Author: Copyright � 2009, Akif TOKUZ
Market_Statistics_v1

Market Statistics Analysis Overview

This script is designed to provide a comprehensive visual representation of market activity by analyzing historical price and volume data. Rather than just looking at where the price went, it seeks to understand how much "weight" or "effort" was behind those price movements. It achieves this through several sophisticated calculations presented on your trading chart.

Core Visual Components

1. The Volume Histogram (Market Profile) The script creates a visual profile of the market by scanning historical data from a specific starting date. It calculates how much trading volume occurred at every individual price level between the highest and lowest points reached in that period.

  • The Logic: Instead of just showing volume per bar, it "distributes" the volume of each candle across its specific price range (High, Low, Open, and Close).
  • The Result: This creates a horizontal histogram (often seen as a "Profile") that shows which price levels have the most significant historical activity. It identifies areas of high interest where the market spent a lot of energy and "stable" areas where volume was lower.

2. VWAP (Volume Weighted Average Price) The script calculates the VWAP, which is a benchmark used to determine the average price paid for all shares/contracts traded during a specific period, weighted by volume.

  • The Logic: It takes the price of every candle, multiplies it by that candle's volume, and divides the total by the total cumulative volume.
  • The Result: This helps traders see the "true" average price of the market, filtering out "noise" from low-volume price spikes.

3. PVP (Price Volume Profile) This acts as a secondary reference point that anchors the starting price data relative to the volume profile, helping to orient the viewer on where the most significant trading began.

4. Standard Deviation Bands (SD1, SD2, and SD3) To help identify overextended price movements, the script calculates "Standard Deviation" bands based on the VWAP.

  • The Logic: It measures how far the current price has deviated from the Volume Weighted Average Price, accounting for the volume of every bar in the sequence.
  • The Result: These appear as lines (optional) that represent boundaries of "normal" market behavior. When the price pushes significantly outside these bands (SD1, SD2, or SD3), it may indicate that the market is stretched and could be due for a correction or a reversal toward the VWAP.

How it Works in Practice

When you load this script, it automatically identifies your chosen starting date and begins "building" the history. It calculates the total range of price movement, populates the volume histogram to show where most trading happened, and draws the VWAP and Standard Deviation lines to show where the market is currently sitting relative to its historical average.

In simple terms: This tool tells you where the most trading has happened (the Histogram), what the fair average price is (VWAP), and how far the current price has wandered away from that fair value (Standard Deviation Bands).

Miscellaneous
Implements a curve of type %1
15 Views
0 Downloads
0 Favorites
Market_Statistics_v1
//+------------------------------------------------------------------+
//|                                            Market_Statistics.mq4 |
//|                                     Copyright © 2009, Akif TOKUZ |
//|                                             akifusenet@gmail.com |
//| Volume histogram implementation is based on Vadim Shumilov       |
//| (DrShumiloff)'s VolumesHist2.3 indicator. Other concepts are     |
//| inspired from Jperl's `Trading With Market Statistics` thread on |
//| Traders Laboratory.                                              |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2009, Akif TOKUZ"
#property link      "akifusenet@gmail.com"

#property indicator_chart_window

#property indicator_buffers 8

#property indicator_color1 Red         //PVP
#property indicator_width1 2

#property indicator_color2 Aqua        //VWAP
#property indicator_width2 2

#property indicator_color3 Green       //SD1Pos
#property indicator_width3 1
#property indicator_style3 2

#property indicator_color4 Red         //SD1Neg
#property indicator_width4 1
#property indicator_style4 2

#property indicator_color5 DarkOliveGreen//SD2Pos
#property indicator_width5 1
#property indicator_style5 2

#property indicator_color6 Crimson     //SD2Neg
#property indicator_width6 1
#property indicator_style6 2

#property indicator_color7 DarkGreen   //SD2Pos
#property indicator_width7 1
#property indicator_style7 2

#property indicator_color8 FireBrick   //SD2Neg
#property indicator_width8 1
#property indicator_style8 2


