p1)
{
ObjectSetText("ma3_p1",space+DoubleToStr(ma3_p1,Digits),8,"Arial",Yellow);}
ObjectCreate("ma4_p1",OBJ_TEXT,0,t1_p1,ma4_p1);//55 ma
if(Bid>ma4_p1) {ObjectSetText("ma4_p1",space+DoubleToStr(ma4_p1,Digits),8,"Arial",LightGreen);}
if(Ask<ma4_p1) {ObjectSetText("ma4_p1",space+DoubleToStr(ma4_p1,Digits),8,"Arial",Pink);}
if(Bid<=ma4_p1 && Ask>=ma4_p1)
{
ObjectSetText("ma4_p1",space+DoubleToStr(ma4_p1,Digits),8,"Arial",Yellow);}
ObjectCreate("ma5_p1",OBJ_TEXT,0,t1_p1,ma5_p1);//89 ma
if(Bid>ma5_p1) {ObjectSetText("ma5_p1",space+DoubleToStr(ma5_p1,Digits),8,"Arial",Green);}
if(Ask<ma5_p1) {ObjectSetText("ma5_p1",space+DoubleToStr(ma5_p1,Digits),8,"Arial",Red);}
if(Bid<=ma5_p1 && Ask>=ma5_p1)
{
ObjectSetText("ma5_p1",space+DoubleToStr(ma5_p1,Digits),8,"Arial",Yellow);
}
ObjectCreate("ma6_p1",OBJ_TEXT,0,t1_p1,NormalizeDouble(ma6_p1,Digits));//144 ma
if(Bid>ma6_p1) {ObjectSetText("ma6_p1",space+DoubleToStr(ma6_p1,Digits),8,"Arial",Green);}
if(Ask<ma6_p1) {ObjectSetText("ma6_p1",space+DoubleToStr(ma6_p1,Digits),8,"Arial",Red);}
if(Bid<=ma6_p1 && Ask>=ma6_p1)
{
ObjectSetText("ma6_p1",space+DoubleToStr(ma6_p1,Digits),8,"Arial",Yellow);}
ObjectCreate("ma7_p1",OBJ_TEXT,0,t1_p1,NormalizeDouble(ma7_p1,Digits));//233 ma
if(Bid>ma7_p1) {ObjectSetText("ma7_p1",space+DoubleToStr(ma7_p1,Digits),8,"Arial",Green);}
if(Ask<ma7_p1) {ObjectSetText("ma7_p1",space+DoubleToStr(ma7_p1,Digits),8,"Arial",Red);}
if(Bid<=ma7_p1 && Ask>=ma7_p1)
{
ObjectSetText("ma7_p1",space+DoubleToStr(ma7_p1,Digits),8,"Arial",Yellow);}
}
//end p1_Fib_Plot()
void p2_Fib_Plot()
{
//p2 dynamic fibo levels
double lo_ma_p2,hi_ma_p2;
lo_ma_p2=ma1_p2;
if(ma2_p2<lo_ma_p2) {lo_ma_p2=ma2_p2;}
if(ma3_p2<lo_ma_p2) {lo_ma_p2=ma3_p2;}
if(ma4_p2<lo_ma_p2) {lo_ma_p2=ma4_p2;}
if(ma5_p2<lo_ma_p2) {lo_ma_p2=ma5_p2;}
if(ma6_p2<lo_ma_p2) {lo_ma_p2=ma6_p2;}
if(ma7_p2<lo_ma_p2) {lo_ma_p2=ma7_p2;}
lo_ma_p2=NormalizeDouble(lo_ma_p2+(fib_SR_shadow_1*Point),Digits);
//----
hi_ma_p2=ma7_p2;
if(ma6_p2>hi_ma_p2) {hi_ma_p2=ma6_p2;}
if(ma5_p2>hi_ma_p2) {hi_ma_p2=ma5_p2;}
if(ma4_p2>hi_ma_p2) {hi_ma_p2=ma4_p2;}
if(ma3_p2>hi_ma_p2) {hi_ma_p2=ma3_p2;}
if(ma2_p2>hi_ma_p2) {hi_ma_p2=ma2_p2;}
if(ma1_p2>hi_ma_p2) {hi_ma_p2=ma1_p2;}
hi_ma_p2=NormalizeDouble(hi_ma_p2-(fib_SR_shadow_1*Point),Digits);
//p2 center dynamic fib placement
if(lo_ma_p2-hi_ma_p2>Ask-Bid)
{
ObjectCreate("lcf_p2",OBJ_TREND,0,t1_p2, lo_ma_p2, t2_p2, lo_ma_p2);
ObjectSet("lcf_p2",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lcf_p2",OBJPROP_WIDTH,2);
ObjectSet("lcf_p2",OBJPROP_RAY,false);
ObjectSet("lcf_p2",OBJPROP_COLOR,fib_SR_shadow_1_c);
ObjectSetText("lcf_p2",DoubleToStr(lo_ma_p2,Digits),7,"Arial",fib_SR_shadow_1_c);
//----
ObjectCreate("hcf_p2",OBJ_TREND,0,t1_p2, hi_ma_p2, t2_p2, hi_ma_p2);
ObjectSet("hcf_p2",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hcf_p2",OBJPROP_WIDTH,2);
ObjectSet("hcf_p2",OBJPROP_RAY,false);
ObjectSet("hcf_p2",OBJPROP_COLOR,fib_SR_shadow_1_c);
ObjectSetText("hcf_p2",DoubleToStr(hi_ma_p2,Digits),7,"Arial",fib_SR_shadow_1_c);
}
//----
double lo_ma_p2_1, lo_ma_p2_2, lo_ma_p2_3, lo_ma_p2_4, lo_ma_p2_5, lo_ma_p2_6;
lo_ma_p2_1=lo_ma_p2+(fib_SR_shadow_2*Point);
lo_ma_p2_2=lo_ma_p2_1+(fib_SR_shadow_3*Point);
lo_ma_p2_3=lo_ma_p2_2+(fib_SR_shadow_4*Point);
lo_ma_p2_4=lo_ma_p2_3+(fib_SR_shadow_5*Point);
lo_ma_p2_5=lo_ma_p2_4+(fib_SR_shadow_6*Point);
lo_ma_p2_6=lo_ma_p2_5+(fib_SR_shadow_7*Point);
//----
double hi_ma_p2_1, hi_ma_p2_2, hi_ma_p2_3, hi_ma_p2_4, hi_ma_p2_5, hi_ma_p2_6;
hi_ma_p2_1=hi_ma_p2-(fib_SR_shadow_2*Point);
hi_ma_p2_2=hi_ma_p2_1-(fib_SR_shadow_3*Point);
hi_ma_p2_3=hi_ma_p2_2-(fib_SR_shadow_4*Point);
hi_ma_p2_4=hi_ma_p2_3-(fib_SR_shadow_5*Point);
hi_ma_p2_5=hi_ma_p2_4-(fib_SR_shadow_6*Point);
hi_ma_p2_6=hi_ma_p2_5-(fib_SR_shadow_7*Point);
//p2 1st level (hi_1_p2, lo_1_p2)
