StepChoppy_v1.3

Download script
Author: Copyright � 2006, Forex-TSD.com
StepChoppy_v1.3

The StepChoppy indicator is a specialized visual tool designed to help traders identify the current state, strength, and potential direction of a market trend. Instead of just showing a simple line, it categorizes price action into eight distinct phases, displayed as a multi-colored histogram in a separate window.

How the Logic Works

The script functions by analyzing the relationship between three primary technical components: moving averages (representing the core trend) and dual Relative Strength Index (RSI) calculations (representing momentum). By comparing these elements, the tool identifies which "stage" the market is currently in.

The logic is divided into two main categories: Upward Trends and Downward Trends. Each category is further broken down into four specific sub-stages:

1. Upward Trend Phases

When the data confirms an overall upward bias, the indicator distinguishes between the following:

  • Strong UpTrend: Indicates powerful, consistent bullish momentum.
  • Retrace UpTrend: Suggests a temporary pullback or "breather" within an ongoing bullish move.
  • Choppy UpTrend: Signals that while the trend is technically up, the price movement has become unstable or sideways.
  • Ready to Change UpTrend: A warning signal indicating that upward momentum is fading and a reversal may be imminent.

2. Downward Trend Phases

Conversely, when the data confirms an overall downward bias, the indicator tracks these stages:

  • Strong DownTrend: Indicates aggressive, consistent bearish momentum.
  • Retrace DownTrend: Suggests a temporary bounce or relief rally within a larger sell-off.
  • Choppy DownTrend: Signals that the price is moving sideways with high uncertainty despite the downward bias.
  • Ready to Change DownTrend: A warning signal indicating that downward pressure is exhausting and a move upward may be approaching.

Summary for Traders

The primary goal of this logic is to provide "context." Rather than simply telling you if the price is going up or down, it tells you how it is moving. It helps filter out "noise" by identifying when a trend is healthy, when it is struggling (choppy), and—most importantly—when the current move is losing steam and a transition to the opposite direction is likely occurring.

Miscellaneous
Implements a curve of type %1
13 Views
0 Downloads
0 Favorites
StepChoppy_v1.3
//+------------------------------------------------------------------+
//|                                              StepChoppy_v1.3.mq4 |
//|                                  Copyright © 2006, Forex-TSD.com |
//|                         Written by IgorAD,igorad2003@yahoo.co.uk |
//|            http://finance.groups.yahoo.com/group/TrendLaboratory |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2006, Forex-TSD.com "
#property link      "http://www.forex-tsd.com/"

#property indicator_separate_window
#property indicator_minimum -0.05
#property indicator_maximum 1.05
#property indicator_buffers 8

//---- input parameters
extern int     Length      = 10;
extern double  Kv          = 1.0;
extern double  StepSize    = 0;
extern int     MA_Mode     = 0;
extern bool    HighLow     = false;
extern double  StepSizeFast=5;
extern double  StepSizeSlow=15;
int MAPeriod=1;
int Price=0;
int Mode=2;
//---- buffers
double UpBuffer1[];
double UpBuffer2[];
double UpBuffer3[];
double UpBuffer4[];

double DnBuffer1[];
double DnBuffer2[];
double DnBuffer3[];
double DnBuffer4[];

//+------------------------------------------------------------------+
//| Custom indicator initialization function                         |
//+------------------------------------------------------------------+
int init()
  {

//----
   SetIndexStyle(0,DRAW_HISTOGRAM,0,3,MediumBlue);
   SetIndexStyle(1,DRAW_HISTOGRAM,0,3,DodgerBlue);
   SetIndexStyle(2,DRAW_HISTOGRAM,0,3,LightBlue);
   SetIndexStyle(3,DRAW_HISTOGRAM,0,3,Aqua);

   SetIndexStyle(4,DRAW_HISTOGRAM,0,3,Crimson);
   SetIndexStyle(5,DRAW_HISTOGRAM,0,3,Tomato);
   SetIndexStyle(6,DRAW_HISTOGRAM,0,3,Orange);
   SetIndexStyle(7,DRAW_HISTOGRAM,0,3,Yellow);

   SetIndexBuffer(0,UpBuffer1);
   SetIndexBuffer(1,UpBuffer2);
   SetIndexBuffer(2,UpBuffer3);
   SetIndexBuffer(3,UpBuffer4);

   SetIndexBuffer(4,DnBuffer1);
   SetIndexBuffer(5,DnBuffer2);
   SetIndexBuffer(6,DnBuffer3);
   SetIndexBuffer(7,DnBuffer4);

//----
   string short_name="StepChoppy";
   IndicatorShortName(short_name);
   SetIndexLabel(0,"Strong UpTrend");
   SetIndexLabel(1,"Retrace UpTrend");
   SetIndexLabel(2,"Choppy UpTrend");
   SetIndexLabel(3,"Be ready to change UpTrend");

   SetIndexLabel(4,"Strong DownTrend");
   SetIndexLabel(5,"Retrace DownTrend");
   SetIndexLabel(6,"Choppy DownTrend");
   SetIndexLabel(7,"Be ready to change DownTrend");
//----

