DFC Next_v3
Download script
This script is designed as a technical analysis tool for the MetaTrader platform, specifically used to identify and project Fibonacci-based price channels on a trading chart. Its primary purpose is to automate the calculation of upper and lower price boundaries based on historical volatility and specific time intervals.
Core Logic Overview
The script operates by identifying significant "delimiter" points in time—such as the start of new hours, days, or weeks—depending on which timeframe the user is currently viewing. Once these boundaries are identified, the script looks back at a specific number of previous cycles to determine the highest and lowest price points reached during that period.
Key Functional Components
1. Timeframe Awareness and Delimiting The logic includes a specialized awareness of time. It recognizes that different trading periods (like 15 minutes, 1 hour, or 4 hours) have different "reset" points. The script identifies these specific moments to segment the market history into organized blocks.
2. Dynamic Fibonacci Calculations Instead of drawing static lines, the script calculates two primary price levels:
- The Mean Value: It establishes a baseline by averaging the highest high, the lowest low, and the previous closing price of a identified period.
- Upper and Lower Channels: Using a user-defined ratio (the Fibonacci component), it projects an upper and lower boundary outward from that mean value. This creates a visual "channel" representing potential price zones.
3. Historical Data Smoothing The script features two different modes of display:
- Sectional Mode: It draws the boundaries specifically at the start of new time delimiters, allowing traders to see how the channel shifts at specific intervals (e.g., every new day).
- Continuous/Moving Mode: If enabled, the script can project these values across all bars in a sequence. It does this by calculating the "delta" (the rate of change) between established boundary points and filling in the gaps linearly so that the lines appear connected and smooth.
4. Real-Time Updates The logic is designed to update dynamically with the live market. It constantly monitors the current bar and recalculates the highest highs and lowest lows as price action develops, ensuring that the projected Fibonacci channels remain relevant to current market volatility.
Summary for the User
In short, this tool takes the "messy" data of historical price movement and organizes it into clean, mathematically derived channels. It tells you where the "ceiling" and "floor" might be based on a specific percentage (the Ratio) of the previous price range, adjusted automatically for the timeframe you are trading.
Miscellaneous
24
Views
0
Downloads
0
Favorites
DFC Next_v3
//+------------------------------------------------------------------------------------+
//| Din_fibo_Next.mq4 |
//| unknown author, get from kaizer, conversed by Rosh |
//| link to kaizer: http://forum.alpari-idc.ru/profile.php?mode=viewprofile&u=4196161 |
//| http://forexsystems.ru/phpBB/index.php|
//+------------------------------------------------------------------------------------+
#property copyright "unknown author, get from kaizer, conversed by Rosh"
#property link "http://forexsystems.ru/phpBB/index.php"
#property indicator_chart_window
#property indicator_buffers 2
#property indicator_color1 Red
#property indicator_color2 Red
//---- input parameters
extern int Fibo_Channel_Period = 3;
extern double Ratio = 0.786;
extern bool SetAllBars = false;
//---- buffers
double ExtMapBuffer1[];