if(lo_ma_p2_1-hi_ma_p2_1>Ask-Bid)
{
ObjectCreate("lo_1_p2",OBJ_TREND,0,t1_p2, lo_ma_p2_1, t2_p2, lo_ma_p2_1);
ObjectSet("lo_1_p2",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lo_1_p2",OBJPROP_WIDTH,2);
ObjectSet("lo_1_p2",OBJPROP_RAY,false);
ObjectSet("lo_1_p2",OBJPROP_COLOR,fib_SR_shadow_2_c);
ObjectSetText("lo_1_p2",DoubleToStr(lo_ma_p2_1,Digits),7,"Arial",fib_SR_shadow_2_c);
//----
ObjectCreate("hi_1_p2",OBJ_TREND,0,t1_p2, hi_ma_p2_1, t2_p2, hi_ma_p2_1);
ObjectSet("hi_1_p2",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hi_1_p2",OBJPROP_WIDTH,2);
ObjectSet("hi_1_p2",OBJPROP_RAY,false);
ObjectSet("hi_1_p2",OBJPROP_COLOR,fib_SR_shadow_2_c);
ObjectSetText("hi_1_p2",DoubleToStr(hi_ma_p2_1,Digits),7,"Arial",fib_SR_shadow_2_c);
}
// 2st level (hi_2_p2, lo_2_p2)
if(lo_ma_p2_2-hi_ma_p2_2>Ask-Bid)
{
ObjectCreate("lo_2_p2",OBJ_TREND,0,t1_p2, lo_ma_p2_2, t2_p2, lo_ma_p2_2);
ObjectSet("lo_2_p2",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lo_2_p2",OBJPROP_WIDTH,2);
ObjectSet("lo_2_p2",OBJPROP_RAY,false);
ObjectSet("lo_2_p2",OBJPROP_COLOR,fib_SR_shadow_3_c);
ObjectSetText("lo_2_p2",DoubleToStr(lo_ma_p2_2,Digits),7,"Arial",fib_SR_shadow_3_c);
//----
ObjectCreate("hi_2_p2",OBJ_TREND,0,t1_p2, hi_ma_p2_2, t2_p2, hi_ma_p2_2);
ObjectSet("hi_2_p2",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hi_2_p2",OBJPROP_WIDTH,2);
ObjectSet("hi_2_p2",OBJPROP_RAY,false);
ObjectSet("hi_2_p2",OBJPROP_COLOR,fib_SR_shadow_3_c);
ObjectSetText("hi_2_p2",DoubleToStr(hi_ma_p2_2,Digits),7,"Arial",fib_SR_shadow_3_c);
}
// 3rd level (hi_3_p2, lo_3_p2)
if(lo_ma_p2_3-hi_ma_p2_3>Ask-Bid)
{
ObjectCreate("lo_3_p2",OBJ_TREND,0,t1_p2, lo_ma_p2_3, t2_p2, lo_ma_p2_3);
ObjectSet("lo_3_p2",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lo_3_p2",OBJPROP_WIDTH,2);
ObjectSet("lo_3_p2",OBJPROP_RAY,false);
ObjectSet("lo_3_p2",OBJPROP_COLOR,fib_SR_shadow_4_c);
ObjectSetText("lo_3_p2",DoubleToStr(lo_ma_p2_3,Digits),7,"Arial",fib_SR_shadow_4_c);
//----
ObjectCreate("hi_3_p2",OBJ_TREND,0,t1_p2, hi_ma_p2_3, t2_p2, hi_ma_p2_3);
ObjectSet("hi_3_p2",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hi_3_p2",OBJPROP_WIDTH,2);
ObjectSet("hi_3_p2",OBJPROP_RAY,false);
ObjectSet("hi_3_p2",OBJPROP_COLOR,fib_SR_shadow_4_c);
ObjectSetText("hi_3_p2",DoubleToStr(hi_ma_p2_3,Digits),7,"Arial",fib_SR_shadow_4_c);
}
// 4th level (hi_4_p2, lo_4_p2)
if(lo_ma_p2_4-hi_ma_p2_4>Ask-Bid)
{
ObjectCreate("lo_4_p2",OBJ_TREND,0,t1_p2, lo_ma_p2_4, t2_p2, lo_ma_p2_4);
ObjectSet("lo_4_p2",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lo_4_p2",OBJPROP_WIDTH,2);
ObjectSet("lo_4_p2",OBJPROP_RAY,false);
ObjectSet("lo_4_p2",OBJPROP_COLOR,fib_SR_shadow_5_c);
ObjectSetText("lo_4_p2",DoubleToStr(lo_ma_p2_4,Digits),7,"Arial",fib_SR_shadow_5_c);
//----
ObjectCreate("hi_4_p2",OBJ_TREND,0,t1_p2, hi_ma_p2_4, t2_p2, hi_ma_p2_4);
ObjectSet("hi_4_p2",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hi_4_p2",OBJPROP_WIDTH,2);
ObjectSet("hi_4_p2",OBJPROP_RAY,false);
ObjectSet("hi_4_p2",OBJPROP_COLOR,fib_SR_shadow_5_c);
ObjectSetText("hi_4_p2",DoubleToStr(hi_ma_p2_4,Digits),7,"Arial",fib_SR_shadow_5_c);
}
// 5th level (hi_5_p2, lo_5_p2)
if(lo_ma_p2_5-hi_ma_p2_5>Ask-Bid)
{
ObjectCreate("lo_5_p2",OBJ_TREND,0,t1_p2, lo_ma_p2_5, t2_p2, lo_ma_p2_5);
ObjectSet("lo_5_p2",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lo_5_p2",OBJPROP_WIDTH,2);
ObjectSet("lo_5_p2",OBJPROP_RAY,false);
ObjectSet("lo_5_p2",OBJPROP_COLOR,fib_SR_shadow_6_c);
ObjectSetText("lo_5_p2",DoubleToStr(lo_ma_p2_5,Digits),7,"Arial",fib_SR_shadow_6_c);
//----
ObjectCreate("hi_5_p2",OBJ_TREND,0,t1_p2, hi_ma_p2_5, t2_p2, hi_ma_p2_5);
ObjectSet("hi_5_p2",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hi_5_p2",OBJPROP_WIDTH,2);
ObjectSet("hi_5_p2",OBJPROP_RAY,false);
ObjectSet("hi_5_p2",OBJPROP_COLOR,fib_SR_shadow_6_c);