   SetIndexDrawBegin(0,Length);
   SetIndexDrawBegin(1,Length);
   SetIndexDrawBegin(2,Length);
   SetIndexDrawBegin(3,Length);
   SetIndexDrawBegin(4,Length);
   SetIndexDrawBegin(5,Length);
   SetIndexDrawBegin(6,Length);
   SetIndexDrawBegin(7,Length);
//----
   return(0);
  }
//+------------------------------------------------------------------+
//| StepChoppy_v1.3                                                  |
//+------------------------------------------------------------------+
int start()
  {
   int  i,counted_bars=IndicatorCounted();
   double RSI, FastRSI, SlowRSI, StepMA, UpTrendMA, DnTrendMA;
//----
   if(Bars<=Length) return(0);
//---- initial zero
   if(counted_bars<1)
      for(i=1;i<=Length;i++)
      {
      UpBuffer1[Bars-i]=0.0;
      UpBuffer2[Bars-i]=0.0;
      UpBuffer3[Bars-i]=0.0;
      UpBuffer4[Bars-i]=0.0;

      DnBuffer1[Bars-i]=0.0;
      DnBuffer2[Bars-i]=0.0;
      DnBuffer3[Bars-i]=0.0;
      DnBuffer4[Bars-i]=0.0;
      }
//----
   if ( counted_bars > 0 )  int limit=Bars-counted_bars;
   if ( counted_bars ==0 )  limit=Bars-Length-1;

   for(i=limit;i>=0;i--)
   {

   UpTrendMA = iCustom(NULL,0,"StepMA_v7",Length,Kv,StepSize,MA_Mode,0,0,HighLow,2,0,1,i);
   DnTrendMA = iCustom(NULL,0,"StepMA_v7",Length,Kv,StepSize,MA_Mode,0,0,HighLow,2,0,2,i);

   RSI=iCustom(NULL,0,"StepRSI_v5.2",Length,StepSizeFast,MAPeriod,Price,Mode,0,i);
   FastRSI=iCustom(NULL,0,"StepRSI_v5.2",Length,StepSizeFast,MAPeriod,Price,Mode,1,i);
   SlowRSI=iCustom(NULL,0,"StepRSI_v5.2",Length,StepSizeSlow,MAPeriod,Price,Mode,1,i);

   UpBuffer1[i] =UpBuffer1[i+1];
   UpBuffer2[i] =UpBuffer2[i+1];
   UpBuffer3[i] =UpBuffer3[i+1];
   UpBuffer4[i] =UpBuffer4[i+1];

   DnBuffer1[i] =DnBuffer1[i+1];
   DnBuffer2[i] =DnBuffer2[i+1];
   DnBuffer3[i] =DnBuffer3[i+1];
   DnBuffer4[i] =DnBuffer4[i+1];

   if (FastRSI > SlowRSI && RSI > FastRSI && UpTrendMA!=EMPTY_VALUE)
   {UpBuffer1[i] = 1.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = 0.0;UpBuffer4[i] = 0.0;
    DnBuffer1[i] = 0.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = 0.0;DnBuffer4[i] = 0.0;}

   else if (FastRSI > SlowRSI && RSI < FastRSI && UpTrendMA!=EMPTY_VALUE)
   {UpBuffer1[i] = 0.0;UpBuffer2[i] = 1.0;UpBuffer3[i] = 0.0;UpBuffer4[i] = 0.0;
    DnBuffer1[i] = 0.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = 0.0;DnBuffer4[i] = 0.0;}

   else if (FastRSI < SlowRSI && RSI > FastRSI && UpTrendMA!=EMPTY_VALUE)
   {UpBuffer1[i] = 0.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = 1.0;UpBuffer4[i] = 0.0;
    DnBuffer1[i] = 0.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = 0.0;DnBuffer4[i] = 0.0;}

   else if (FastRSI < SlowRSI && RSI < FastRSI && UpTrendMA!=EMPTY_VALUE)
   {UpBuffer1[i] = 0.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = 0.0;UpBuffer4[i] = 1.0;
    DnBuffer1[i] = 0.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = 0.0;DnBuffer4[i] = 0.0;}


   else if (FastRSI < SlowRSI && RSI < FastRSI && DnTrendMA!=EMPTY_VALUE)
   {UpBuffer1[i] = 0.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = 0.0;UpBuffer4[i] = 0.0;
    DnBuffer1[i] = 1.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = 0.0;DnBuffer4[i] = 0.0;}

   else if (FastRSI < SlowRSI && RSI > FastRSI && DnTrendMA!=EMPTY_VALUE)
   {UpBuffer1[i] = 0.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = 0.0;UpBuffer4[i] = 0.0;
    DnBuffer1[i] = 0.0;DnBuffer2[i] = 1.0;DnBuffer3[i] = 0.0;DnBuffer4[i] = 0.0;}

   else if (FastRSI > SlowRSI && RSI < FastRSI && DnTrendMA!=EMPTY_VALUE)
   {UpBuffer1[i] = 0.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = 0.0;UpBuffer4[i] = 0.0;
    DnBuffer1[i] = 0.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = 1.0;DnBuffer4[i] = 0.0;}

   else if (FastRSI > SlowRSI && RSI > FastRSI && DnTrendMA!=EMPTY_VALUE)
   {UpBuffer1[i] = 0.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = 0.0;UpBuffer4[i] = 0.0;
    DnBuffer1[i] = 0.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = 0.0;DnBuffer4[i] = 1.0;}
   }

//----
   return(0);
  }
//+------------------------------------------------------------------+

Dependencies

StepMA_v7

This indicator calculates a quantized price trajectory by determining dynamic step sizes based on average range volatility and applying trend-dependent price boundaries.

StepRSI_v5.2

This indicator applies a staircase-style quantization to relative strength values, identifying significant structural shifts in price velocity while filtering out minor volatility noise.
