2MA Crossover2-mtf

Download script
Author: Copyright � 2005-07, Jason Robinson (jnrtrading)
2MA Crossover2-mtf

This script is designed as a visual trading tool for MetaTrader 4 that identifies specific "crossover" moments between two different moving averages. Instead of just drawing the average lines on your chart, this tool focuses on detecting the exact point where one line passes through another, marking these events with visual icons and sending notifications to the user.

Core Functionality

The primary logic revolves around monitoring two distinct moving averages (MA1 and MA2). You can customize these settings to choose different calculation types—such as Simple (SMA), Exponential (EMA), Smoothed (SMMA), or Linear Weighted (LWMA)—and set their specific time periods.

How the Logic Works

The script constantly scans the price data to determine if a crossover has occurred by looking at three consecutive points in time:

  1. Previous State: It checks where the two lines were one step back.
  2. Current State: It checks where the lines are right now.
  3. Future/Immediate Context: It verifies the trend immediately following the cross to ensure the movement is significant.

When the script detects that the first moving average has moved from below to above the second (a "Cross Up"), or from above to below (a "Cross Down"), it triggers two actions:

  • Visual Markers: It places a specific arrow or icon on the chart at the crossover point. The position of these icons is automatically adjusted based on the volatility of the market (using price range calculations) to ensure they remain clearly visible and do not overlap with the candlesticks.
  • Alert System: If enabled, the script will trigger a pop-up alert or send an email notification at the moment the crossover happens. To prevent your screen from being flooded with messages, it is programmed to only send one alert per new price bar.

Key Features for Users

  • Visual Customization: You can choose from various arrow styles (such as thin, thick, hollow, or specific shapes like "thumbs up" or "fingers") to suit your visual preferences.
  • Dynamic Timeframes: The script automatically detects which timeframe you are viewing (e.g., 1-minute, Hourly, Daily) and includes this information in the alert messages so you know exactly which chart triggered the signal.
  • Signal Clarity: By focusing on the crossover points rather than just drawing lines, the tool helps traders identify trend shifts more quickly, especially when looking at very short timeframes where moving average lines might become cluttered or difficult to read.
Indicators Used
Moving average indicator
Miscellaneous
Implements a curve of type %1It issuies visual alerts to the screenIt sends emails
11 Views
0 Downloads
0 Favorites
2MA Crossover2-mtf
//+------------------------------------------------------------------+
//|                                  2MA Crossover.mq4 modified from |
//|                                         EMA-Crossover_Signal.mq4 |
//|         Copyright © 2005-07, Jason Robinson (jnrtrading)         |
//|                   http://www.jnrtading.co.uk                     |
//+------------------------------------------------------------------+

/*
  +------------------------------------------------------------------+
  | Allows you to enter two ema periods and it will then show you at |
  | Which point they crossed over. It is more usful on the shorter   |
  | periods that get obscured by the bars / candlesticks and when    |
  | the zoom level is out. Also allows you then to remove the emas   |
  | from the chart. (emas are initially set at 5 and 6)              |
  +------------------------------------------------------------------+
*/
#property copyright "Copyright © 2005-07, Jason Robinson (jnrtrading)"
#property link      "http://www.jnrtrading.co.uk"

#property indicator_chart_window
#property indicator_buffers 2
#property indicator_color1 Green//DodgerBlue
#property indicator_width1 2
#property indicator_color2 Maroon//Magenta
#property indicator_width2 2

extern string note1 = "First Moving Average";
extern int MA1 =   2;//4;
extern string note2 = "0=sma, 1=ema, 2=smma, 3=lwma";
extern int MA1Mode = 3; //0=sma, 1=ema, 2=smma, 3=lwma
extern string note3 = "--------------------------------------------";
extern string note4 = "Second Moving Average";
extern int MA2 =   5;//8;
extern string note5 = "0=sma, 1=ema, 2=smma, 3=lwma";
extern int MA2Mode = 3; //0=sma, 1=ema, 2=smma, 3=lwma
extern string note6 = "--------------------------------------------";
extern string note7 = "Arrow Type";
extern string note8 = "0=Thick, 1=Thin, 2=Hollow, 3=Round";
extern string note9 = "4=Fractal, 5=Diagonal Thin";
extern string note10 = "6=Diagonal Thick, 7=Diagonal Hollow";
extern string note11 = "8=Thumb, 9=Finger";
extern int ArrowType=1;//2;
extern string note12 = "--------------------------------------------";
extern string note13 = "turn on Alert = true; turn off = false";
extern bool AlertOn = true;
extern string note14 = "--------------------------------------------";
extern string note15 = "send Email Alert = true; turn off = false";
extern bool SendAnEmail=false;

double CrossUp[];
double CrossDown[];
string AlertPrefix, MA1short_name, MA2short_name;
string GetTimeFrameStr() {
   switch(Period())
   {
      case 1 : string TimeFrameStr="M1"; break;
      case 5 : TimeFrameStr="M5"; break;
      case 15 : TimeFrameStr="M15"; break;
      case 30 : TimeFrameStr="M30"; break;
      case 60 : TimeFrameStr="H1"; break;
      case 240 : TimeFrameStr="H4"; break;
      case 1440 : TimeFrameStr="D1"; break;
      case 10080 : TimeFrameStr="W1"; break;
      case 43200 : TimeFrameStr="MN1"; break;
      default : TimeFrameStr=Period();
   }
   return (TimeFrameStr);
   }

