Technical Overview: Turbo JVEL Indicator Logic
This script is designed to analyze market price trends by calculating a sophisticated "slope" based on the Jurik Moving Average (JMA) logic. Unlike standard moving averages that can be sluggish or overly smooth, this tool aims to identify the direction and velocity of price movement while minimizing lag.
Data Source and Normalization
The script begins by determining the core price data to analyze. It intelligently distinguishes between different types of currency pairs:
- For specific major pairs (like USDJPY or EURJPY), it uses the Typical Price (the average of the High, Low, and Close prices).
- For all other markets, it applies a multiplier to ensure the price data is scaled correctly for the internal calculations.
The Core Calculation Engine
The logic follows a multi-stage processing pipeline to transform raw price data into a readable trend signal:
1. Adaptive Smoothing (The "Big Cycle") The script uses a complex series of loops to determine how the price is reacting relative to previous movements. It calculates the distance between current prices and past trends, using these values to adjust the sensitivity of the indicator. This allows the tool to react quickly to sudden market shifts while remaining stable during periods of slow movement.
2. Dynamic Phase and Length Adjustment The behavior of the indicator is influenced by two primary user inputs: Length (the lookback period) and Phase (the responsiveness). The script translates these into mathematical variables that dictate how much weight is given to recent price action versus older historical data.
3. Trend Slope Calculation After processing the data through the smoothing engine, the script calculates a moving average value. It then compares the current calculated value against the previous one to determine the "Slope":
- Upward Momentum: If the current value is higher than the previous value, it records a positive difference as an "UpSlope."
- Downward Momentum: If the current value is lower, it records a negative difference as a "DownSlope."
Visual Output
The final output is displayed in a separate window below the main price chart. It provides a histogram that visually represents the strength and direction of the trend:
- Green Histogram: Represents upward price momentum (positive slope).
- Red Histogram: Represents downward price momentum (negative slope).
By isolating these values into a dedicated histogram, the script allows users to see the "velocity" of the market trend independent of the price noise.
11
Views
0
Downloads
0
Favorites
Turbo_JVEL1
//+------------------------------------------------------------------+
//| Turbo_JVEL.mq4 |
//| Copyright © 2005, TrendLaboratory Ltd. |
//| Modified by bluto to use Typical Price (HLC/3) |
//| http://finance.groups.yahoo.com/group/TrendLaboratory |
//| Thanks to Weld, Jurik Research http://weld.torguem.net|
//+------------------------------------------------------------------+
#property copyright "Copyright © 2005, TrendLaboratory Ltd."
#property link "http://finance.groups.yahoo.com/group/TrendLaboratory"
#property indicator_separate_window
#property indicator_buffers 2
#property indicator_color1 Green
#property indicator_color2 Red
//---- input parameters
extern int Length = 14;
extern int Phase = 0;
//---- buffers
double UpBuffer [];
double DnBuffer [];
double JMAValueBuffer [];
double fC0Buffer [];
double fA8Buffer [];
double fC8Buffer [];
//---- temporary buffers
double list[128], ring1[128], ring2[11], buffer[62];
//---- bool flag
bool initFlag;
//---- integer vars
int limitValue, startValue, loopParam, loopCriteria;
int cycleLimit, highLimit, counterA, counterB;
//---- double vars
double cycleDelta, lowDValue, highDValue, absValue, paramA, paramB;
double phaseParam, logParam, JMAValue, series, sValue, sqrtParam, lengthDivider;
//---- temporary int variables
int s58, s60, s40, s38, s68;
//+------------------------------------------------------------------+
//| JMA initFlagization function |
//+------------------------------------------------------------------+
int init()
{
double lengthParam;
//---- 3 additional buffers are used for counting.
