Yearly_Pivots

Overview

This script is designed to automatically identify and display "Yearly Pivot Points" on your trading charts. Pivot points are significant price levels used by traders to determine potential support (floors) and resistance (ceilings). By calculating these based on annual data, the tool helps you visualize the major price boundaries for the current year.

How It Works

The script operates through a systematic process of gathering historical data and performing mathematical calculations to project future price levels:

1. Data Gathering The script automatically scans the previous year's monthly data. It looks specifically for three key pieces of information from that past period:

  • The highest price reached (High)
  • The lowest price reached (Low)
  • The closing price at the end of December (Close)

2. Core Pivot Calculations Once it has gathered the High, Low, and Close prices from the previous year, it uses standard financial formulas to calculate several key levels:

  • The Pivot Point (P): The central equilibrium price for the year, calculated as the average of the High, Low, and Close.
  • Resistance Levels (R1, R2, R3): These represent prices above the Pivot Point where the market may face selling pressure.
  • Support Levels (S1, S2, S3): These represent prices below the Pivot Point where the market may find buying interest.

3. Mid-Point Calculations For traders who require more granular detail, the script also calculates "Mid-Pivots." These are the halfway points between the main levels (e.g., the midpoint between the central Pivot and Resistance 1). These serve as secondary zones where price action might slow down or reverse.

Visual Features

To make this data easy to read on your chart, the script handles all the visual heavy lifting:

  • Automatic Drawing: It draws horizontal lines across your chart for every calculated level (P, R1-R3, S1-S3, and Mid-Pivots).
  • Color Coding: Resistance levels are typically highlighted in red tones, while Support levels are shown in blue tones, allowing for instant visual identification of market "danger" or "opportunity" zones.
  • Dynamic Labeling: The script places text labels next to each line, displaying the exact price value so you don't have to guess the coordinates manually.
  • Clean Up: The script includes a "housekeeping" feature that ensures old lines are deleted when the tool is removed or refreshed, keeping your chart clean and uncluttered.

Summary of Benefits

Instead of manually calculating complex annual averages, this tool provides an instant visual map of the year's most important price levels. It allows you to see where big "walls" (Resistance) and "floors" (Support) are located, helping you make more informed decisions on where to place your trades.

Price Data Components
Series array that contains open time of each barSeries array that contains the highest prices of each barSeries array that contains the lowest prices of each barSeries array that contains close prices for each bar
10 Views
0 Downloads
0 Favorites
Yearly_Pivots
//+------------------------------------------------------------------+
//|                                                Yearly_Pivots.mq4 |
//|                                          Copyright © 2008,  Siro |
//+------------------------------------------------------------------+

#property indicator_chart_window


extern int LineWidth=2;
extern int MidLineWidth=0;
extern string Style="LineStyle should be 0-5";
extern int LineStyle=0;
extern int MidLineStyle=3;
extern color P_color=Navy;
extern color S_color=Blue;
extern color MS_color=Blue;
extern color R_color=Red;
extern color MR_color=Red;
extern bool ShowMidPivots=true;





double P,R1,R2,R3,S1,S2,S3;
double MR1,MR2,MR3,MS1,MS2,MS3;
int actualyear;
double high=-999999,low=999999,close;
//+------------------------------------------------------------------+
//| Custom indicator initialization function                         |
//+------------------------------------------------------------------+
int init()
  {
//---- indicators
//----
   if(ObjectFind("Yearly_Pivot_P")!=-1)
      ObjectDelete("Yearly_Pivot_P");
   if(ObjectFind("Yearly_Pivot_R1")!=-1)
      ObjectDelete("Yearly_Pivot_R1");
   if(ObjectFind("Yearly_Pivot_R2")!=-1)
      ObjectDelete("Yearly_Pivot_R2");
   if(ObjectFind("Yearly_Pivot_R3")!=-1)
      ObjectDelete("Yearly_Pivot_R3");
   if(ObjectFind("Yearly_Pivot_S1")!=-1)
      ObjectDelete("Yearly_Pivot_S1");
   if(ObjectFind("Yearly_Pivot_S2")!=-1)
      ObjectDelete("Yearly_Pivot_S2");
   if(ObjectFind("Yearly_Pivot_S3")!=-1)
      ObjectDelete("Yearly_Pivot_S3");
   if(ObjectFind("Yearly_Pivot_LABEL_P")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_P");
   if(ObjectFind("Yearly_Pivot_LABEL_R1")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_R1");
   if(ObjectFind("Yearly_Pivot_LABEL_R2")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_R2");
   if(ObjectFind("Yearly_Pivot_LABEL_R3")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_R3");
   if(ObjectFind("Yearly_Pivot_LABEL_S1")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_S1");
   if(ObjectFind("Yearly_Pivot_LABEL_S2")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_S2");
   if(ObjectFind("Yearly_Pivot_LABEL_S3")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_S3");

