pinbardetector
Download script
This script is designed to automatically identify a specific candlestick pattern known as a "Pinbar" on trading charts. By scanning historical and real-time price data, it filters out market noise to highlight potential reversal signals based on precise geometric requirements.
Core Logic Overview
The tool operates by comparing two consecutive candles: the current candle (referred to as the "Nose") and the previous candle (referred to as the "Left Eye"). It looks for specific physical characteristics in these candles to determine if they form a valid Bullish or Bearish Pinbar.
1. Structural Requirements
For a pattern to be detected, the script ensures the candles meet several proportion-based rules:
- Body Size: The "body" (the实 price action area) of the Nose must be small relative to its total length. This identifies candles where the price moved significantly in one direction but "rejected" that move.
- Protrusion: The script checks how far the "wick" or "tail" of the candle extends. It looks for a significant protrusion compared to the candle's body, signifying a strong push back from a previous price level.
- Positioning: The script verifies where the body is located. For a Bearish Pinbar, the body should be near the bottom of the candle; for a Bullish Pinbar, it should be near the top.
2. Relative Comparisons (The "Left Eye" Analysis)
Unlike basic indicators that only look at one candle in isolation, this script analyzes the relationship between the current candle and the one immediately preceding it:
- Size Consistency: It compares the lengths and body sizes of both candles to ensure they are proportional to one another.
- Directional Alignment: Depending on your settings, the script can check if the previous candle moved in the opposite direction of the current move, which often helps confirm a change in market momentum.
- Depth and Placement: It measures the distance between the candles (the "Depth") to ensure there is sufficient space between the rejection point and the previous price action, confirming that the price movement is distinct rather than a continuation of a trend.
Visual Feedback and Notifications
Once the logic confirms that both candles meet all the strict geometric criteria for a Pinbar:
- Chart Marking: The script automatically places an arrow on the chart. Red arrows signify a Bearish Pinbar (potential downward move), and Lime arrows signify a Bullish Pinbar (potential upward move).
- Alert System: If enabled, the tool provides real-time notifications. You can receive audible alerts or pop-up messages on your screen the moment a new pattern is confirmed.
- Email Notifications: For traders who are away from their screens, the script can be configured to send an email alert providing the symbol name and the specific timeframe where the pattern occurred.
Customization Options
The logic is highly flexible. While it comes with "Common" and "Strict" presets, users can manually adjust the sensitivity of every rule—such as how small the body must be, how deep the "tail" must protrude, and whether the previous candle must move in a specific direction. This allows the tool to be tuned for different assets (like Forex, Stocks, or Crypto) where price volatility varies.
Miscellaneous
9
Views
0
Downloads
0
Favorites
pinbardetector
//+------------------------------------------------------------------+
//| Pinbar Detector |
//| Copyright © 2011, EarnForex.com |
//| http://www.earnforex.com/ |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2011, EarnForex"
#property link "http://www.earnforex.com"
/*
Pinbar Detector - detects Pinbars on charts.
Has two sets of predefined settings: common and strict.
Fully modifiable parameters of Pinbar pattern.