//---- input parameters
extern datetime  StartDate=D'2009.08.06 00:00';
extern int    HistogramAmplitude = 100;
extern bool    Show_SD1 = true;
extern bool    Show_SD2 = false;
extern bool    Show_SD3 = false;
//---- buffers
double PVP[];
double VWAP[];
double SD1Pos[];
double SD1Neg[];
double SD2Pos[];
double SD2Neg[];
double SD3Pos[];
double SD3Neg[];

double Hist[]; // drawn specifically

datetime OpenTime = 0;  // To check if we have a new bar
string   OBJECT_PREFIX = "VolumeHistogram_";
int      items;         // numbers of items inside volume histogram
int      Bars_Back = 0; // Shows the starting bar for given date
double   SD;            // standart deviation



// Finds the bar number for the given date
int FindStartIndex(datetime startDate)
{
   for (int i=Bars-1; i>=0; i--)
   {
      if (Time[i]>=StartDate) return (i);
   }
   return( 0);
}


int init()
{
   Bars_Back=FindStartIndex(StartDate);
   ObjectSet( "Starting_Time", OBJPROP_TIME1, Time[Bars_Back]);
   ObjectSet("Starting_Time", OBJPROP_COLOR, Red);
   ObjectCreate("Starting_Time", OBJ_VLINE, 0, Time[Bars_Back], 0);

//---- indicators
   IndicatorBuffers(8);

   SetIndexStyle(0,DRAW_LINE);
   SetIndexLabel(0,"PVP");
   SetIndexBuffer(0,PVP);

   SetIndexStyle(1,DRAW_LINE);
   SetIndexLabel(1,"VWAP");
   SetIndexBuffer(1,VWAP);

   if (Show_SD1==true) SetIndexStyle(2,DRAW_LINE);
   else  SetIndexStyle(2,DRAW_NONE);
   SetIndexLabel(2,"SD1Pos");
   SetIndexBuffer(2,SD1Pos);

   if (Show_SD1==true) SetIndexStyle(3,DRAW_LINE);
   else  SetIndexStyle(3,DRAW_NONE);
   SetIndexLabel(3,"SD1Neg");
   SetIndexBuffer(3,SD1Neg);

   if (Show_SD2==true) SetIndexStyle(4,DRAW_LINE);
   else  SetIndexStyle(4,DRAW_NONE);
   SetIndexLabel(4,"SD2Pos");
   SetIndexBuffer(4,SD2Pos);

   if (Show_SD2==true) SetIndexStyle(5,DRAW_LINE);
   else  SetIndexStyle(5,DRAW_NONE);
   SetIndexLabel(5,"SD2Neg");
   SetIndexBuffer(5,SD2Neg);

   if (Show_SD3==true) SetIndexStyle(6,DRAW_LINE);
   else  SetIndexStyle(6,DRAW_NONE);
   SetIndexLabel(6,"SD3Pos");
   SetIndexBuffer(6,SD3Pos);

   if (Show_SD3==true) SetIndexStyle(7,DRAW_LINE);
   else  SetIndexStyle(7,DRAW_NONE);
   SetIndexLabel(7,"SD3Neg");
   SetIndexBuffer(7,SD3Neg);

   string short_name="Market_Statistics";
   IndicatorShortName(short_name);


   return(0);
}


// Delete all objects with given prefix
void ObDeleteObjectsByPrefix(string Prefix)
{
   int L = StringLen(Prefix);
   int i = 0;
   while(i < ObjectsTotal())
   {
       string ObjName = ObjectName(i);
       if(StringSubstr(ObjName, 0, L) != Prefix)
       {
           i++;
           continue;
       }
       ObjectDelete(ObjName);
   }
}






int start()
{
   double TotalVolume=0;
   double TotalPV=0;
   int n;

   if (OpenTime != Open[0])
   {
      Bars_Back=FindStartIndex(StartDate);
      //ObjectSet( "Starting_Time", OBJPROP_TIME1, Time[Bars_Back]);