ObjectSetText("hi_5_p2",DoubleToStr(hi_ma_p2_5,Digits),7,"Arial",fib_SR_shadow_6_c);
}
// 6th level (hi_6_p2, lo_6_p2)
if(lo_ma_p2_6-hi_ma_p2_6>Ask-Bid)
{
ObjectCreate("lo_6_p2",OBJ_TREND,0,t1_p2, lo_ma_p2_6, t2_p2, lo_ma_p2_6);
ObjectSet("lo_6_p2",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lo_6_p2",OBJPROP_WIDTH,2);
ObjectSet("lo_6_p2",OBJPROP_RAY,false);
ObjectSet("lo_6_p2",OBJPROP_COLOR,fib_SR_shadow_7_c);
ObjectSetText("lo_6_p2",DoubleToStr(lo_ma_p2_6,Digits),7,"Arial",fib_SR_shadow_7_c);
//----
ObjectCreate("hi_6_p2",OBJ_TREND,0,t1_p2, hi_ma_p2_6, t2_p2, hi_ma_p2_6);
ObjectSet("hi_6_p2",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hi_6_p2",OBJPROP_WIDTH,2);
ObjectSet("hi_6_p2",OBJPROP_RAY,false);
ObjectSet("hi_6_p2",OBJPROP_COLOR,fib_SR_shadow_7_c);
ObjectSetText("hi_6_p2",DoubleToStr(hi_ma_p2_6,Digits),7,"Arial",fib_SR_shadow_7_c);
}
//_______________Moving Average Support & Resistance Levels______________________________
string space=" ";
ObjectCreate("ma1_p2",OBJ_TEXT,0,t1_p2,ma1_p2);//13 ma
ObjectSetText("ma1_p2",space+DoubleToStr(ma1_p2,Digits),8,"Arial",White);
ObjectCreate("ma2_p2",OBJ_TEXT,0,t1_p2,ma2_p2);//21 ma
ObjectSetText("ma2_p2",space+DoubleToStr(ma2_p2,Digits),8,"Arial",White);
ObjectCreate("ma3_p2",OBJ_TEXT,0,t1_p2,ma3_p2);//34 ma
//----
if(Bid>ma3_p2) {ObjectSetText("ma3_p2",space+DoubleToStr(ma3_p2,Digits),8,"Arial",LightGreen);}
if(Ask<ma3_p2) {ObjectSetText("ma3_p2",space+DoubleToStr(ma3_p2,Digits),8,"Arial",Pink);}
if(Bid<=ma3_p2 && Ask>=ma3_p2)
{
ObjectSetText("ma3_p2",space+DoubleToStr(ma3_p2,Digits),8,"Arial",Yellow);
}
ObjectCreate("ma4_p2",OBJ_TEXT,0,t1_p2,ma4_p2);//55 ma
if(Bid>ma4_p2) {ObjectSetText("ma4_p2",space+DoubleToStr(ma4_p2,Digits),8,"Arial",LightGreen);}
if(Ask<ma4_p2) {ObjectSetText("ma4_p2",space+DoubleToStr(ma4_p2,Digits),8,"Arial",Pink);}
if(Bid<=ma4_p2 && Ask>=ma4_p2)
{
ObjectSetText("ma4_p2",space+DoubleToStr(ma4_p2,Digits),8,"Arial",Yellow);
}
ObjectCreate("ma5_p2",OBJ_TEXT,0,t1_p2,ma5_p2);//89 ma
if(Bid>ma5_p2) {ObjectSetText("ma5_p2",space+DoubleToStr(ma5_p2,Digits),8,"Arial",Green);}
if(Ask<ma5_p2) {ObjectSetText("ma5_p2",space+DoubleToStr(ma5_p2,Digits),8,"Arial",Red);}
if(Bid<=ma5_p2 && Ask>=ma5_p2)
{
ObjectSetText("ma5_p2",space+DoubleToStr(ma5_p2,Digits),8,"Arial",Yellow);
}
ObjectCreate("ma6_p2",OBJ_TEXT,0,t1_p2,NormalizeDouble(ma6_p2,Digits));//144 ma
if(Bid>ma6_p2) {ObjectSetText("ma6_p2",space+DoubleToStr(ma6_p2,Digits),8,"Arial",Green);}
if(Ask<ma6_p2) {ObjectSetText("ma6_p2",space+DoubleToStr(ma6_p2,Digits),8,"Arial",Red);}
if(Bid<=ma6_p2 && Ask>=ma6_p2)
{
ObjectSetText("ma6_p2",space+DoubleToStr(ma6_p2,Digits),8,"Arial",Yellow);
}
ObjectCreate("ma7_p2",OBJ_TEXT,0,t1_p2,NormalizeDouble(ma7_p2,Digits));//233 ma
if(Bid>ma7_p2) {ObjectSetText("ma7_p2",space+DoubleToStr(ma7_p2,Digits),8,"Arial",Green);}
if(Ask<ma7_p2) {ObjectSetText("ma7_p2",space+DoubleToStr(ma7_p2,Digits),8,"Arial",Red);}
if(Bid<=ma7_p2 && Ask>=ma7_p2)
{
ObjectSetText("ma7_p2",space+DoubleToStr(ma7_p2,Digits),8,"Arial",Yellow);
}
}
//end p2_Fib_Plot()
void p3_Fib_Plot()
{
//p3 dynamic fibo levels
double lo_ma_p3,hi_ma_p3;
lo_ma_p3=ma1_p3;
if(ma2_p3<lo_ma_p3) {lo_ma_p3=ma2_p3;}
if(ma3_p3<lo_ma_p3) {lo_ma_p3=ma3_p3;}
if(ma4_p3<lo_ma_p3) {lo_ma_p3=ma4_p3;}
if(ma5_p3<lo_ma_p3) {lo_ma_p3=ma5_p3;}
if(ma6_p3<lo_ma_p3) {lo_ma_p3=ma6_p3;}
if(ma7_p3<lo_ma_p3) {lo_ma_p3=ma7_p3;}
lo_ma_p3=NormalizeDouble(lo_ma_p3+(fib_SR_shadow_1*Point),Digits);
hi_ma_p3=ma7_p3;
if(ma6_p3>hi_ma_p3) {hi_ma_p3=ma6_p3;}
if(ma5_p3>hi_ma_p3) {hi_ma_p3=ma5_p3;}
if(ma4_p3>hi_ma_p3) {hi_ma_p3=ma4_p3;}
if(ma3_p3>hi_ma_p3) {hi_ma_p3=ma3_p3;}
if(ma2_p3>hi_ma_p3) {hi_ma_p3=ma2_p3;}
if(ma1_p3>hi_ma_p3) {hi_ma_p3=ma1_p3;}
hi_ma_p3=NormalizeDouble(hi_ma_p3-(fib_SR_shadow_1*Point),Digits);
