GG-TimeFramer
Download scriptThe GG-TimeFramer is a specialized visual tool designed for the MetaTrader 4 platform to help traders organize and visualize multi-timeframe price action within a single view. Instead of forcing you to switch back and forth between different charts (like jumping from a 1-minute chart to a Daily chart), this script consolidates that information into a clean, structured layout.
Core Functionality
The primary purpose of this script is to provide a "bird's-eye view" of the market across seven different timeframes simultaneously: 1 Minute (M1), 5 Minutes (M5), 15 Minutes (M15), 30 Minutes (M30), 1 Hour (H1), 4 Hours (H4), and Daily (D1).
Key Features and Logic
1. Multi-Timeframe Data Collection The script automatically fetches the specific price data—specifically the Opening, High, and Low prices—for all seven timeframes mentioned above. It does this in real-time, ensuring that the information displayed is always current.
2. Dynamic Visual Representation Rather than just showing numbers, the script draws visual "boxes" (rectangles) on your screen. Each box represents a specific timeframe's price range.
- The size and position of these boxes are calculated based on the timeframe they represent.
- It uses a unique labeling system to clearly identify which box belongs to which timeframe (e.g., "Daily," "H4," "M15").
3. Trend Color Coding One of the most useful features is the automated color-coding logic. The script compares the current market price against the opening price of each specific timeframe:
- Upward Movement: If the current price is higher than the opening price of a timeframe, the corresponding box turns a "YellowGreen" color.
- Downward Movement: If the current price is lower than the opening price, it turns a "Tomato" (reddish) color.
- Neutral/Flat: If the price is exactly at the opening, it appears in a neutral "Silver" color.
4. High/Low Reference Lines The script includes optional "High" and "Low" reference lines. These act as boundaries for specific timeframes (like the Daily High and Low). You can toggle these on or off via the settings to see exactly where the price boundaries sit for those larger intervals, helping you identify potential resistance or support levels.
5. Spatial Organization (The "Framer") To keep the screen from looking cluttered, the script uses "Separator Lines." These are vertical markers that divide the visual area into segments. This creates a structured grid where each timeframe has its own dedicated "lane," making it much easier to read at a glance than if all the data were piled on top of one another.
6. Clean Workspace Management The logic includes an automatic cleanup routine. Every time the script refreshes, it deletes the old drawings and replaces them with new ones. This ensures that your chart remains tidy and that you aren't looking at "ghost" data from previous price movements.
//+------------------------------------------------------------------+
//| GG-TimeFramer.mq4 |
//| Copyright © 2009, GGekko |
//| http://www.fx-ggekko.com |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2009, GGekko"
#property link "http://www.fx-ggekko.com"
#property indicator_separate_window
#property indicator_buffers 2
extern string __Copyright__ = "www.fx-ggekko.com";
extern bool Show_Daily_HighLow = true;
extern bool Show_H4_HighLow = false;
extern bool Show_H1_HighLow = false;
extern bool Show_M30_HighLow = false;
extern bool Show_M15_HighLow = false;
extern bool Show_M5_HighLow = false;
extern color UpColor = YellowGreen;
extern color DojiColor = Silver;
extern color DownColor = Tomato;
extern color TextColor = DarkSlateGray;
extern color PriceLineColor = DarkGreen;