      OpenTime = Open[0];

      double max = High[iHighest( NULL , 0, MODE_HIGH, Bars_Back, 0)];
      double min =  Low[ iLowest( NULL , 0, MODE_LOW,  Bars_Back, 0)];
      items = MathRound((max - min) / Point);

      ArrayResize(Hist, items);
      ArrayInitialize(Hist, 0);

      TotalVolume=0;
      TotalPV=0;
      for (int i = Bars_Back; i >= 1; i--)
      {
         double t1 = Low[i], t2 = Open[i], t3 = Close[i], t4 = High[i];
         if (t2 > t3) {t3 = Open[i]; t2 = Close[i];}
         double totalRange = 2*(t4 - t1) - t3 + t2;

         if (totalRange != 0.0)
         {
            for (double Price_i = t1; Price_i <= t4; Price_i += Point)
            {
               n = MathRound((Price_i - min) / Point);

               if (t1 <= Price_i && Price_i <  t2)
               {
                  Hist[n] += MathRound(Volume[i]*2*(t2-t1)/totalRange);
               }
               if (t2 <= Price_i && Price_i <= t3)
               {
                  Hist[n] += MathRound(Volume[i]*(t3-t2)/totalRange);
               }
               if (t3 <  Price_i && Price_i <= t4)
               {
                  Hist[n] += MathRound(Volume[i]*2*(t4-t3)/totalRange);
               }
            }//for
         }else
         {
            // Check if all values are equal to each other
            n = MathRound((t3 - min) / Point);
            Hist[n] += Volume[i];
         }//if


         // use H+L+C/3 as average price
         TotalPV+=Volume[i]*((Low[i]+High[i]+Close[i])/3);
         TotalVolume+=Volume[i];

         if (i==Bars_Back) PVP[i]=Close[i];
         else PVP[i]=min+ArrayMaximum(Hist)*Point;

         if (i==Bars_Back) VWAP[i]=Close[i];
         else VWAP[i]=TotalPV/TotalVolume;


         SD=0;
         for (int k = Bars_Back; k >= i; k--)
         {
            double avg=(High[k]+Close[k]+Low[k])/3;
            double diff=avg-VWAP[i];
            SD+=(Volume[k]/TotalVolume)*(diff*diff);
          }
          SD=MathSqrt(SD);
          SD1Pos[i]=VWAP[i]+SD;
          SD1Neg[i]=VWAP[i]-SD;
          SD2Pos[i]=SD1Pos[i]+SD;
          SD2Neg[i]=SD1Neg[i]-SD;
          SD3Pos[i]=SD2Pos[i]+SD;
          SD3Neg[i]=SD2Neg[i]-SD;
      }//for

      ObDeleteObjectsByPrefix(OBJECT_PREFIX);

      int MaxVolume = Hist[ArrayMaximum(Hist)];
      int multiplier;
      for (i = 0; i <= items; i++)
      {
         // Protection if we have less bar than amplitude yet
         if (Bars_Back<HistogramAmplitude) multiplier=Bars_Back;
         else multiplier=HistogramAmplitude;

         if (MaxVolume != 0) Hist[i] = MathRound(multiplier * Hist[i] / MaxVolume );

         if (Hist[i] > 0)
         {
            int time_i = Bars_Back-Hist[i];
            if (time_i>=0)
            {
               ObjectCreate(OBJECT_PREFIX+i, OBJ_RECTANGLE, 0, Time[Bars_Back], min + i*Point, Time[time_i], min + (i+1)*Point);
               ObjectSet(OBJECT_PREFIX+i, OBJPROP_STYLE, DRAW_HISTOGRAM);
               ObjectSet(OBJECT_PREFIX+i, OBJPROP_COLOR, Teal);
               ObjectSet(OBJECT_PREFIX+i, OBJPROP_BACK, true);
            }//if
         } //if
      }//for
   }//MAIN IF BAR START
   return(0);
}

int deinit()
{
   ObDeleteObjectsByPrefix(OBJECT_PREFIX);
   ObjectDelete("Starting_Time");
   return(0);
}