//p3 center dynamic fib placement
if(lo_ma_p3-hi_ma_p3>Ask-Bid)
{
ObjectCreate("lcf_p3",OBJ_TREND,0,t1_p3, lo_ma_p3, t2_p3, lo_ma_p3);
ObjectSet("lcf_p3",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lcf_p3",OBJPROP_WIDTH,2);
ObjectSet("lcf_p3",OBJPROP_RAY,false);
ObjectSet("lcf_p3",OBJPROP_COLOR,fib_SR_shadow_1_c);
ObjectSetText("lcf_p3",DoubleToStr(lo_ma_p3,Digits),7,"Arial",fib_SR_shadow_1_c);
//----
ObjectCreate("hcf_p3",OBJ_TREND,0,t1_p3, hi_ma_p3, t2_p3, hi_ma_p3);
ObjectSet("hcf_p3",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hcf_p3",OBJPROP_WIDTH,2);
ObjectSet("hcf_p3",OBJPROP_RAY,false);
ObjectSet("hcf_p3",OBJPROP_COLOR,fib_SR_shadow_1_c);
ObjectSetText("hcf_p3",DoubleToStr(hi_ma_p3,Digits),7,"Arial",fib_SR_shadow_1_c);
}
//----
double lo_ma_p3_1, lo_ma_p3_2, lo_ma_p3_3, lo_ma_p3_4, lo_ma_p3_5, lo_ma_p3_6;
lo_ma_p3_1=lo_ma_p3+(fib_SR_shadow_2*Point);
lo_ma_p3_2=lo_ma_p3_1+(fib_SR_shadow_3*Point);
lo_ma_p3_3=lo_ma_p3_2+(fib_SR_shadow_4*Point);
lo_ma_p3_4=lo_ma_p3_3+(fib_SR_shadow_5*Point);
lo_ma_p3_5=lo_ma_p3_4+(fib_SR_shadow_6*Point);
lo_ma_p3_6=lo_ma_p3_5+(fib_SR_shadow_7*Point);
//----
double hi_ma_p3_1, hi_ma_p3_2, hi_ma_p3_3, hi_ma_p3_4, hi_ma_p3_5, hi_ma_p3_6;
hi_ma_p3_1=hi_ma_p3-(fib_SR_shadow_2*Point);
hi_ma_p3_2=hi_ma_p3_1-(fib_SR_shadow_3*Point);
hi_ma_p3_3=hi_ma_p3_2-(fib_SR_shadow_4*Point);
hi_ma_p3_4=hi_ma_p3_3-(fib_SR_shadow_5*Point);
hi_ma_p3_5=hi_ma_p3_4-(fib_SR_shadow_6*Point);
hi_ma_p3_6=hi_ma_p3_5-(fib_SR_shadow_7*Point);
//p3 1st level (hi_1_p3, lo_1_p3)
if(lo_ma_p3_1-hi_ma_p3_1>Ask-Bid)
{
ObjectCreate("lo_1_p3",OBJ_TREND,0,t1_p3, lo_ma_p3_1, t2_p3, lo_ma_p3_1);
ObjectSet("lo_1_p3",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lo_1_p3",OBJPROP_WIDTH,2);
ObjectSet("lo_1_p3",OBJPROP_RAY,false);
ObjectSet("lo_1_p3",OBJPROP_COLOR,fib_SR_shadow_2_c);
ObjectSetText("lo_1_p3",DoubleToStr(lo_ma_p3_1,Digits),7,"Arial",fib_SR_shadow_2_c);
//----
ObjectCreate("hi_1_p3",OBJ_TREND,0,t1_p3, hi_ma_p3_1, t2_p3, hi_ma_p3_1);
ObjectSet("hi_1_p3",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hi_1_p3",OBJPROP_WIDTH,2);
ObjectSet("hi_1_p3",OBJPROP_RAY,false);
ObjectSet("hi_1_p3",OBJPROP_COLOR,fib_SR_shadow_2_c);
ObjectSetText("hi_1_p3",DoubleToStr(hi_ma_p3_1,Digits),7,"Arial",fib_SR_shadow_2_c);
}
// 2st level (hi_2_p3, lo_2_p3)
if(lo_ma_p3_2-hi_ma_p3_2>Ask-Bid)
{
ObjectCreate("lo_2_p3",OBJ_TREND,0,t1_p3, lo_ma_p3_2, t2_p3, lo_ma_p3_2);
ObjectSet("lo_2_p3",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lo_2_p3",OBJPROP_WIDTH,2);
ObjectSet("lo_2_p3",OBJPROP_RAY,false);
ObjectSet("lo_2_p3",OBJPROP_COLOR,fib_SR_shadow_3_c);
ObjectSetText("lo_2_p3",DoubleToStr(lo_ma_p3_2,Digits),7,"Arial",fib_SR_shadow_3_c);
//----
ObjectCreate("hi_2_p3",OBJ_TREND,0,t1_p3, hi_ma_p3_2, t2_p3, hi_ma_p3_2);
ObjectSet("hi_2_p3",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hi_2_p3",OBJPROP_WIDTH,2);
ObjectSet("hi_2_p3",OBJPROP_RAY,false);
ObjectSet("hi_2_p3",OBJPROP_COLOR,fib_SR_shadow_3_c);
ObjectSetText("hi_2_p3",DoubleToStr(hi_ma_p3_2,Digits),7,"Arial",fib_SR_shadow_3_c);
}
// 3rd level (hi_3_p3, lo_3_p3)
if(lo_ma_p3_3-hi_ma_p3_3>Ask-Bid)
{
ObjectCreate("lo_3_p3",OBJ_TREND,0,t1_p3, lo_ma_p3_3, t2_p3, lo_ma_p3_3);
ObjectSet("lo_3_p3",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lo_3_p3",OBJPROP_WIDTH,2);
ObjectSet("lo_3_p3",OBJPROP_RAY,false);
ObjectSet("lo_3_p3",OBJPROP_COLOR,fib_SR_shadow_4_c);
ObjectSetText("lo_3_p3",DoubleToStr(lo_ma_p3_3,Digits),7,"Arial",fib_SR_shadow_4_c);
//----
ObjectCreate("hi_3_p3",OBJ_TREND,0,t1_p3, hi_ma_p3_3, t2_p3, hi_ma_p3_3);
ObjectSet("hi_3_p3",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hi_3_p3",OBJPROP_WIDTH,2);
ObjectSet("hi_3_p3",OBJPROP_RAY,false);
ObjectSet("hi_3_p3",OBJPROP_COLOR,fib_SR_shadow_4_c);