Usage instructions:
http://www.earnforex.com/forex-strategy/pinbar-trading-system
*/
#property indicator_chart_window
#property indicator_buffers 2
#property indicator_color1 Red
#property indicator_width1 2
#property indicator_color2 Lime
#property indicator_width2 2
//---
extern bool UseAlerts=true;
extern bool UseEmailAlerts=false; // Don't forget to configure SMTP parameters in Tools->Options->Emails
extern bool UseCustomSettings=false; // true = use below parameters
extern double CustomMaxNoseBodySize = 0.33; // Max. Body / Candle length ratio of the Nose Bar
extern double CustomNoseBodyPosition = 0.4; // Body position in Nose Bar (e.g. top/bottom 40%)
extern bool CustomLeftEyeOppositeDirection=true; // true = Direction of Left Eye Bar should be opposite to pattern (bearish bar for bullish Pinbar pattern and vice versa)
extern bool CustomNoseSameDirection=false; // true = Direction of Nose Bar should be the same as of pattern (bullish bar for bullish Pinbar pattern and vice versa)
extern bool CustomNoseBodyInsideLeftEyeBody=false; // true = Nose Body should be contained inside Left Eye Body
extern double CustomLeftEyeMinBodySize=0.1; // Min. Body / Candle length ratio of the Left Eye Bar
extern double CustomNoseProtruding=0.5; // Minmum protrusion of Nose Bar compared to Nose Bar length
extern double CustomNoseBodyToLeftEyeBody=1; // Maximum relative size of the Nose Bar Body to Left Eye Bar Body
extern double CustomNoseLengthToLeftEyeLength=0; // Minimum relative size of the Nose Bar Length to Left Eye Bar Length
extern double CustomLeftEyeDepth=0.1; // Minimum relative depth of the Left Eye to its length; depth is difference with Nose's back
//--- Indicator buffers
double Down[];
double Up[];
//--- Global variables
int LastBars=0;
double MaxNoseBodySize=0.33;
double NoseBodyPosition=0.4;
bool LeftEyeOppositeDirection=true;
bool NoseSameDirection=false;
bool NoseBodyInsideLeftEyeBody=false;
double LeftEyeMinBodySize=0.1;
double NoseProtruding=0.5;
double NoseBodyToLeftEyeBody=1;
double NoseLengthToLeftEyeLength=0;
double LeftEyeDepth=0.2;
//+------------------------------------------------------------------+
//| Custom indicator initialization function |
//+------------------------------------------------------------------+
int init()
{
//---- indicator buffers mapping
SetIndexBuffer(0,Down);
SetIndexBuffer(1,Up);
//---- drawing settings
SetIndexStyle(0,DRAW_ARROW);
SetIndexArrow(0,74);
SetIndexStyle(1,DRAW_ARROW);
SetIndexArrow(1,74);
//----
SetIndexEmptyValue(0,EMPTY_VALUE);
SetIndexEmptyValue(1,EMPTY_VALUE);
//---- indicator labels
SetIndexLabel(0,"Bearish Pinbar");
SetIndexLabel(1,"Bullish Pinbar");
//----
if(UseCustomSettings)
{
MaxNoseBodySize=CustomMaxNoseBodySize;
NoseBodyPosition=CustomNoseBodyPosition;
LeftEyeOppositeDirection=CustomLeftEyeOppositeDirection;
NoseSameDirection=CustomNoseSameDirection;
LeftEyeMinBodySize=CustomLeftEyeMinBodySize;
NoseProtruding=CustomNoseProtruding;
NoseBodyToLeftEyeBody=CustomNoseBodyToLeftEyeBody;
NoseLengthToLeftEyeLength=CustomNoseLengthToLeftEyeLength;
LeftEyeDepth=CustomLeftEyeDepth;
}
return(0);
}
//+------------------------------------------------------------------+
//| Custom indicator iteration function |
//+------------------------------------------------------------------+
int start()
{
int NeedBarsCounted;
double NoseLength,NoseBody,LeftEyeBody,LeftEyeLength;
//---
if(LastBars == Bars) return(0);
NeedBarsCounted=Bars-LastBars;
LastBars=Bars;
if(NeedBarsCounted==Bars) NeedBarsCounted--;
//---
for(int i=NeedBarsCounted; i>=1; i--)
{
//--- Won't have Left Eye for the left-most bar
if(i==Bars-1) continue;
//--- Left Eye and Nose bars's paramaters
NoseLength=High[i]-Low[i];