   if(ObjectFind("Yearly_Pivot_MR1")!=-1)
      ObjectDelete("Yearly_Pivot_MR1");
   if(ObjectFind("Yearly_Pivot_MR2")!=-1)
      ObjectDelete("Yearly_Pivot_MR2");
   if(ObjectFind("Yearly_Pivot_MR3")!=-1)
      ObjectDelete("Yearly_Pivot_MR3");
   if(ObjectFind("Yearly_Pivot_MS1")!=-1)
      ObjectDelete("Yearly_Pivot_MS1");
   if(ObjectFind("Yearly_Pivot_MS2")!=-1)
      ObjectDelete("Yearly_Pivot_MS2");
   if(ObjectFind("Yearly_Pivot_MS3")!=-1)
      ObjectDelete("Yearly_Pivot_MS3");
   if(ObjectFind("Yearly_Pivot_LABEL_MR1")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_MR1");
   if(ObjectFind("Yearly_Pivot_LABEL_MR2")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_MR2");
   if(ObjectFind("Yearly_Pivot_LABEL_MR3")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_MR3");
   if(ObjectFind("Yearly_Pivot_LABEL_MS1")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_MS1");
   if(ObjectFind("Yearly_Pivot_LABEL_MS2")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_MS2");
   if(ObjectFind("Yearly_Pivot_LABEL_MS3")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_MS3");
   IndicatorShortName("Yearly Pivots");

   return(0);
  }
//+------------------------------------------------------------------+
//| Custom indicator deinitialization function                       |
//+------------------------------------------------------------------+
int deinit()
  {
//----
      if(ObjectFind("Yearly_Pivot_P")!=-1)
      ObjectDelete("Yearly_Pivot_P");
   if(ObjectFind("Yearly_Pivot_R1")!=-1)
      ObjectDelete("Yearly_Pivot_R1");
   if(ObjectFind("Yearly_Pivot_R2")!=-1)
      ObjectDelete("Yearly_Pivot_R2");
   if(ObjectFind("Yearly_Pivot_R3")!=-1)
      ObjectDelete("Yearly_Pivot_R3");
   if(ObjectFind("Yearly_Pivot_S1")!=-1)
      ObjectDelete("Yearly_Pivot_S1");
   if(ObjectFind("Yearly_Pivot_S2")!=-1)
      ObjectDelete("Yearly_Pivot_S2");
   if(ObjectFind("Yearly_Pivot_S3")!=-1)
      ObjectDelete("Yearly_Pivot_S3");
   if(ObjectFind("Yearly_Pivot_LABEL_P")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_P");
   if(ObjectFind("Yearly_Pivot_LABEL_R1")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_R1");
   if(ObjectFind("Yearly_Pivot_LABEL_R2")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_R2");
   if(ObjectFind("Yearly_Pivot_LABEL_R3")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_R3");
   if(ObjectFind("Yearly_Pivot_LABEL_S1")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_S1");
   if(ObjectFind("Yearly_Pivot_LABEL_S2")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_S2");
   if(ObjectFind("Yearly_Pivot_LABEL_S3")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_S3");