ObjectSetText("hi_3_p3",DoubleToStr(hi_ma_p3_3,Digits),7,"Arial",fib_SR_shadow_4_c);
}
// 4th level (hi_4_p3, lo_4_p3)
if(lo_ma_p3_4-hi_ma_p3_4>Ask-Bid)
{
ObjectCreate("lo_4_p3",OBJ_TREND,0,t1_p3, lo_ma_p3_4, t2_p3, lo_ma_p3_4);
ObjectSet("lo_4_p3",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lo_4_p3",OBJPROP_WIDTH,2);
ObjectSet("lo_4_p3",OBJPROP_RAY,false);
ObjectSet("lo_4_p3",OBJPROP_COLOR,fib_SR_shadow_5_c);
ObjectSetText("lo_4_p3",DoubleToStr(lo_ma_p3_4,Digits),7,"Arial",fib_SR_shadow_5_c);
//----
ObjectCreate("hi_4_p3",OBJ_TREND,0,t1_p3, hi_ma_p3_4, t2_p3, hi_ma_p3_4);
ObjectSet("hi_4_p3",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hi_4_p3",OBJPROP_WIDTH,2);
ObjectSet("hi_4_p3",OBJPROP_RAY,false);
ObjectSet("hi_4_p3",OBJPROP_COLOR,fib_SR_shadow_5_c);
ObjectSetText("hi_4_p3",DoubleToStr(hi_ma_p3_4,Digits),7,"Arial",fib_SR_shadow_5_c);
}
// 5th level (hi_5_p3, lo_5_p3)
if(lo_ma_p3_5-hi_ma_p3_5>Ask-Bid)
{
ObjectCreate("lo_5_p3",OBJ_TREND,0,t1_p3, lo_ma_p3_5, t2_p3, lo_ma_p3_5);
ObjectSet("lo_5_p3",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lo_5_p3",OBJPROP_WIDTH,2);
ObjectSet("lo_5_p3",OBJPROP_RAY,false);
ObjectSet("lo_5_p3",OBJPROP_COLOR,fib_SR_shadow_6_c);
ObjectSetText("lo_5_p3",DoubleToStr(lo_ma_p3_5,Digits),7,"Arial",fib_SR_shadow_6_c);
//----
ObjectCreate("hi_5_p3",OBJ_TREND,0,t1_p3, hi_ma_p3_5, t2_p3, hi_ma_p3_5);
ObjectSet("hi_5_p3",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hi_5_p3",OBJPROP_WIDTH,2);
ObjectSet("hi_5_p3",OBJPROP_RAY,false);
ObjectSet("hi_5_p3",OBJPROP_COLOR,fib_SR_shadow_6_c);
ObjectSetText("hi_5_p3",DoubleToStr(hi_ma_p3_5,Digits),7,"Arial",fib_SR_shadow_6_c);
}
// 6th level (hi_6_p3, lo_6_p3)
if(lo_ma_p3_6-hi_ma_p3_6>Ask-Bid)
{
ObjectCreate("lo_6_p3",OBJ_TREND,0,t1_p3, lo_ma_p3_6, t2_p3, lo_ma_p3_6);
ObjectSet("lo_6_p3",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lo_6_p3",OBJPROP_WIDTH,2);
ObjectSet("lo_6_p3",OBJPROP_RAY,false);
ObjectSet("lo_6_p3",OBJPROP_COLOR,fib_SR_shadow_7_c);
ObjectSetText("lo_6_p3",DoubleToStr(lo_ma_p3_6,Digits),7,"Arial",fib_SR_shadow_7_c);
//----
ObjectCreate("hi_6_p3",OBJ_TREND,0,t1_p3, hi_ma_p3_6, t2_p3, hi_ma_p3_6);
ObjectSet("hi_6_p3",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hi_6_p3",OBJPROP_WIDTH,2);
ObjectSet("hi_6_p3",OBJPROP_RAY,false);
ObjectSet("hi_6_p3",OBJPROP_COLOR,fib_SR_shadow_7_c);
ObjectSetText("hi_6_p3",DoubleToStr(hi_ma_p3_6,Digits),7,"Arial",fib_SR_shadow_7_c);
}
//_______________Moving Average Support & Resistance Levels______________________________
string space=" ";
ObjectCreate("ma1_p3",OBJ_TEXT,0,t1_p3,ma1_p3);//13 ma
ObjectSetText("ma1_p3",space+DoubleToStr(ma1_p3,Digits),8,"Arial",White);
ObjectCreate("ma2_p3",OBJ_TEXT,0,t1_p3,ma2_p3);//21 ma
ObjectSetText("ma2_p3",space+DoubleToStr(ma2_p3,Digits),8,"Arial",White);
ObjectCreate("ma3_p3",OBJ_TEXT,0,t1_p3,ma3_p3);//34 ma
if(Bid>ma3_p3) {ObjectSetText("ma3_p3",space+DoubleToStr(ma3_p3,Digits),8,"Arial",LightGreen);
}
if(Ask<ma3_p3) {ObjectSetText("ma3_p3",space+DoubleToStr(ma3_p3,Digits),8,"Arial",Pink);
}
if(Bid<=ma3_p3 && Ask>=ma3_p3)
{
ObjectSetText("ma3_p3",space+DoubleToStr(ma3_p3,Digits),8,"Arial",Yellow);
}
ObjectCreate("ma4_p3",OBJ_TEXT,0,t1_p3,ma4_p3);//55 ma
if(Bid>ma4_p3) {ObjectSetText("ma4_p3",space+DoubleToStr(ma4_p3,Digits),8,"Arial",LightGreen);
}
if(Ask<ma4_p3) {ObjectSetText("ma4_p3",space+DoubleToStr(ma4_p3,Digits),8,"Arial",Pink);
}
if(Bid<=ma4_p3 && Ask>=ma4_p3)
{
ObjectSetText("ma4_p3",space+DoubleToStr(ma4_p3,Digits),8,"Arial",Yellow);
}
//----
ObjectCreate("ma5_p3",OBJ_TEXT,0,t1_p3,ma5_p3);//89 ma
if(Bid>ma5_p3) {ObjectSetText("ma5_p3",space+DoubleToStr(ma5_p3,Digits),8,"Arial",Green);
}
if(Ask<ma5_p3) {ObjectSetText("ma5_p3",space+DoubleToStr(ma5_p3,Digits),8,"Arial",Red);
}
if(Bid<=ma5_p3 && Ask>=ma5_p3)
{