extern color HighLowColor = SlateGray;
extern color SeparatorColor = Orange;
extern int CandleWidth = 10;
double M1_O,M1_H,M1_L;
double M5_O,M5_H,M5_L;
double M15_O,M15_H,M15_L;
double M30_O,M30_H,M30_L;
double H1_O,H1_H,H1_L;
double H4_O,H4_H,H4_L;
double D1_O,D1_H,D1_L;
color Color_M1,Color_M5,Color_M15,Color_M30,Color_H1,Color_H4,Color_D1;
//---- buffers
double ExtMapBuffer1[];
double ExtMapBuffer2[];
//+------------------------------------------------------------------+
//| Custom indicator initialization function |
//+------------------------------------------------------------------+
int init()
{
//---- indicators
IndicatorBuffers(2);
SetIndexBuffer(0,ExtMapBuffer1);
SetIndexBuffer(1,ExtMapBuffer2);
SetIndexStyle(0,DRAW_NONE);
SetIndexStyle(1,DRAW_NONE);
IndicatorShortName("GG-TimeFramer (www.fx-ggekko.com)");
//----
return(0);
}
//+------------------------------------------------------------------+
//| Custom indicator deinitialization function |
//+------------------------------------------------------------------+
int deinit()
{
//----
ObjectDelete("D1TF");
ObjectDelete("H4TF");
ObjectDelete("H1TF");
ObjectDelete("M30TF");
ObjectDelete("M15TF");
ObjectDelete("M5TF");
ObjectDelete("M1TF");
ObjectDelete("D1");
ObjectDelete("H4");
ObjectDelete("H1");
ObjectDelete("M30");
ObjectDelete("M15");
ObjectDelete("M5");
ObjectDelete("M1");
ObjectDelete("PriceLine");
ObjectDelete("D1HighLine");
ObjectDelete("D1LowLine");
ObjectDelete("H4HighLine");
ObjectDelete("H4LowLine");
ObjectDelete("H1HighLine");
ObjectDelete("H1LowLine");
ObjectDelete("M30HighLine");
ObjectDelete("M30LowLine");
ObjectDelete("M15HighLine");
ObjectDelete("M15LowLine");
ObjectDelete("M5HighLine");
ObjectDelete("M5LowLine");
ObjectDelete("SeparatorLineD1");
ObjectDelete("SeparatorLineH4");
ObjectDelete("SeparatorLineH1");
ObjectDelete("SeparatorLineM30");
ObjectDelete("SeparatorLineM15");
ObjectDelete("SeparatorLineM5");
//----
return(0);
}
//+------------------------------------------------------------------+
//| Custom indicator iteration function |
//+------------------------------------------------------------------+
int start()
{
M1_O=iOpen(NULL,1,0);
M1_H=iHigh(NULL,1,0);
M1_L=iLow(NULL,1,0);
M5_O=iOpen(NULL,5,0);
M5_H=iHigh(NULL,5,0);
M5_L=iLow(NULL,5,0);
M15_O=iOpen(NULL,15,0);
M15_H=iHigh(NULL,15,0);
M15_L=iLow(NULL,15,0);
M30_O=iOpen(NULL,30,0);
M30_H=iHigh(NULL,30,0);
M30_L=iLow(NULL,30,0);
H1_O=iOpen(NULL,60,0);
H1_H=iHigh(NULL,60,0);
H1_L=iLow(NULL,60,0);
H4_O=iOpen(NULL,240,0);
H4_H=iHigh(NULL,240,0);
H4_L=iLow(NULL,240,0);
D1_O=iOpen(NULL,1440,0);
D1_H=iHigh(NULL,1440,0);
D1_L=iLow(NULL,1440,0);
ExtMapBuffer1[WindowFirstVisibleBar()]=D1_H+5*Point;
ExtMapBuffer2[WindowFirstVisibleBar()]=D1_L-5*Point;
ObjectDelete("D1TF");
ObjectCreate("D1TF",OBJ_TEXT,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[7*CandleWidth-1],Bid);
ObjectSetText("D1TF"," Daily",8,"Tahoma",TextColor);
ObjectDelete("H4TF");
ObjectCreate("H4TF",OBJ_TEXT,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[6*CandleWidth-1],Bid);
ObjectSetText("H4TF"," H4",8,"Tahoma",TextColor);
ObjectDelete("H1TF");
ObjectCreate("H1TF",OBJ_TEXT,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[5*CandleWidth-1],Bid);
ObjectSetText("H1TF"," H1",8,"Tahoma",TextColor);
ObjectDelete("M30TF");
ObjectCreate("M30TF",OBJ_TEXT,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[4*CandleWidth-1],Bid);
ObjectSetText("M30TF"," M30",8,"Tahoma",TextColor);
ObjectDelete("M15TF");
ObjectCreate("M15TF",OBJ_TEXT,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[3*CandleWidth-1],Bid);
ObjectSetText("M15TF"," M15",8,"Tahoma",TextColor);
ObjectDelete("M5TF");
ObjectCreate("M5TF",OBJ_TEXT,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[2*CandleWidth-1],Bid);