if(NoseLength == 0) NoseLength = Point;
LeftEyeLength = High[i + 1] - Low[i + 1];
if(LeftEyeLength==0) LeftEyeLength=Point;
NoseBody=MathAbs(Open[i]-Close[i]);
if(NoseBody == 0) NoseBody = Point;
LeftEyeBody = MathAbs(Open[i + 1] - Close[i + 1]);
if(LeftEyeBody==0) LeftEyeBody=Point;
//--- Bearish Pinbar
if(High[i]-High[i+1]>=NoseLength*NoseProtruding) // Nose protrusion
{
if(NoseBody/NoseLength<=MaxNoseBodySize) // Nose body to candle length ratio
{
if(1 -(High[i]-MathMax(Open[i],Close[i]))/NoseLength<NoseBodyPosition) // Nose body position in bottom part of the bar
{
if((!LeftEyeOppositeDirection) || (Close[i+1]>Open[i+1])) // Left Eye bullish if required
{
if((!NoseSameDirection) || (Close[i]<Open[i])) // Nose bearish if required
{
if(LeftEyeBody/LeftEyeLength>=LeftEyeMinBodySize) // Left eye body to candle length ratio
{
if((MathMax(Open[i],Close[i])<=High[i+1]) && (MathMin(Open[i],Close[i])>=Low[i+1])) // Nose body inside Left Eye bar
{
if(NoseBody/LeftEyeBody<=NoseBodyToLeftEyeBody) // Nose body to Left Eye body ratio
{
if(NoseLength/LeftEyeLength>=NoseLengthToLeftEyeLength) // Nose length to Left Eye length ratio
{
if(Low[i]-Low[i+1]>=LeftEyeLength*LeftEyeDepth) // Left Eye low is low enough
{
if((!NoseBodyInsideLeftEyeBody) || ((MathMax(Open[i],Close[i])<=MathMax(Open[i+1],Close[i+1])) && (MathMin(Open[i],Close[i])>=MathMin(Open[i+1],Close[i+1])))) // Nose body inside Left Eye body if required
{
Down[i]=High[i]+5*Point+NoseLength/5;
if(i==1) SendAlert("Bearish"); // Send alerts only for the latest fully formed bar
}
}
}
}
}
}
}
}
}
}
}
//--- Bullish Pinbar
if(Low[i+1]-Low[i]>=NoseLength*NoseProtruding) // Nose protrusion
{
if(NoseBody/NoseLength<=MaxNoseBodySize) // Nose body to candle length ratio
{
if(1 -(MathMin(Open[i],Close[i])-Low[i])/NoseLength<NoseBodyPosition) // Nose body position in top part of the bar
{
if((!LeftEyeOppositeDirection) || (Close[i+1]<Open[i+1])) // Left Eye bearish if required
{
if((!NoseSameDirection) || (Close[i]>Open[i])) // Nose bullish if required
{
if(LeftEyeBody/LeftEyeLength>=LeftEyeMinBodySize) // Left eye body to candle length ratio
{
if((MathMax(Open[i],Close[i])<=High[i+1]) && (MathMin(Open[i],Close[i])>=Low[i+1])) // Nose body inside Left Eye bar
{
if(NoseBody/LeftEyeBody<=NoseBodyToLeftEyeBody) // Nose body to Left Eye body ratio
{
if(NoseLength/LeftEyeLength>=NoseLengthToLeftEyeLength) // Nose length to Left Eye length ratio
{
if(High[i+1]-High[i]>=LeftEyeLength*LeftEyeDepth) // Left Eye high is high enough
{
if((!NoseBodyInsideLeftEyeBody) || ((MathMax(Open[i],Close[i])<=MathMax(Open[i+1],Close[i+1])) && (MathMin(Open[i],Close[i])>=MathMin(Open[i+1],Close[i+1])))) // Nose body inside Left Eye body if required
{
Up[i]=Low[i]-5*Point-NoseLength/5;
if(i==1) SendAlert("Bullish"); // Send alerts only for the latest fully formed bar
}
}
}
}
}
}
}
}
}
}
}
}
return(0);
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
string TimeframeToString(int P)
{
switch(P)
{
case PERIOD_M1: return("M1");
case PERIOD_M5: return("M5");
case PERIOD_M15: return("M15");
case PERIOD_M30: return("M30");
case PERIOD_H1: return("H1");
case PERIOD_H4: return("H4");
case PERIOD_D1: return("D1");
case PERIOD_W1: return("W1");
case PERIOD_MN1: return("MN1");
}
return("");
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
void SendAlert(string dir)
{
string per=TimeframeToString(Period());
if(UseAlerts)
{
Alert(dir+" Pinbar on ",Symbol()," @ ",per);
PlaySound("alert.wav");
}
if(UseEmailAlerts)
SendMail(Symbol()+" @ "+per+" - "+dir+" Pinbar",dir+" Pinbar on "+Symbol()+" @ "+per+" as of "+TimeToStr(TimeCurrent()));
}
//+------------------------------------------------------------------+
