Fractals
Download script
This script is designed to identify and highlight specific price patterns on a trading chart known as "Fractals." In technical analysis, fractals are used to pinpoint potential turning points in the market—specifically, local peaks (highs) and valleys (lows).
Core Functionality
The primary purpose of this tool is to automatically scan historical price data and place visual markers (arrows) on the chart whenever it detects a specific geometric relationship between a candle and its neighboring candles.
How the Logic Works
The script evaluates every price bar on the chart by looking at the "High" and "Low" prices. It searches for two distinct types of movements:
1. Upward Fractals (Peaks) The tool looks for high points where the price reaches a local maximum. It validates these in several configurations:
- Standard Peak: A single candle whose high is strictly higher than the two candles immediately preceding it and the two candles immediately following it.
- Extended Peaks: The script also checks for more complex patterns involving 6, 7, 8, or 9 consecutive bars. In these cases, it looks for "plateaus" where the price stays at a certain high level across multiple bars while ensuring that all candles outside of that specific range are lower.
2. Downward Fractals (Valleys) Similarly, the tool identifies local minimums where the price reaches a valley. It checks for:
- Standard Valley: A single candle whose low is strictly lower than the two candles preceding it and the two candles following it.
- Extended Valleys: Just like the upward patterns, it scans for wider formations spanning up to 9 bars, identifying areas where the price bottoms out and remains at that level before moving higher on either side.
Visual Output
When the script successfully identifies one of these patterns:
- It places a Red marker (arrow) above the high point for upward fractals.
- It places a Blue marker (arrow) below the low point for downward fractals.
By providing these visual cues, the script helps traders see "structural" points in the market price action, making it easier to identify support and resistance levels or potential trend reversals at a glance.
Miscellaneous
12
Views
0
Downloads
0
Favorites
Fractals
//+------------------------------------------------------------------+
//| Fractals.mq4 |
//| Copyright © 2005, MetaQuotes Software Corp. |
//| http://www.metaquotes.net |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2005, MetaQuotes Software Corp."
#property link "http://www.metaquotes.net"
#property indicator_chart_window
#property indicator_buffers 2
#property indicator_color1 Red
#property indicator_color2 Blue
//---- input parameters
//---- buffers
double ExtUpFractalsBuffer[];
double ExtDownFractalsBuffer[];
//+------------------------------------------------------------------+
//| Custom indicator initialization function |
//+------------------------------------------------------------------+
int init()
{
//---- indicator buffers mapping
SetIndexBuffer(0,ExtUpFractalsBuffer);
SetIndexBuffer(1,ExtDownFractalsBuffer);
//---- drawing settings
SetIndexStyle(0,DRAW_ARROW);
SetIndexArrow(0,119);
SetIndexStyle(1,DRAW_ARROW);
SetIndexArrow(1,119);
//----
SetIndexEmptyValue(0,0.0);
SetIndexEmptyValue(1,0.0);
//---- name for DataWindow
SetIndexLabel(0,"Fractal Up");
SetIndexLabel(1,"Fractal Down");
//---- initialization done
return(0);
}
//+------------------------------------------------------------------+
//| Custor indicator deinitialization function |
//+------------------------------------------------------------------+
int deinit()
{
//---- TODO: add your code here
//----
return(0);
}
//+------------------------------------------------------------------+
//| Custom indicator iteration function |
//+------------------------------------------------------------------+
int start()
{
int i,nCountedBars;
bool bFound;
double dCurrent;
nCountedBars=IndicatorCounted();
//---- last counted bar will be recounted
if(nCountedBars<=2)
i=Bars-nCountedBars-3;
if(nCountedBars>2)
{
nCountedBars--;
i=Bars-nCountedBars-1;
}
//----Up and Down Fractals
while(i>=2)
{
//----Fractals up
bFound=false;
dCurrent=High[i];
if(dCurrent>High[i+1] && dCurrent>High[i+2] && dCurrent>High[i-1] && dCurrent>High[i-2])
{
bFound=true;
ExtUpFractalsBuffer[i]=dCurrent;
}
//----6 bars Fractal
if(!bFound && (Bars-i-1)>=3)
{
if(dCurrent==High[i+1] && dCurrent>High[i+2] && dCurrent>High[i+3] &&
dCurrent>High[i-1] && dCurrent>High[i-2])
{
bFound=true;
ExtUpFractalsBuffer[i]=dCurrent;
}
}
//----7 bars Fractal
if(!bFound && (Bars-i-1)>=4)
{
if(dCurrent>=High[i+1] && dCurrent==High[i+2] && dCurrent>High[i+3] && dCurrent>High[i+4] &&
dCurrent>High[i-1] && dCurrent>High[i-2])
{
bFound=true;
ExtUpFractalsBuffer[i]=dCurrent;
}
}
//----8 bars Fractal
if(!bFound && (Bars-i-1)>=5)
{
if(dCurrent>=High[i+1] && dCurrent==High[i+2] && dCurrent==High[i+3] && dCurrent>High[i+4] && dCurrent>High[i+5] &&
dCurrent>High[i-1] && dCurrent>High[i-2])
{
bFound=true;
ExtUpFractalsBuffer[i]=dCurrent;
}
}
//----9 bars Fractal
if(!bFound && (Bars-i-1)>=6)
{
if(dCurrent>=High[i+1] && dCurrent==High[i+2] && dCurrent>=High[i+3] && dCurrent==High[i+4] && dCurrent>High[i+5] &&
dCurrent>High[i+6] && dCurrent>High[i-1] && dCurrent>High[i-2])
{
bFound=true;
ExtUpFractalsBuffer[i]=dCurrent;
}
}
//----Fractals down
bFound=false;
dCurrent=Low[i];
if(dCurrent<Low[i+1] && dCurrent<Low[i+2] && dCurrent<Low[i-1] && dCurrent<Low[i-2])
{
bFound=true;
ExtDownFractalsBuffer[i]=dCurrent;
}
//----6 bars Fractal
if(!bFound && (Bars-i-1)>=3)
{
if(dCurrent==Low[i+1] && dCurrent<Low[i+2] && dCurrent<Low[i+3] &&
dCurrent<Low[i-1] && dCurrent<Low[i-2])
{
bFound=true;
ExtDownFractalsBuffer[i]=dCurrent;
}
}
//----7 bars Fractal
if(!bFound && (Bars-i-1)>=4)
{
if(dCurrent<=Low[i+1] && dCurrent==Low[i+2] && dCurrent<Low[i+3] && dCurrent<Low[i+4] &&
dCurrent<Low[i-1] && dCurrent<Low[i-2])
{
bFound=true;
ExtDownFractalsBuffer[i]=dCurrent;
}
}
//----8 bars Fractal
if(!bFound && (Bars-i-1)>=5)
{
if(dCurrent<=Low[i+1] && dCurrent==Low[i+2] && dCurrent==Low[i+3] && dCurrent<Low[i+4] && dCurrent<Low[i+5] &&
dCurrent<Low[i-1] && dCurrent<Low[i-2])
{
bFound=true;
ExtDownFractalsBuffer[i]=dCurrent;
}
}
//----9 bars Fractal
if(!bFound && (Bars-i-1)>=6)
{
if(dCurrent<=Low[i+1] && dCurrent==Low[i+2] && dCurrent<=Low[i+3] && dCurrent==Low[i+4] && dCurrent<Low[i+5] &&
dCurrent<Low[i+6] && dCurrent<Low[i-1] && dCurrent<Low[i-2])
{
bFound=true;
ExtDownFractalsBuffer[i]=dCurrent;
}
}
i--;
}
//----
return(0);
}
//+------------------------------------------------------------------+