ObjectSetText("ma5_p3",space+DoubleToStr(ma5_p3,Digits),8,"Arial",Yellow);
}
//----
ObjectCreate("ma6_p3",OBJ_TEXT,0,t1_p3,NormalizeDouble(ma6_p3,Digits));//144 ma
if(Bid>ma6_p3) {ObjectSetText("ma6_p3",space+DoubleToStr(ma6_p3,Digits),8,"Arial",Green);
}
if(Ask<ma6_p3) {ObjectSetText("ma6_p3",space+DoubleToStr(ma6_p3,Digits),8,"Arial",Red);
}
if(Bid<=ma6_p3 && Ask>=ma6_p3)
{
ObjectSetText("ma6_p3",space+DoubleToStr(ma6_p3,Digits),8,"Arial",Yellow);
}
//----
ObjectCreate("ma7_p3",OBJ_TEXT,0,t1_p3,NormalizeDouble(ma7_p3,Digits));//233 ma
if(Bid>ma7_p3) {ObjectSetText("ma7_p3",space+DoubleToStr(ma7_p3,Digits),8,"Arial",Green);
}
if(Ask<ma7_p3) {ObjectSetText("ma7_p3",space+DoubleToStr(ma7_p3,Digits),8,"Arial",Red);
}
if(Bid<=ma7_p3 && Ask>=ma7_p3)
{
ObjectSetText("ma7_p3",space+DoubleToStr(ma7_p3,Digits),8,"Arial",Yellow);
}
}
//end p3_Fib_Plot()
void p4_Fib_Plot()
{
//p4 dynamic fibo levels
double lo_ma_p4,hi_ma_p4;
lo_ma_p4=ma1_p4;
if(ma2_p4<lo_ma_p4) {lo_ma_p4=ma2_p4;}
if(ma3_p4<lo_ma_p4) {lo_ma_p4=ma3_p4;}
if(ma4_p4<lo_ma_p4) {lo_ma_p4=ma4_p4;}
if(ma5_p4<lo_ma_p4) {lo_ma_p4=ma5_p4;}
if(ma6_p4<lo_ma_p4) {lo_ma_p4=ma6_p4;}
if(ma7_p4<lo_ma_p4) {lo_ma_p4=ma7_p4;}
lo_ma_p4=NormalizeDouble(lo_ma_p4+(fib_SR_shadow_1*Point),Digits);
//----
hi_ma_p4=ma7_p4;
if(ma6_p4>hi_ma_p4) {hi_ma_p4=ma6_p4;}
if(ma5_p4>hi_ma_p4) {hi_ma_p4=ma5_p4;}
if(ma4_p4>hi_ma_p4) {hi_ma_p4=ma4_p4;}
if(ma3_p4>hi_ma_p4) {hi_ma_p4=ma3_p4;}
if(ma2_p4>hi_ma_p4) {hi_ma_p4=ma2_p4;}
if(ma1_p4>hi_ma_p4) {hi_ma_p4=ma1_p4;}
hi_ma_p4=NormalizeDouble(hi_ma_p4-(fib_SR_shadow_1*Point),Digits);
//p4 center dynamic fib placement
if(lo_ma_p4-hi_ma_p4>Ask-Bid)
{
ObjectCreate("lcf_p4",OBJ_TREND,0,t1_p4, lo_ma_p4, t2_p4, lo_ma_p4);
ObjectSet("lcf_p4",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lcf_p4",OBJPROP_WIDTH,2);
ObjectSet("lcf_p4",OBJPROP_RAY,false);
ObjectSet("lcf_p4",OBJPROP_COLOR,fib_SR_shadow_1_c);
ObjectSetText("lcf_p4",DoubleToStr(lo_ma_p4,Digits),7,"Arial",fib_SR_shadow_1_c);
//----
ObjectCreate("hcf_p4",OBJ_TREND,0,t1_p4, hi_ma_p4, t2_p4, hi_ma_p4);
ObjectSet("hcf_p4",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hcf_p4",OBJPROP_WIDTH,2);
ObjectSet("hcf_p4",OBJPROP_RAY,false);
ObjectSet("hcf_p4",OBJPROP_COLOR,fib_SR_shadow_1_c);
ObjectSetText("hcf_p4",DoubleToStr(hi_ma_p4,Digits),7,"Arial",fib_SR_shadow_1_c);
}
//----
double lo_ma_p4_1, lo_ma_p4_2, lo_ma_p4_3, lo_ma_p4_4, lo_ma_p4_5, lo_ma_p4_6;
lo_ma_p4_1=lo_ma_p4+(fib_SR_shadow_2*Point);
lo_ma_p4_2=lo_ma_p4_1+(fib_SR_shadow_3*Point);
lo_ma_p4_3=lo_ma_p4_2+(fib_SR_shadow_4*Point);
lo_ma_p4_4=lo_ma_p4_3+(fib_SR_shadow_5*Point);
lo_ma_p4_5=lo_ma_p4_4+(fib_SR_shadow_6*Point);
lo_ma_p4_6=lo_ma_p4_5+(fib_SR_shadow_7*Point);
//-----
double hi_ma_p4_1, hi_ma_p4_2, hi_ma_p4_3, hi_ma_p4_4, hi_ma_p4_5, hi_ma_p4_6;
hi_ma_p4_1=hi_ma_p4-(fib_SR_shadow_2*Point);
hi_ma_p4_2=hi_ma_p4_1-(fib_SR_shadow_3*Point);
hi_ma_p4_3=hi_ma_p4_2-(fib_SR_shadow_4*Point);
hi_ma_p4_4=hi_ma_p4_3-(fib_SR_shadow_5*Point);
hi_ma_p4_5=hi_ma_p4_4-(fib_SR_shadow_6*Point);
hi_ma_p4_6=hi_ma_p4_5-(fib_SR_shadow_7*Point);
//p4 1st level (hi_1_p4, lo_1_p4)
if(lo_ma_p4_1-hi_ma_p4_1>Ask-Bid)
{
ObjectCreate("lo_1_p4",OBJ_TREND,0,t1_p4, lo_ma_p4_1, t2_p4, lo_ma_p4_1);
ObjectSet("lo_1_p4",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lo_1_p4",OBJPROP_WIDTH,2);
ObjectSet("lo_1_p4",OBJPROP_RAY,false);
ObjectSet("lo_1_p4",OBJPROP_COLOR,fib_SR_shadow_2_c);
ObjectSetText("lo_1_p4",DoubleToStr(lo_ma_p4_1,Digits),7,"Arial",fib_SR_shadow_2_c);
//----
ObjectCreate("hi_1_p4",OBJ_TREND,0,t1_p4, hi_ma_p4_1, t2_p4, hi_ma_p4_1);
ObjectSet("hi_1_p4",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hi_1_p4",OBJPROP_WIDTH,2);
ObjectSet("hi_1_p4",OBJPROP_RAY,false);
ObjectSet("hi_1_p4",OBJPROP_COLOR,fib_SR_shadow_2_c);
