Parabolic_Alert
Download scriptThis script is a specialized trading tool designed to track price movements and provide real-time alerts when the market shows signs of shifting direction. It utilizes a logic structure similar to the "Parabolic Sar" (Stop and Reverse) system, which helps traders identify potential entry points by following the trend until a specific reversal condition is met.
How the Logic Works
1. Trend Tracking and Dynamic Calculation The tool constantly monitors the high and low prices of the market. It calculates a dynamic "reference line" that moves in relation to these price points. Instead of staying static, this line adjusts based on the strength of the current trend. If the price continues to move strongly in one direction, the tool modifies its calculations (the "Step" and "Maximum" values) to tighten the tracking, ensuring it stays responsive to fast-moving markets.
2. Reversal Detection The core intelligence of this script lies in its ability to recognize when a trend is exhausting itself. It looks for specific instances where the current price crosses over the calculated reference line.
- Bullish Reversal: If the price was moving downward but then breaks above the reference line, the tool identifies a potential shift toward an upward move.
- Bearish Reversal: If the price was moving upward but then breaks below the reference line, the tool identifies a potential shift toward a downward move.
3. Smart Memory and Smoothing To ensure the alerts are accurate and not triggered by minor "noise" or random flickers in the price, the script maintains a memory of previous highs, lows, and reversal points. It uses this historical data to validate whether a price movement is significant enough to warrant an alert or if it is simply a temporary fluctuation.
4. User Notifications When the logic confirms a definitive reversal has occurred on the very latest piece of data (the current candle), the script takes action to notify the user immediately. It performs three actions simultaneously:
- Audible Alert: Plays a sound file to grab the trader's attention.
- Visual On-Screen Text: Displays a clear "Buy Alert" or "Sell Alert" directly on the trading chart.
- Timestamping: Records the exact time of the reversal for the user's reference.
Summary for the User
In simple terms, this script acts as an automated trend-watcher. It "follows" the market price and calculates a boundary line; the moment the price breaks through that boundary in the opposite direction, it triggers an alarm to let you know that the market trend may be changing, allowing for quicker reaction times than manual monitoring would provide.
//+------------------------------------------------------------------+
//| Parabolic_Alert.mq4 |
//| Original file name: Parabolic.mq4 |
//| Copyright © 2004, MetaQuotes Software Corp. |
//| http://www.metaquotes.net/ |
//| Modified to give audible alarm on reversal |
//| Modified by Jim Arner, Sr. |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2004, MetaQuotes Software Corp."
#property link "http://www.metaquotes.net/"
#property indicator_chart_window
#property indicator_buffers 1
#property indicator_color1 DarkOrange
//---- input parameters
extern double Step=0.05;
extern double Maximum=0.3;
//---- buffers
double SarBuffer[];
//----
int save_lastreverse;
bool save_dirlong, save_dirshort;
double save_start;
double save_last_high;
double save_last_low;
double save_ep;
double save_sar;
//+------------------------------------------------------------------+
//| Custom indicator initialization function |
//+------------------------------------------------------------------+
int init()
{
//---- indicators
IndicatorDigits(Digits);
SetIndexStyle(0,DRAW_ARROW);
SetIndexArrow(0,158);
SetIndexBuffer(0,SarBuffer);
//----
return(0);
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
void SaveLastReverse(int last,int dir_l,int dir_s,double start,double low,double high,double ep,double sar)
{
save_lastreverse=last;
save_dirlong=dir_l;
save_dirshort=dir_s;
save_start=start;
save_last_low=low;
save_last_high=high;
save_ep=ep;
save_sar=sar;
}
//+------------------------------------------------------------------+
//| Parabolic Sell And Reverse system |
//+------------------------------------------------------------------+
int start()
{
static bool first=true;
bool dirlong, dirshort;
double start,last_high,last_low;