   if(ObjectFind("Yearly_Pivot_MR1")!=-1)
      ObjectDelete("Yearly_Pivot_MR1");
   if(ObjectFind("Yearly_Pivot_MR2")!=-1)
      ObjectDelete("Yearly_Pivot_MR2");
   if(ObjectFind("Yearly_Pivot_MR3")!=-1)
      ObjectDelete("Yearly_Pivot_MR3");
   if(ObjectFind("Yearly_Pivot_MS1")!=-1)
      ObjectDelete("Yearly_Pivot_MS1");
   if(ObjectFind("Yearly_Pivot_MS2")!=-1)
      ObjectDelete("Yearly_Pivot_MS2");
   if(ObjectFind("Yearly_Pivot_MS3")!=-1)
      ObjectDelete("Yearly_Pivot_MS3");
   if(ObjectFind("Yearly_Pivot_LABEL_MR1")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_MR1");
   if(ObjectFind("Yearly_Pivot_LABEL_MR2")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_MR2");
   if(ObjectFind("Yearly_Pivot_LABEL_MR3")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_MR3");
   if(ObjectFind("Yearly_Pivot_LABEL_MS1")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_MS1");
   if(ObjectFind("Yearly_Pivot_LABEL_MS2")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_MS2");
   if(ObjectFind("Yearly_Pivot_LABEL_MS3")!=-1)
      ObjectDelete("Yearly_Pivot_LABEL_MS3");
//----
   return(0);
  }
//+------------------------------------------------------------------+
//| Custom indicator iteration function                              |
//+------------------------------------------------------------------+
int start()
  {
   int    pos=0;
   int    counted_bars=IndicatorCounted();
   actualyear=TimeYear(iTime(NULL,PERIOD_MN1,0));
   if(counted_bars < 0)
        return(-1);
//---- last counted bar will be recounted
    if(counted_bars > 0)
        counted_bars--;
    pos = 0;

    while(actualyear-TimeYear(iTime(NULL, PERIOD_MN1, pos))<=1)
    {
      if(actualyear-TimeYear(iTime(NULL, PERIOD_MN1, pos))==1)
      {
         if(iHigh(NULL,PERIOD_MN1,pos)>high)
            high=iHigh(NULL,PERIOD_MN1,pos);
         if(iLow(NULL,PERIOD_MN1,pos)<low)
            low=iLow(NULL,PERIOD_MN1,pos);
         if(TimeMonth(iTime(NULL, PERIOD_MN1, pos))==12)
            close=iClose(NULL,PERIOD_MN1,pos);
      }





      pos++;
    }

    P=(high+low+close)/3;
    R1 = (2*P)-low;
    S1 = (2*P)-high;
    R2 = P + (R1-S1);
    S2 = P - (R1-S1);
    R3 = high+2*(P-low);
    S3 = low-2*(high-P);

    MR1=(P+R1)/2;
    MR2=(R1+R2)/2;
    MR3=(R2+R3)/2;
    MS1=(P+S1)/2;
    MS2=(S1+S2)/2;
    MS3=(S2+S3)/2;

    //**************************PIVOTS!!!********************************
    ObjectCreate("Yearly_Pivot_P", OBJ_HLINE, 0, 0, P);
    ObjectSet("Yearly_Pivot_P", OBJPROP_COLOR, P_color);
    ObjectSet("Yearly_Pivot_P", OBJPROP_STYLE, LineStyle);
    ObjectSet("Yearly_Pivot_P", OBJPROP_WIDTH, LineWidth);

    ObjectCreate("Yearly_Pivot_R1", OBJ_HLINE, 0, 0, R1);
    ObjectSet("Yearly_Pivot_R1", OBJPROP_COLOR, R_color);
    ObjectSet("Yearly_Pivot_R1", OBJPROP_STYLE, LineStyle);
    ObjectSet("Yearly_Pivot_R1", OBJPROP_WIDTH, LineWidth);

    ObjectCreate("Yearly_Pivot_R2", OBJ_HLINE, 0, 0, R2);
    ObjectSet("Yearly_Pivot_R2", OBJPROP_COLOR, R_color);
    ObjectSet("Yearly_Pivot_R2", OBJPROP_STYLE, LineStyle);
    ObjectSet("Yearly_Pivot_R2", OBJPROP_WIDTH, LineWidth);

    ObjectCreate("Yearly_Pivot_R3", OBJ_HLINE, 0, 0, R3);
    ObjectSet("Yearly_Pivot_R3", OBJPROP_COLOR, R_color);
    ObjectSet("Yearly_Pivot_R3", OBJPROP_STYLE, LineStyle);
    ObjectSet("Yearly_Pivot_R3", OBJPROP_WIDTH, LineWidth);

    ObjectCreate("Yearly_Pivot_S1", OBJ_HLINE, 0, 0, S1);
    ObjectSet("Yearly_Pivot_S1", OBJPROP_COLOR, S_color);
    ObjectSet("Yearly_Pivot_S1", OBJPROP_STYLE, LineStyle);
    ObjectSet("Yearly_Pivot_S1", OBJPROP_WIDTH, LineWidth);