double ExtMapBuffer2[];
double tvBuffer[];
//----
int hh, ll, first, counterPeriod;
double tv, MaH, MaL;
//+------------------------------------------------------------------+
//| Ïîëó÷èì ñëåäóþùèé ïåðèîä |
//+------------------------------------------------------------------+
string GetNextPeriod(int _Period)
{
string nextPeriod="";
//----
switch (_Period)
{
case 5: nextPeriod = "H1"; break;
case 15: nextPeriod = "H1"; break;
case 30: nextPeriod = "H4"; break;
case 60: nextPeriod = "H4"; break;
case 240: nextPeriod = "D1"; break;
case 1440: nextPeriod = "W1"; break;
case 10080: nextPeriod = "M"; break;
default: Print("Íåäîïóñòèìûé ïåðèîä!!!");
}
//----
return(nextPeriod);
}
//+------------------------------------------------------------------+
//| Ïðîâåðèì - ðàçäåëèòåëü äèàïàçîíà èëè íåò |
//+------------------------------------------------------------------+
bool isDelimeter(int _Period, int _shift)
{
bool result=false;
//----
switch (_Period)
{
case 5: result = (TimeMinute(Time[_shift]) == 0);
break;
case 15: result = (TimeMinute(Time[_shift]) == 0);
break;
case 30: result = (TimeMinute(Time[_shift]) == 0) &&
MathMod(TimeHour(Time[_shift]), 4.0) == 0.0;
break;
case 60: result = (TimeMinute(Time[_shift]) == 0) &&
MathMod(TimeHour(Time[_shift]),4.0) == 0.0;
break;
case 240: result = (TimeMinute(Time[_shift]) == 0) &&
(TimeHour(Time[_shift]) == 0);
break;
case 1440: result = (TimeDayOfWeek(Time[_shift]) == 1) &&
(TimeHour(Time[_shift]) == 0);
break;
case 10080: result = (TimeDay(Time[_shift]) == 1) ||
((TimeDay(Time[_shift])==2 &&
TimeDay(Time[_shift+1]) !=1 ))||
((TimeDay(Time[_shift]) == 3 &&
TimeDay(Time[_shift+1]) != 2));
break;
default: Print("Íåäîïóñòèìûé ïåðèîä!!!");
}
//----
return(result);
}
//+------------------------------------------------------------------+
//| Óñòàíîâèì MaH è MaL íà ãðàíèöå äèàïàçîíà |
//+------------------------------------------------------------------+
void SetHnL(int _shift)
{
//----
int i = _shift + 1;
counterPeriod = 0;
first = 0;
while(counterPeriod < Fibo_Channel_Period)
{
while(tvBuffer[i] == 0.0 && i < Bars)
i++;
if(first == 0)
first = i;
counterPeriod++;
i++;
}
i--;
hh = Highest(NULL, 0, MODE_HIGH, i - _shift, _shift + 1);
ll = Lowest(NULL, 0, MODE_LOW, i - _shift, _shift + 1);
tv = NormalizeDouble((High[hh] + Low[ll] + Close[_shift+1]) / 3.0, Digits);
MaH = tv + NormalizeDouble((High[hh] - Low[ll]) / 2.0*Ratio, Digits);
MaL = tv - NormalizeDouble((High[hh] - Low[ll]) / 2.0*Ratio, Digits);
tvBuffer[_shift] = tv;
ExtMapBuffer1[_shift] = MaH;
ExtMapBuffer2[_shift] = MaL;
if(SetAllBars)
SetMovingHnL(first, _shift);
}
//+------------------------------------------------------------------+
//| Óñòàíîâèì MaH è MaL âíóòðè äèàïàçîíà |
//+------------------------------------------------------------------+
void SetMovingHnL(int _DelimeterBar, int CurBar)
{
int m_cnt;
double deltaH, deltaL;
//----
deltaH = (ExtMapBuffer1[_DelimeterBar] - ExtMapBuffer1[CurBar]) / (_DelimeterBar-CurBar);
deltaL = (ExtMapBuffer2[_DelimeterBar] - ExtMapBuffer2[CurBar]) / (_DelimeterBar-CurBar);
for(m_cnt = _DelimeterBar - 1; m_cnt > CurBar; m_cnt--)
{
ExtMapBuffer1[m_cnt] = ExtMapBuffer1[m_cnt+1] - deltaH;
ExtMapBuffer2[m_cnt] = ExtMapBuffer2[m_cnt+1] - deltaL;
}
for(m_cnt = _DelimeterBar - 1; m_cnt > CurBar; m_cnt--)
{
ExtMapBuffer1[m_cnt] = NormalizeDouble(ExtMapBuffer1[m_cnt], Digits);
ExtMapBuffer2[m_cnt] = NormalizeDouble(ExtMapBuffer2[m_cnt], Digits);
}
}
//+------------------------------------------------------------------+
//| Óñòàíîâèì MaH è MaL íà ïðàâîì êðàþ |