double ep,sar,price_low,price_high,price;
int i,counted_bars=IndicatorCounted();
string TradeTime;
//----
if(Bars<3) return(0);
//---- initial settings
i=Bars-2;
if(counted_bars==0 || first)
{
first=false;
dirlong=true;
dirshort=false;
start=Step;
last_high=-10000000.0;
last_low=10000000.0;
while(i>0)
{
save_lastreverse=i;
price_low=Low[i];
if(last_low>price_low) last_low=price_low;
price_high=High[i];
if(last_high<price_high) last_high=price_high;
if(price_high>High[i+1] && price_low>Low[i+1]) break;
if(price_high<High[i+1] && price_low<Low[i+1]) { dirlong=false; break; }
i--;
}
//---- initial zero
int k=i;
while(k<Bars)
{
SarBuffer[k]=0.0;
k++;
}
//---- check further
if(dirlong) { SarBuffer[i]=Low[i+1]; ep=High[i]; }
if(dirshort) { SarBuffer[i]=High[i+1]; ep=Low[i]; }
i--;
}
else
{
i=save_lastreverse+1;
start=save_start;
dirlong=save_dirlong;
dirshort=save_dirshort;
last_high=save_last_high;
last_low=save_last_low;
ep=save_ep;
sar=save_sar;
}
//----
while(i>=0)
{
price_low=Low[i];
price_high=High[i];
//--- check for reverse
if(dirlong==true && price_low<SarBuffer[i+1])
{
// Print("Section 1 Code executing"," I= ",i," DirLong= ",dirlong," DirShort= ",dirshort);
SaveLastReverse(i,true,false,start,price_low,last_high,ep,sar);
start=Step; dirlong=false; dirshort=true;
// Comment("I= ",i);
if (i==0)
{
PlaySound("alert.wav");
TradeTime = TimeToStr(CurTime(),TIME_SECONDS);
Comment("\nSell Alert","\nChart Time= ", TradeTime);
}
ep=price_low; last_low=price_low;
SarBuffer[i]=last_high;
i--;
continue;
}
if(dirshort==true && price_high>SarBuffer[i+1])
{
// Print("Section 2 Code executing"," I= ",i," DirLong= ",dirlong," DirShort= ",dirshort);
SaveLastReverse(i,false,true,start,last_low,price_high,ep,sar);
start=Step; dirlong=true; dirshort=false;
// Comment("I= ",i);
if (i==0)
{
PlaySound("alert.wav");
TradeTime = TimeToStr(CurTime(),TIME_SECONDS);
Comment("\nBuy Alert","\nChart Time= ", TradeTime);
}
ep=price_high; last_high=price_high;
SarBuffer[i]=last_low;
i--;
continue;
}
//---
price=SarBuffer[i+1];
sar=price+start*(ep-price);
if(dirlong)
{
/*
Comment("DirLong","\nI= ",i,"\nDirL ",dirlong,"\nDirS ",dirshort,
"\nStart= ",start,"\nLow= ",last_low,"\nHigh= ",last_high,
"\nEP= ",ep,"\nSAR= ",sar,"\nMinute= ",Minute());
*/
// Print("Section 3 Code executing"," I= ",i," DirLong= ",dirlong," DirShort= ",dirshort);
if(ep<price_high && (start+Step)<=Maximum) start+=Step;
if(price_high<High[i+1] && i==Bars-2) sar=SarBuffer[i+1];
price=Low[i+1];
if(sar>price) sar=price;
price=Low[i+2];
if(sar>price) sar=price;
if(sar>price_low)
{
SaveLastReverse(i,true,false,start,price_low,last_high,ep,sar);
start=Step; dirlong=false; dirshort=true; ep=price_low;
last_low=price_low;
SarBuffer[i]=last_high;
i--;
/*
if (i == 0)
{
Print("Section 3a Code executing"," I= ",i," DirLong= ",dirlong," DirShort= ",dirshort);
}
*/
if (dirshort && i == 0)
{
PlaySound("alert.wav");
TradeTime = TimeToStr(CurTime(),TIME_SECONDS);
Comment("\nSell Alert","\nChart Time= ", TradeTime);
}
continue;
}
if(ep<price_high) { last_high=price_high; ep=price_high; }
}
if(dirshort)
{
/*
Comment("DirShort","\nI= ",i,"\nDirL ",dirlong,"\nDirS ",dirshort,
"\nStart= ",start,"\nLow= ",last_low,"\nHigh= ",last_high,
"\nEP= ",ep,"\nSAR= ",sar,"\nMinute= ",Minute());
*/
// Print("Section 4 Code executing"," I= ",i," DirLong= ",dirlong," DirShort= ",dirshort);
if(ep>price_low && (start+Step)<=Maximum) start+=Step;
if(price_low<Low[i+1] && i==Bars-2) sar=SarBuffer[i+1];
price=High[i+1];
if(sar<price) sar=price;
price=High[i+2];
if(sar<price) sar=price;
if(sar<price_high)
{
SaveLastReverse(i,false,true,start,last_low,price_high,ep,sar);
start=Step; dirlong=true; dirshort=false; ep=price_high;
last_high=price_high;
SarBuffer[i]=last_low;
i--;
/*
if (i == 0)
{
Print("Section 4a Code executing"," I= ",i," DirLong= ",dirlong," DirShort= ",dirshort);
}
*/
if (dirlong && i == 0)
{
PlaySound("alert.wav");
TradeTime = TimeToStr(CurTime(),TIME_SECONDS);
Comment("\nBuy Alert","\nChart Time= ", TradeTime);
}
continue;
}
if(ep>price_low) { last_low=price_low; ep=price_low; }
}
SarBuffer[i]=sar;
i--;
}
// sar=SarBuffer[0];
// price=iSAR(NULL,0,Step,Maximum,0);
// if(sar!=price) Print("custom=",sar," SAR=",price," counted=",counted_bars);
// if(sar==price) Print("custom=",sar," SAR=",price," counted=",counted_bars);
//----
return(0);
}
//+------------------------------------------------------------------+