    ObjectCreate("Yearly_Pivot_S2", OBJ_HLINE, 0, 0, S2);
    ObjectSet("Yearly_Pivot_S2", OBJPROP_COLOR, S_color);
    ObjectSet("Yearly_Pivot_S2", OBJPROP_STYLE, LineStyle);
    ObjectSet("Yearly_Pivot_S2", OBJPROP_WIDTH, LineWidth);

    ObjectCreate("Yearly_Pivot_S3", OBJ_HLINE, 0, 0, S3);
    ObjectSet("Yearly_Pivot_S3", OBJPROP_COLOR, S_color);
    ObjectSet("Yearly_Pivot_S3", OBJPROP_STYLE, LineStyle);
    ObjectSet("Yearly_Pivot_S3", OBJPROP_WIDTH, LineWidth);

    ObjectCreate("Yearly_Pivot_LABEL_P", OBJ_TEXT, 0, Time[0], P);
    ObjectSet("Yearly_Pivot_LABEL_P", OBJPROP_COLOR, P_color);
    ObjectSetText("Yearly_Pivot_LABEL_P", "Pivot:"+DoubleToStr(P,Digits));

    ObjectCreate("Yearly_Pivot_LABEL_R1", OBJ_TEXT, 0, Time[0], R1);
    ObjectSet("Yearly_Pivot_LABEL_R1", OBJPROP_COLOR, R_color);
    ObjectSetText("Yearly_Pivot_LABEL_R1", "R1:"+DoubleToStr(R1,Digits));

    ObjectCreate("Yearly_Pivot_LABEL_R2", OBJ_TEXT, 0, Time[0], R2);
    ObjectSet("Yearly_Pivot_LABEL_R2", OBJPROP_COLOR, R_color);
    ObjectSetText("Yearly_Pivot_LABEL_R2", "R2:"+DoubleToStr(R2,Digits));

    ObjectCreate("Yearly_Pivot_LABEL_R3", OBJ_TEXT, 0, Time[0], R3);
    ObjectSet("Yearly_Pivot_LABEL_R3", OBJPROP_COLOR, R_color);
    ObjectSetText("Yearly_Pivot_LABEL_R3", "R3:"+DoubleToStr(R3,Digits));

    ObjectCreate("Yearly_Pivot_LABEL_S1", OBJ_TEXT, 0, Time[0], S1);
    ObjectSet("Yearly_Pivot_LABEL_S1", OBJPROP_COLOR, S_color);
    ObjectSetText("Yearly_Pivot_LABEL_S1", "S1:"+DoubleToStr(S1,Digits));

    ObjectCreate("Yearly_Pivot_LABEL_S2", OBJ_TEXT, 0, Time[0], S2);
    ObjectSet("Yearly_Pivot_LABEL_S2", OBJPROP_COLOR, S_color);
    ObjectSetText("Yearly_Pivot_LABEL_S2", "S2:"+DoubleToStr(S2,Digits));

    ObjectCreate("Yearly_Pivot_LABEL_S3", OBJ_TEXT, 0, Time[0], S3);
    ObjectSet("Yearly_Pivot_LABEL_S3", OBJPROP_COLOR, S_color);
    ObjectSetText("Yearly_Pivot_LABEL_S3", "S3:"+DoubleToStr(S3,Digits));
    //***********************************************************************