ObjectSetText("M5TF"," M5",8,"Tahoma",TextColor);
ObjectDelete("M1TF");
ObjectCreate("M1TF",OBJ_TEXT,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[1*CandleWidth-1],Bid);
ObjectSetText("M1TF"," M1",8,"Tahoma",TextColor);
if(M1_O>Bid) Color_M1=DownColor;
else if(M1_O<Bid) Color_M1=UpColor;
else Color_M1=DojiColor;
if(M5_O>Bid) Color_M5=DownColor;
else if(M5_O<Bid) Color_M5=UpColor;
else Color_M5=DojiColor;
if(M15_O>Bid) Color_M15=DownColor;
else if(M15_O<Bid) Color_M15=UpColor;
else Color_M15=DojiColor;
if(M30_O>Bid) Color_M30=DownColor;
else if(M30_O<Bid) Color_M30=UpColor;
else Color_M30=DojiColor;
if(H1_O>Bid) Color_H1=DownColor;
else if(H1_O<Bid) Color_H1=UpColor;
else Color_H1=DojiColor;
if(H4_O>Bid) Color_H4=DownColor;
else if(H4_O<Bid) Color_H4=UpColor;
else Color_H4=DojiColor;
if(D1_O>Bid) Color_D1=DownColor;
else if(D1_O<Bid) Color_D1=UpColor;
else Color_D1=DojiColor;
ObjectDelete("D1");
ObjectCreate("D1",OBJ_RECTANGLE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[7*CandleWidth],D1_L,Time[6*CandleWidth],D1_H);
ObjectSet("D1",OBJPROP_COLOR,Color_D1);
ObjectDelete("H4");
ObjectCreate("H4",OBJ_RECTANGLE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[6*CandleWidth],H4_L,Time[5*CandleWidth],H4_H);
ObjectSet("H4",OBJPROP_COLOR,Color_H4);
ObjectDelete("H1");
ObjectCreate("H1",OBJ_RECTANGLE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[5*CandleWidth],H1_L,Time[4*CandleWidth],H1_H);
ObjectSet("H1",OBJPROP_COLOR,Color_H1);
ObjectDelete("M30");
ObjectCreate("M30",OBJ_RECTANGLE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[4*CandleWidth],M30_L,Time[3*CandleWidth],M30_H);
ObjectSet("M30",OBJPROP_COLOR,Color_M30);
ObjectDelete("M15");
ObjectCreate("M15",OBJ_RECTANGLE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[3*CandleWidth],M15_L,Time[2*CandleWidth],M15_H);
ObjectSet("M15",OBJPROP_COLOR,Color_M15);
ObjectDelete("M5");
ObjectCreate("M5",OBJ_RECTANGLE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[2*CandleWidth],M5_L,Time[1*CandleWidth],M5_H);
ObjectSet("M5",OBJPROP_COLOR,Color_M5);
ObjectDelete("M1");
ObjectCreate("M1",OBJ_RECTANGLE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[1*CandleWidth],M1_L,Time[0*CandleWidth],M1_H);
ObjectSet("M1",OBJPROP_COLOR,Color_M1);
ObjectDelete("PriceLine");
ObjectCreate("PriceLine",OBJ_HLINE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[WindowFirstVisibleBar()],Bid);
ObjectSet("PriceLine",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("PriceLine",OBJPROP_COLOR,PriceLineColor);
ObjectDelete("D1HighLine");
ObjectDelete("D1LowLine");
if(Show_Daily_HighLow)
{
ObjectCreate("D1HighLine",OBJ_HLINE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[WindowFirstVisibleBar()],D1_H);
ObjectSet("D1HighLine",OBJPROP_STYLE,STYLE_DOT);
ObjectSet("D1HighLine",OBJPROP_COLOR,HighLowColor);
ObjectCreate("D1LowLine",OBJ_HLINE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[WindowFirstVisibleBar()],D1_L);
ObjectSet("D1LowLine",OBJPROP_STYLE,STYLE_DOT);
ObjectSet("D1LowLine",OBJPROP_COLOR,HighLowColor);
}
ObjectDelete("H4HighLine");
ObjectDelete("H4LowLine");
if(Show_H4_HighLow)
{
ObjectCreate("H4HighLine",OBJ_HLINE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[WindowFirstVisibleBar()],H4_H);
ObjectSet("H4HighLine",OBJPROP_STYLE,STYLE_DOT);
ObjectSet("H4HighLine",OBJPROP_COLOR,HighLowColor);
ObjectCreate("H4LowLine",OBJ_HLINE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[WindowFirstVisibleBar()],H4_L);
ObjectSet("H4LowLine",OBJPROP_STYLE,STYLE_DOT);
ObjectSet("H4LowLine",OBJPROP_COLOR,HighLowColor);
}
ObjectDelete("H1HighLine");
ObjectDelete("H1LowLine");
if(Show_H1_HighLow)
{