ObjectSetText("hi_1_p4",DoubleToStr(hi_ma_p4_1,Digits),7,"Arial",fib_SR_shadow_2_c);
}
// 2st level (hi_2_p4, lo_2_p4)
if(lo_ma_p4_2-hi_ma_p4_2>Ask-Bid)
{
ObjectCreate("lo_2_p4",OBJ_TREND,0,t1_p4, lo_ma_p4_2, t2_p4, lo_ma_p4_2);
ObjectSet("lo_2_p4",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lo_2_p4",OBJPROP_WIDTH,2);
ObjectSet("lo_2_p4",OBJPROP_RAY,false);
ObjectSet("lo_2_p4",OBJPROP_COLOR,fib_SR_shadow_3_c);
ObjectSetText("lo_2_p4",DoubleToStr(lo_ma_p4_2,Digits),7,"Arial",fib_SR_shadow_3_c);
//----
ObjectCreate("hi_2_p4",OBJ_TREND,0,t1_p4, hi_ma_p4_2, t2_p4, hi_ma_p4_2);
ObjectSet("hi_2_p4",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hi_2_p4",OBJPROP_WIDTH,2);
ObjectSet("hi_2_p4",OBJPROP_RAY,false);
ObjectSet("hi_2_p4",OBJPROP_COLOR,fib_SR_shadow_3_c);
ObjectSetText("hi_2_p4",DoubleToStr(hi_ma_p4_2,Digits),7,"Arial",fib_SR_shadow_3_c);
}
// 3rd level (hi_3_p4, lo_3_p4)
if(lo_ma_p4_3-hi_ma_p4_3>Ask-Bid)
{
ObjectCreate("lo_3_p4",OBJ_TREND,0,t1_p4, lo_ma_p4_3, t2_p4, lo_ma_p4_3);
ObjectSet("lo_3_p4",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lo_3_p4",OBJPROP_WIDTH,2);
ObjectSet("lo_3_p4",OBJPROP_RAY,false);
ObjectSet("lo_3_p4",OBJPROP_COLOR,fib_SR_shadow_4_c);
ObjectSetText("lo_3_p4",DoubleToStr(lo_ma_p4_3,Digits),7,"Arial",fib_SR_shadow_4_c);
//-----
ObjectCreate("hi_3_p4",OBJ_TREND,0,t1_p4, hi_ma_p4_3, t2_p4, hi_ma_p4_3);
ObjectSet("hi_3_p4",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hi_3_p4",OBJPROP_WIDTH,2);
ObjectSet("hi_3_p4",OBJPROP_RAY,false);
ObjectSet("hi_3_p4",OBJPROP_COLOR,fib_SR_shadow_4_c);
ObjectSetText("hi_3_p4",DoubleToStr(hi_ma_p4_3,Digits),7,"Arial",fib_SR_shadow_4_c);
}
// 4th level (hi_4_p4, lo_4_p4)
if(lo_ma_p4_4-hi_ma_p4_4>Ask-Bid)
{
ObjectCreate("lo_4_p4",OBJ_TREND,0,t1_p4, lo_ma_p4_4, t2_p4, lo_ma_p4_4);
ObjectSet("lo_4_p4",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lo_4_p4",OBJPROP_WIDTH,2);
ObjectSet("lo_4_p4",OBJPROP_RAY,false);
ObjectSet("lo_4_p4",OBJPROP_COLOR,fib_SR_shadow_5_c);
ObjectSetText("lo_4_p4",DoubleToStr(lo_ma_p4_4,Digits),7,"Arial",fib_SR_shadow_5_c);
//----
ObjectCreate("hi_4_p4",OBJ_TREND,0,t1_p4, hi_ma_p4_4, t2_p4, hi_ma_p4_4);
ObjectSet("hi_4_p4",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hi_4_p4",OBJPROP_WIDTH,2);
ObjectSet("hi_4_p4",OBJPROP_RAY,false);
ObjectSet("hi_4_p4",OBJPROP_COLOR,fib_SR_shadow_5_c);
ObjectSetText("hi_4_p4",DoubleToStr(hi_ma_p4_4,Digits),7,"Arial",fib_SR_shadow_5_c);
}
// 5th level (hi_5_p4, lo_5_p4)
if(lo_ma_p4_5-hi_ma_p4_5>Ask-Bid)
{
ObjectCreate("lo_5_p4",OBJ_TREND,0,t1_p4, lo_ma_p4_5, t2_p4, lo_ma_p4_5);
ObjectSet("lo_5_p4",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lo_5_p4",OBJPROP_WIDTH,2);
ObjectSet("lo_5_p4",OBJPROP_RAY,false);
ObjectSet("lo_5_p4",OBJPROP_COLOR,fib_SR_shadow_6_c);
ObjectSetText("lo_5_p4",DoubleToStr(lo_ma_p4_5,Digits),7,"Arial",fib_SR_shadow_6_c);
//----
ObjectCreate("hi_5_p4",OBJ_TREND,0,t1_p4, hi_ma_p4_5, t2_p4, hi_ma_p4_5);
ObjectSet("hi_5_p4",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hi_5_p4",OBJPROP_WIDTH,2);
ObjectSet("hi_5_p4",OBJPROP_RAY,false);
ObjectSet("hi_5_p4",OBJPROP_COLOR,fib_SR_shadow_6_c);
ObjectSetText("hi_5_p4",DoubleToStr(hi_ma_p4_5,Digits),7,"Arial",fib_SR_shadow_6_c);
}
// 6th level (hi_6_p4, lo_6_p4)
if(lo_ma_p4_6-hi_ma_p4_6>Ask-Bid)
{
ObjectCreate("lo_6_p4",OBJ_TREND,0,t1_p4, lo_ma_p4_6, t2_p4, lo_ma_p4_6);
ObjectSet("lo_6_p4",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("lo_6_p4",OBJPROP_WIDTH,2);
ObjectSet("lo_6_p4",OBJPROP_RAY,false);
ObjectSet("lo_6_p4",OBJPROP_COLOR,fib_SR_shadow_7_c);
ObjectSetText("lo_6_p4",DoubleToStr(lo_ma_p4_6,Digits),7,"Arial",fib_SR_shadow_7_c);
//----
ObjectCreate("hi_6_p4",OBJ_TREND,0,t1_p4, hi_ma_p4_6, t2_p4, hi_ma_p4_6);
ObjectSet("hi_6_p4",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("hi_6_p4",OBJPROP_WIDTH,2);