IndicatorBuffers(6);
//---- drawing settings
SetIndexStyle (0, DRAW_HISTOGRAM);
SetIndexStyle (1, DRAW_HISTOGRAM);
SetIndexDrawBegin(0, 30);
SetIndexDrawBegin(1, 30);
//---- 4 indicator buffers mapping
SetIndexBuffer (0, UpBuffer);
SetIndexBuffer (1, DnBuffer);
SetIndexBuffer (2, JMAValueBuffer);
SetIndexBuffer (3, fC0Buffer);
SetIndexBuffer (4, fA8Buffer);
SetIndexBuffer (5, fC8Buffer);
//---- initialize one buffer (neccessary)
ArrayInitialize (ring2, 0);
ArrayInitialize (ring1, 0);
ArrayInitialize (buffer, 0);
//---- name for DataWindow and indicator subwindow label
IndicatorShortName ("JMA Slope - Typical Price(" + Length + "," + Phase + ")");
SetIndexLabel (0, "UpSlope");
SetIndexLabel (1, "DownSlope");
//---- initial part
limitValue = 63;
startValue = 64;
//----
for (int i = 0; i <= limitValue; i++) list [i] = -1000000;
for (i = startValue; i <= 127; i++) list [i] = 1000000;
//----
initFlag = true;
if (Length < 1.0000000002) lengthParam = 0.0000000001;
else lengthParam = (Length - 1) / 2.0;
//----
if (Phase < -100) phaseParam = 0.5;
else if (Phase > 100) phaseParam = 2.5;
else phaseParam = Phase / 100.0 + 1.5;
//----
logParam = MathLog (MathSqrt (lengthParam)) / MathLog (2.0);
//----
if (logParam + 2.0 < 0) logParam = 0;
else logParam = logParam + 2.0;
//----
sqrtParam = MathSqrt(lengthParam) * logParam;
lengthParam = lengthParam * 0.9;
lengthDivider = lengthParam / (lengthParam + 2.0);
//----
return;
}
//+------------------------------------------------------------------+
//| JMA iteration function |
//+------------------------------------------------------------------+
int start()
{
//---- get already counted bars
int counted_bars = IndicatorCounted();
//---- check for possible errors
if (counted_bars < 0) return (-1);
int limit = Bars - counted_bars - 1;
//---- main cycle
for (int shift = limit; shift >= 0; shift--) {
if ((Symbol()=="USDJPYm") || (Symbol()=="EURJPYm") || (Symbol()=="GBPJPYm" || Symbol()=="USDJPY") || (Symbol()=="EURJPY") || (Symbol()=="GBPJPY"))
{
series = ((High[shift]+Low[shift]+Close[shift])/3);
} else {
series = ((High[shift]*100 + Low[shift]*100 + Close[shift]*100)/3);
}
if (loopParam < 61) {
loopParam++;
buffer [loopParam] = series;
}
if (loopParam > 30) {
if (initFlag) {
initFlag = false;
int diffFlag = 0;
for (int i = 1; i <= 29; i++) {
if (buffer [i + 1] != buffer [i]) diffFlag = 1;
}
highLimit = diffFlag * 30;
if (highLimit == 0) paramB = series;
else paramB = buffer[1];
paramA = paramB;
if (highLimit > 29) highLimit = 29;
} else
highLimit = 0;
//---- big cycle
for (i = highLimit; i >= 0; i--) {
if (i == 0) sValue = series; else sValue = buffer [31 - i];
if (MathAbs (sValue - paramA) > MathAbs (sValue - paramB)) absValue = MathAbs(sValue - paramA); else absValue = MathAbs(sValue - paramB);
double dValue = absValue + 0.0000000001; //1.0e-10;
if (counterA <= 1) counterA = 127; else counterA--;
if (counterB <= 1) counterB = 10; else counterB--;
if (cycleLimit < 128) cycleLimit++;
cycleDelta += (dValue - ring2 [counterB]);
ring2 [counterB] = dValue;
if (cycleLimit > 10) highDValue = cycleDelta / 10.0; else highDValue = cycleDelta / cycleLimit;
if (cycleLimit > 127) {
dValue = ring1 [counterA];
ring1 [counterA] = highDValue;
s68 = 64; s58 = s68;
while (s68 > 1) {
if (list [s58] < dValue) {
s68 = s68 / 2.0;
s58 += s68;
} else
if (list [s58] <= dValue) {
s68 = 1;
} else {
s68 = s68 / 2.0;
s58 -= s68;
}
}
} else {
ring1 [counterA] = highDValue;
if ((limitValue + startValue) > 127) {
startValue--;
s58 = startValue;
} else {
limitValue++;
s58 = limitValue;
}
if (limitValue > 96) s38 = 96; else s38 = limitValue;
if (startValue < 32) s40 = 32; else s40 = startValue;
}
//----
s68 = 64;
s60 = s68;
while (s68 > 1) {
if (list [s60] >= highDValue) {
if (list [s60 - 1] <= highDValue) {
s68 = 1;
}
else {
s68 = s68 / 2.0;
s60 -= s68;
}
}
else {
s68 = s68 / 2.0;
s60 += s68;
}