ObjectCreate("H1HighLine",OBJ_HLINE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[WindowFirstVisibleBar()],H1_H);
ObjectSet("H1HighLine",OBJPROP_STYLE,STYLE_DOT);
ObjectSet("H1HighLine",OBJPROP_COLOR,HighLowColor);
ObjectCreate("H1LowLine",OBJ_HLINE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[WindowFirstVisibleBar()],H1_L);
ObjectSet("H1LowLine",OBJPROP_STYLE,STYLE_DOT);
ObjectSet("H1LowLine",OBJPROP_COLOR,HighLowColor);
}
ObjectDelete("M30HighLine");
ObjectDelete("M30LowLine");
if(Show_M30_HighLow)
{
ObjectCreate("M30HighLine",OBJ_HLINE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[WindowFirstVisibleBar()],M30_H);
ObjectSet("M30HighLine",OBJPROP_STYLE,STYLE_DOT);
ObjectSet("M30HighLine",OBJPROP_COLOR,HighLowColor);
ObjectCreate("M30LowLine",OBJ_HLINE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[WindowFirstVisibleBar()],M30_L);
ObjectSet("M30LowLine",OBJPROP_STYLE,STYLE_DOT);
ObjectSet("M30LowLine",OBJPROP_COLOR,HighLowColor);
}
ObjectDelete("M15HighLine");
ObjectDelete("M15LowLine");
if(Show_M15_HighLow)
{
ObjectCreate("M15HighLine",OBJ_HLINE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[WindowFirstVisibleBar()],M15_H);
ObjectSet("M15HighLine",OBJPROP_STYLE,STYLE_DOT);
ObjectSet("M15HighLine",OBJPROP_COLOR,HighLowColor);
ObjectCreate("M15LowLine",OBJ_HLINE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[WindowFirstVisibleBar()],M15_L);
ObjectSet("M15LowLine",OBJPROP_STYLE,STYLE_DOT);
ObjectSet("M15LowLine",OBJPROP_COLOR,HighLowColor);
}
ObjectDelete("M5HighLine");
ObjectDelete("M5LowLine");
if(Show_M5_HighLow)
{
ObjectCreate("M5HighLine",OBJ_HLINE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[WindowFirstVisibleBar()],M5_H);
ObjectSet("M5HighLine",OBJPROP_STYLE,STYLE_DOT);
ObjectSet("M5HighLine",OBJPROP_COLOR,HighLowColor);
ObjectCreate("M5LowLine",OBJ_HLINE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[WindowFirstVisibleBar()],M5_L);
ObjectSet("M5LowLine",OBJPROP_STYLE,STYLE_DOT);
ObjectSet("M5LowLine",OBJPROP_COLOR,HighLowColor);
}
ObjectDelete("SeparatorLineD1");
ObjectCreate("SeparatorLineD1",OBJ_VLINE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[1*CandleWidth],0);
ObjectSet("SeparatorLineD1",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("SeparatorLineD1",OBJPROP_COLOR,SeparatorColor);
ObjectDelete("SeparatorLineH4");
ObjectCreate("SeparatorLineH4",OBJ_VLINE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[2*CandleWidth],0);
ObjectSet("SeparatorLineH4",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("SeparatorLineH4",OBJPROP_COLOR,SeparatorColor);
ObjectDelete("SeparatorLineH1");
ObjectCreate("SeparatorLineH1",OBJ_VLINE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[3*CandleWidth],0);
ObjectSet("SeparatorLineH1",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("SeparatorLineH1",OBJPROP_COLOR,SeparatorColor);
ObjectDelete("SeparatorLineM30");
ObjectCreate("SeparatorLineM30",OBJ_VLINE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[4*CandleWidth],0);
ObjectSet("SeparatorLineM30",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("SeparatorLineM30",OBJPROP_COLOR,SeparatorColor);
ObjectDelete("SeparatorLineM15");
ObjectCreate("SeparatorLineM15",OBJ_VLINE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[5*CandleWidth],0);
ObjectSet("SeparatorLineM15",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("SeparatorLineM15",OBJPROP_COLOR,SeparatorColor);
ObjectDelete("SeparatorLineM5");
ObjectCreate("SeparatorLineM5",OBJ_VLINE,WindowFind("GG-TimeFramer (www.fx-ggekko.com)"),Time[6*CandleWidth],0);
ObjectSet("SeparatorLineM5",OBJPROP_STYLE,STYLE_SOLID);
ObjectSet("SeparatorLineM5",OBJPROP_COLOR,SeparatorColor);
//----
return(0);
}
//+------------------------------------------------------------------+