ObjectSet("hi_6_p4",OBJPROP_RAY,false);
ObjectSet("hi_6_p4",OBJPROP_COLOR,fib_SR_shadow_7_c);
ObjectSetText("hi_6_p4",DoubleToStr(hi_ma_p4_6,Digits),7,"Arial",fib_SR_shadow_7_c);
}
//_______________Moving Average Support & Resistance Levels______________________________
string space=" ";
ObjectCreate("ma1_p4",OBJ_TEXT,0,t1_p4,ma1_p4);//13 ma
ObjectSetText("ma1_p4",space+DoubleToStr(ma1_p4,Digits),8,"Arial",White);
ObjectCreate("ma2_p4",OBJ_TEXT,0,t1_p4,ma2_p4);//21 ma
ObjectSetText("ma2_p4",space+DoubleToStr(ma2_p4,Digits),8,"Arial",White);
ObjectCreate("ma3_p4",OBJ_TEXT,0,t1_p4,ma3_p4);//34 ma
//----
if(Bid>ma3_p4) {ObjectSetText("ma3_p4",space+DoubleToStr(ma3_p4,Digits),8,"Arial",LightGreen);
}
if(Ask<ma3_p4) {ObjectSetText("ma3_p4",space+DoubleToStr(ma3_p4,Digits),8,"Arial",Pink);
}
if(Bid<=ma3_p4 && Ask>=ma3_p4)
{
ObjectSetText("ma3_p4",space+DoubleToStr(ma3_p4,Digits),8,"Arial",Yellow);
}
ObjectCreate("ma4_p4",OBJ_TEXT,0,t1_p4,ma4_p4);//55 ma
if(Bid>ma4_p4) {ObjectSetText("ma4_p4",space+DoubleToStr(ma4_p4,Digits),8,"Arial",LightGreen);
}
if(Ask<ma4_p4) {ObjectSetText("ma4_p4",space+DoubleToStr(ma4_p4,Digits),8,"Arial",Pink);
}
if(Bid<=ma4_p4 && Ask>=ma4_p4)
{
ObjectSetText("ma4_p4",space+DoubleToStr(ma4_p4,Digits),8,"Arial",Yellow);
}
ObjectCreate("ma5_p4",OBJ_TEXT,0,t1_p4,ma5_p4);//89 ma
if(Bid>ma5_p4) {ObjectSetText("ma5_p4",space+DoubleToStr(ma5_p4,Digits),8,"Arial",Green);
}
if(Ask<ma5_p4) {ObjectSetText("ma5_p4",space+DoubleToStr(ma5_p4,Digits),8,"Arial",Red);
}
if(Bid<=ma5_p4 && Ask>=ma5_p4)
{
ObjectSetText("ma5_p4",space+DoubleToStr(ma5_p4,Digits),8,"Arial",Yellow);
}
ObjectCreate("ma6_p4",OBJ_TEXT,0,t1_p4,NormalizeDouble(ma6_p4,Digits));//144 ma
if(Bid>ma6_p4) {ObjectSetText("ma6_p4",space+DoubleToStr(ma6_p4,Digits),8,"Arial",Green);
}
if(Ask<ma6_p4) {ObjectSetText("ma6_p4",space+DoubleToStr(ma6_p4,Digits),8,"Arial",Red);
}
if(Bid<=ma6_p4 && Ask>=ma6_p4)
{
ObjectSetText("ma6_p4",space+DoubleToStr(ma6_p4,Digits),8,"Arial",Yellow);
}
ObjectCreate("ma7_p4",OBJ_TEXT,0,t1_p4,NormalizeDouble(ma7_p4,Digits));//233 ma
if(Bid>ma7_p4) {ObjectSetText("ma7_p4",space+DoubleToStr(ma7_p4,Digits),8,"Arial",Green);
}
if(Ask<ma7_p4) {ObjectSetText("ma7_p4",space+DoubleToStr(ma7_p4,Digits),8,"Arial",Red);
}
if(Bid<=ma7_p4 && Ask>=ma7_p4)
{
ObjectSetText("ma7_p4",space+DoubleToStr(ma7_p4,Digits),8,"Arial",Yellow);
}
}
//end p4_Fib.Plot()
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
void column()
{
//..................Time Frame Columns.................................................
string down, up;down=(string)Bid; up=(string)Ask;
//----
ObjectCreate((string)p1_ma+"m "+down,OBJ_RECTANGLE,0,t1_p1,Bid,t2_p1,0);
ObjectSet((string)p1_ma+"m "+down,OBJPROP_COLOR,Red);
ObjectCreate((string)p1_ma+"m "+up,OBJ_RECTANGLE,0,t1_p1,Ask,t2_p1,Ask*1.5);
ObjectSet((string)p1_ma+"m "+up,OBJPROP_COLOR,Green);
//----
ObjectCreate((string)p2_ma+"m "+down,OBJ_RECTANGLE,0,t1_p2,0,t2_p2,Bid);
ObjectSet((string)p2_ma+"m "+down,OBJPROP_COLOR,Red);
ObjectCreate((string)p2_ma+"m "+up,OBJ_RECTANGLE,0,t1_p2,Ask,t2_p2,Ask*1.5);
ObjectSet((string)p2_ma+"m "+up,OBJPROP_COLOR,Green);
//----
ObjectCreate((string)p3_ma+"m "+down,OBJ_RECTANGLE,0,t1_p3,Bid,t2_p3,0);
ObjectSet((string)p3_ma+"m "+down,OBJPROP_COLOR,Red);
ObjectCreate((string)p3_ma+"m "+up,OBJ_RECTANGLE,0,t1_p3,Ask,t2_p3,Ask*1.5);
ObjectSet((string)p3_ma+"m "+up,OBJPROP_COLOR,Green);
//----
ObjectCreate((string)p4_ma+"m "+down,OBJ_RECTANGLE,0,t1_p4,Bid,t2_p4,0);
ObjectSet((string)p4_ma+"m "+down,OBJPROP_COLOR,Red);
ObjectCreate((string)p4_ma+"m "+up,OBJ_RECTANGLE,0,t1_p4,Ask,t2_p4,Ask*1.5);
ObjectSet((string)p4_ma+"m "+up,OBJPROP_COLOR,Green);}//end column();
//---- done
//+------------------------------------------------------------------+
Comments