if ((s60 == 127) && (highDValue > list[127])) s60 = 128;
}
if (cycleLimit > 127) {
if (s58 >= s60) {
if (((s38 + 1) > s60) && ((s40 - 1) < s60))
lowDValue += highDValue;
else if ((s40 > s60) && ((s40 - 1) < s58))
lowDValue += list [s40 - 1];
}
else if (s40 >= s60) {
if (((s38 + 1) < s60) && ((s38 + 1) > s58))
lowDValue += list[s38 + 1];
}
else if ((s38 + 2) > s60)
lowDValue += highDValue;
else if (((s38 + 1) < s60) && ((s38 + 1) > s58))
lowDValue += list[s38 + 1];
if (s58 > s60) {
if (((s40 - 1) < s58) && ((s38 + 1) > s58))
lowDValue -= list [s58];
else if ((s38 < s58) && ((s38 + 1) > s60))
lowDValue -= list [s38];
}
else {
if (((s38 + 1) > s58) && ((s40 - 1) < s58))
lowDValue -= list [s58];
else if ((s40 > s58) && (s40 < s60))
lowDValue -= list [s40];
}
}
if (s58 <= s60) {
if (s58 >= s60) list[s60] = highDValue; else {
for (int j = s58 + 1; j <= (s60 - 1); j++) {
list [j - 1] = list[j];
}
list [s60 - 1] = highDValue;
}
} else {
for (j = s58 - 1; j >= s60; j--) {
list [j + 1] = list [j];
}
list [s60] = highDValue;
}
if (cycleLimit <= 127) {
lowDValue = 0;
for (j = s40; j <= s38; j++) {
lowDValue += list[j];
}
}
//----
if ((loopCriteria + 1) > 31) loopCriteria = 31; else loopCriteria++;
double JMATempValue, sqrtDivider = sqrtParam / (sqrtParam + 1.0);
if (loopCriteria <= 30) {
if (sValue - paramA > 0) paramA = sValue; else paramA = sValue - (sValue - paramA) * sqrtDivider;
if (sValue - paramB < 0) paramB = sValue; else paramB = sValue - (sValue - paramB) * sqrtDivider;
JMATempValue = series;
if (loopCriteria == 30) {
fC0Buffer [shift] = series;
int intPart;
if (MathCeil(sqrtParam) >= 1) intPart = MathCeil(sqrtParam); else intPart = 1;
int leftInt = IntPortion (intPart);
if (MathFloor(sqrtParam) >= 1) intPart = MathFloor(sqrtParam); else intPart = 1;
int rightPart = IntPortion (intPart);
if (leftInt == rightPart) dValue = 1.0;
else
dValue = (sqrtParam - rightPart) / (leftInt - rightPart);
if (rightPart <= 29) int upShift = rightPart; else upShift = 29;
if (leftInt <= 29) int dnShift = leftInt; else dnShift = 29;
fA8Buffer [shift] = (series - buffer [loopParam - upShift]) * (1 - dValue) / rightPart + (series - buffer[loopParam - dnShift]) * dValue / leftInt;
}
} else {
double powerValue, squareValue;
dValue = lowDValue / (s38 - s40 + 1);
if (0.5 <= logParam - 2.0) powerValue = logParam - 2.0;
else powerValue = 0.5;
if (logParam >= MathPow(absValue/dValue, powerValue)) dValue = MathPow (absValue/dValue, powerValue); else dValue = logParam;
if (dValue < 1) dValue = 1;
powerValue = MathPow (sqrtDivider, MathSqrt (dValue));
if (sValue - paramA > 0) paramA = sValue; else paramA = sValue - (sValue - paramA) * powerValue;
if (sValue - paramB < 0) paramB = sValue; else paramB = sValue - (sValue - paramB) * powerValue;
}
}
// ---- end of big cycle
if (loopCriteria > 30) {
JMATempValue = JMAValueBuffer [shift + 1];
powerValue = MathPow (lengthDivider, dValue);
squareValue = MathPow (powerValue, 2);
fC0Buffer [shift] = (1 - powerValue) * series + powerValue * fC0Buffer [shift + 1];
fC8Buffer [shift] = (series - fC0Buffer [shift]) * (1 - lengthDivider) + lengthDivider * fC8Buffer [shift + 1];
fA8Buffer [shift] = (phaseParam * fC8Buffer [shift] + fC0Buffer [shift] - JMATempValue) *
(powerValue * (-2.0) + squareValue + 1) + squareValue * fA8Buffer [shift + 1];
JMATempValue += fA8Buffer [shift];
}
JMAValue = JMATempValue;
}
if (loopParam <= 30) JMAValue = 0;
JMAValueBuffer [shift] = JMAValue;
double rel=JMAValueBuffer [shift]-JMAValueBuffer [shift+1];
if(rel>=0)
{
UpBuffer[shift]=rel;
DnBuffer[shift]=0;
}
else
{
DnBuffer[shift]=rel;
UpBuffer[shift]=0;
}
//---- End of main cycle
}
return;
}
//+------------------------------------------------------------------+
int IntPortion (double param) {
if (param > 0) return (MathFloor (param));
if (param < 0) return (MathCeil (param));
return (0.0);
}
//+------------------------------------------------------------------+