    //****************************Midpivots*************************************
    if(ShowMidPivots==true)
    {
       ObjectCreate("Yearly_Pivot_MR1", OBJ_HLINE, 0, 0, MR1);
       ObjectSet("Yearly_Pivot_MR1", OBJPROP_COLOR, MR_color);
       ObjectSet("Yearly_Pivot_MR1", OBJPROP_STYLE, MidLineStyle);
       ObjectSet("Yearly_Pivot_MR1", OBJPROP_WIDTH, MidLineWidth);
       ObjectCreate("Yearly_Pivot_MR2", OBJ_HLINE, 0, 0, MR2);
       ObjectSet("Yearly_Pivot_MR2", OBJPROP_COLOR, MR_color);
       ObjectSet("Yearly_Pivot_MR2", OBJPROP_STYLE, MidLineStyle);
       ObjectSet("Yearly_Pivot_MR2", OBJPROP_WIDTH, MidLineWidth);
       ObjectCreate("Yearly_Pivot_MR3", OBJ_HLINE, 0, 0, MR3);
       ObjectSet("Yearly_Pivot_MR3", OBJPROP_COLOR, MR_color);
       ObjectSet("Yearly_Pivot_MR3", OBJPROP_STYLE, MidLineStyle);
       ObjectSet("Yearly_Pivot_MR3", OBJPROP_WIDTH, MidLineWidth);
       ObjectCreate("Yearly_Pivot_MS1", OBJ_HLINE, 0, 0, MS1);
       ObjectSet("Yearly_Pivot_MS1", OBJPROP_COLOR, MS_color);
       ObjectSet("Yearly_Pivot_MS1", OBJPROP_STYLE, MidLineStyle);
       ObjectSet("Yearly_Pivot_MS1", OBJPROP_WIDTH, MidLineWidth);
       ObjectCreate("Yearly_Pivot_MS2", OBJ_HLINE, 0, 0, MS2);
       ObjectSet("Yearly_Pivot_MS2", OBJPROP_COLOR, MS_color);
       ObjectSet("Yearly_Pivot_MS2", OBJPROP_STYLE, MidLineStyle);
       ObjectSet("Yearly_Pivot_MS2", OBJPROP_WIDTH, MidLineWidth);
       ObjectCreate("Yearly_Pivot_MS3", OBJ_HLINE, 0, 0, MS3);
       ObjectSet("Yearly_Pivot_MS3", OBJPROP_COLOR, MS_color);
       ObjectSet("Yearly_Pivot_MS3", OBJPROP_STYLE, MidLineStyle);
       ObjectSet("Yearly_Pivot_MS3", OBJPROP_WIDTH, MidLineWidth);

       ObjectCreate("Yearly_Pivot_LABEL_MR1", OBJ_TEXT, 0, Time[0], MR1);
       ObjectSet("Yearly_Pivot_LABEL_MR1", OBJPROP_COLOR, MR_color);
       ObjectSetText("Yearly_Pivot_LABEL_MR1", "MR1:"+DoubleToStr(MR1,Digits));
       ObjectCreate("Yearly_Pivot_LABEL_MR2", OBJ_TEXT, 0, Time[0], MR2);
       ObjectSet("Yearly_Pivot_LABEL_MR2", OBJPROP_COLOR, MR_color);
       ObjectSetText("Yearly_Pivot_LABEL_MR2", "MR2:"+DoubleToStr(MR2,Digits));
       ObjectCreate("Yearly_Pivot_LABEL_MR3", OBJ_TEXT, 0, Time[0], MR3);
       ObjectSet("Yearly_Pivot_LABEL_MR3", OBJPROP_COLOR, MR_color);
       ObjectSetText("Yearly_Pivot_LABEL_MR3", "MR3:"+DoubleToStr(MR3,Digits));
       ObjectCreate("Yearly_Pivot_LABEL_MS1", OBJ_TEXT, 0, Time[0], MS1);
       ObjectSet("Yearly_Pivot_LABEL_MS1", OBJPROP_COLOR, MS_color);
       ObjectSetText("Yearly_Pivot_LABEL_MS1", "MS1:"+DoubleToStr(MS1,Digits));
       ObjectCreate("Yearly_Pivot_LABEL_MS2", OBJ_TEXT, 0, Time[0], MS2);
       ObjectSet("Yearly_Pivot_LABEL_MS2", OBJPROP_COLOR, MS_color);
       ObjectSetText("Yearly_Pivot_LABEL_MS2", "MS2:"+DoubleToStr(MS2,Digits));
       ObjectCreate("Yearly_Pivot_LABEL_MS3", OBJ_TEXT, 0, Time[0], MS3);
       ObjectSet("Yearly_Pivot_LABEL_MS3", OBJPROP_COLOR, MS_color);
       ObjectSetText("Yearly_Pivot_LABEL_MS3", "MS3:"+DoubleToStr(MS3,Digits));

    }
    //**************************************************************************
//----

//----
   return(0);
  }
//+------------------------------------------------------------------+

Similar scripts

Get trend

background_trixcandle_htf

dynamicrs_c_v1

Asymmetric bands

RiskReward Ratio v0.1

This tool calculates and visualizes the mathematical relationship between entry price, stop-loss distance, and take-profit targets in real-time.

ClusterFilter_ch_price

iFMA

ExpM_BykovTrend

^Dyn_AllLevels

This indicator calculates and plots daily pivot points and support/resistance levels based on the previous day's high, low, and closing prices using two customizable weighting formulas.

TrendEMA - Display Trend And MA Values

This indicator evaluates the relative sequential alignment of three distinct Exponential Moving Averages to dynamically categorize market behavior into upward, downward, or neutral trends.

NormalizedVolume

Comments