//+------------------------------------------------------------------+
void SetValuesNullBar(int _shift)
{
//----
int i = _shift;
while(tvBuffer[i] == 0.0)
i++;
for(int j = i - 1; j > _shift; j--)
{
ExtMapBuffer1[j] = 0.0;
ExtMapBuffer2[j] = 0.0;
}
first = 0;
i = _shift;
counterPeriod = 0;
while(counterPeriod<Fibo_Channel_Period)
{
while(tvBuffer[i] == 0.0 && i < Bars)
i++;
if(first == 0)
first = i;
counterPeriod++;
i++;
}
i--;
hh = Highest(NULL, 0, MODE_HIGH, i - _shift, _shift);
ll = Lowest(NULL, 0, MODE_LOW, i - _shift, _shift);
tv = NormalizeDouble((High[hh] + Low[ll] + Close[_shift]) / 3.0, Digits);
MaH = tv + NormalizeDouble((High[hh] - Low[ll]) / 2.0*Ratio, Digits);
MaL = tv - NormalizeDouble((High[hh] - Low[ll]) / 2.0*Ratio, Digits);
ExtMapBuffer1[_shift] = MaH;
ExtMapBuffer2[_shift] = MaL;
if(SetAllBars)
SetMovingHnL(first, _shift);
}
//-------------------------------------------------------------------+
//| Custom indicator initialization function |
//+------------------------------------------------------------------+
int init()
{
//---- indicators
IndicatorBuffers(3);
string label;
if(SetAllBars)
{
SetIndexStyle(0, DRAW_LINE);
SetIndexBuffer(0, ExtMapBuffer1);
label = "DFC Next " + GetNextPeriod(Period()) + "(" + Fibo_Channel_Period + ") MaH";
SetIndexLabel(0, label);
SetIndexEmptyValue(0, 0.0);
SetIndexStyle(1, DRAW_LINE);
SetIndexBuffer(1, ExtMapBuffer2);
label="DFC Next " + GetNextPeriod(Period()) + "(" + Fibo_Channel_Period + ") MaL";
SetIndexLabel(1, label);
SetIndexEmptyValue(1, 0.0);
}
else
{
SetIndexStyle(0, DRAW_SECTION);
SetIndexBuffer(0, ExtMapBuffer1);
label="DFC Next " + GetNextPeriod(Period()) + "(" + Fibo_Channel_Period + ") MaH";
SetIndexLabel(0, label);
SetIndexEmptyValue(0, 0.0);
SetIndexStyle(1, DRAW_SECTION);
SetIndexBuffer(1, ExtMapBuffer2);
label="DFC Next " + GetNextPeriod(Period()) + "(" + Fibo_Channel_Period + ") MaL";
SetIndexLabel(1, label);
SetIndexEmptyValue(1, 0.0);
}
//----
SetIndexBuffer(2, tvBuffer);
SetIndexEmptyValue(2, 0.0);
//----
return(0);
}
//+------------------------------------------------------------------+
//| Custor indicator deinitialization function |
//+------------------------------------------------------------------+
int deinit()
{
//----
return(0);
}
//+------------------------------------------------------------------+
//| Custom indicator iteration function |
//+------------------------------------------------------------------+
int start()
{
int counted_bars = IndicatorCounted();
int cnt, limit;
//----
if(Period() == 10080)
return;
if(counted_bars < 0)
return(-1);
if(counted_bars > 0)
limit = Bars - counted_bars;
if(counted_bars == 0)
{
// íàéòè ïåðâûé è âòîðîé ðàçäåëèòåëü è óñòàíîâèòü limit
cnt = Bars - 1;
while(!isDelimeter(Period(), cnt))
cnt--;
first = cnt;
cnt--;
counterPeriod = 0;
while(counterPeriod < Fibo_Channel_Period)
{
while(!isDelimeter(Period(), cnt))
cnt--;
cnt--;
counterPeriod++;
}
cnt++;
hh = Highest(NULL, 0, MODE_HIGH, first-cnt, cnt + 1);
ll = Lowest(NULL, 0, MODE_LOW, first - cnt, cnt + 1);
tv = NormalizeDouble((High[hh] + Low[ll] + Close[cnt+1]) / 3.0, Digits);
MaH = tv + NormalizeDouble((High[hh] - Low[ll]) / 2.0*Ratio, Digits);
MaL = tv - NormalizeDouble((High[hh] - Low[ll]) / 2.0*Ratio, Digits);
tvBuffer[cnt] = tv;
ExtMapBuffer1[cnt] = MaH;
ExtMapBuffer2[cnt] = MaL;
limit = cnt - 1;
}
//----
for(int shift = limit; shift >= 0; shift--)
{
if(isDelimeter(Period(), shift))
SetHnL(shift); // else SetMovingHnL(shift);
if(shift == 0)
SetValuesNullBar(shift);
}
//----
return(0);
}
//+------------------------------------------------------------------+