//+------------------------------------------------------------------+
//| Custom indicator initialization function                         |
//+------------------------------------------------------------------+
int init()
  {
//---- indicators
   if (ArrowType == 0) {
      SetIndexStyle(0,DRAW_ARROW);
      SetIndexArrow(0, 233);
      SetIndexStyle(1,DRAW_ARROW);
      SetIndexArrow(1, 234);
   }
   else if (ArrowType == 1) {
      SetIndexStyle(0,DRAW_ARROW);
      SetIndexArrow(0, 233);//225);
      SetIndexStyle(1,DRAW_ARROW);
      SetIndexArrow(1, 234);//226);
   }
   else if (ArrowType == 2) {
      SetIndexStyle(0,DRAW_ARROW);
      SetIndexArrow(0, 241);
      SetIndexStyle(1,DRAW_ARROW);
      SetIndexArrow(1, 242);
   }
   else if (ArrowType == 3) {
      SetIndexStyle(0,DRAW_ARROW);
      SetIndexArrow(0, 221);
      SetIndexStyle(1,DRAW_ARROW);
      SetIndexArrow(1, 222);
   }
   else if (ArrowType == 4) {
      SetIndexStyle(0,DRAW_ARROW);
      SetIndexArrow(0, 217);
      SetIndexStyle(1,DRAW_ARROW);
      SetIndexArrow(1, 218);
   }
   else if (ArrowType == 5) {
      SetIndexStyle(0,DRAW_ARROW);
      SetIndexArrow(0, 228);
      SetIndexStyle(1,DRAW_ARROW);
      SetIndexArrow(1, 230);
   }
   else if (ArrowType == 6) {
      SetIndexStyle(0,DRAW_ARROW);
      SetIndexArrow(0, 236);
      SetIndexStyle(1,DRAW_ARROW);
      SetIndexArrow(1, 238);
   }
   else if (ArrowType == 7) {
      SetIndexStyle(0,DRAW_ARROW);
      SetIndexArrow(0, 246);
      SetIndexStyle(1,DRAW_ARROW);
      SetIndexArrow(1, 248);
   }
   else if (ArrowType == 8) {
      SetIndexStyle(0,DRAW_ARROW);
      SetIndexArrow(0, 67);
      SetIndexStyle(1,DRAW_ARROW);
      SetIndexArrow(1, 68);
   }
   else if (ArrowType == 9) {
      SetIndexStyle(0,DRAW_ARROW);
      SetIndexArrow(0, 71);
      SetIndexStyle(1,DRAW_ARROW);
      SetIndexArrow(1, 72);
   }

   SetIndexBuffer(0, CrossUp);
   SetIndexBuffer(1, CrossDown);

//---- indicator short name
   switch(MA1Mode)
     {
      case 1 : MA1short_name="EMA";  break;
      case 2 : MA1short_name="SMMA"; break;
      case 3 : MA1short_name="LWMA"; break;
      default :
         MA1Mode=0;
         MA1short_name="SMA";
     }
   switch(MA2Mode)
     {
      case 1 : MA2short_name="EMA";  break;
      case 2 : MA2short_name="SMMA"; break;
      case 3 : MA2short_name="LWMA"; break;
      default :
         MA2Mode=0;
         MA2short_name="SMA";
     }

   AlertPrefix=Symbol()+" ("+GetTimeFrameStr()+"):  ";
//----
   return(0);
  }
//+------------------------------------------------------------------+
//| Custom indicator deinitialization function                       |
//+------------------------------------------------------------------+
int deinit()
  {
//----

//----
   return(0);
  }
//+------------------------------------------------------------------+
bool NewBar()
{
   static datetime lastbar;
   datetime curbar = Time[0];
   if(lastbar!=curbar)
   {
      lastbar=curbar;
      return (true);
   }
   else
   {
      return(false);
   }
}
//+------------------------------------------------------------------+
//| Custom indicator iteration function                              |
//+------------------------------------------------------------------+
int start() {
   int limit, i, counter;
   double MA1now, MA2now, MA1previous, MA2previous, MA1after, MA2after;
   double Range, AvgRange;
   int counted_bars=IndicatorCounted();
//---- check for possible errors
   if(counted_bars<0) return(-1);
//---- last counted bar will be recounted
   if(counted_bars>0) counted_bars--;

   limit=Bars-counted_bars;

   for(i = 0; i <= limit; i++) {

      counter=i;
      Range=0;
      AvgRange=0;
      for (counter=i ;counter<=i+9;counter++)
      {
         AvgRange=AvgRange+MathAbs(High[counter]-Low[counter]);
      }
      Range=AvgRange/33;//10

      MA1now = iMA(NULL, 0, MA1, 0, MA1Mode, PRICE_CLOSE, i);
      MA1previous = iMA(NULL, 0, MA1, 0, MA1Mode, PRICE_CLOSE, i+1);
      MA1after = iMA(NULL, 0, MA1, 0, MA1Mode, PRICE_CLOSE, i-1);

      MA2now = iMA(NULL, 0, MA2, 0, MA2Mode, PRICE_CLOSE, i);
      MA2previous = iMA(NULL, 0, MA2, 0, MA2Mode, PRICE_CLOSE, i+1);
      MA2after = iMA(NULL, 0, MA2, 0, MA2Mode, PRICE_CLOSE, i-1);

      if ((MA1now > MA2now) && (MA1previous < MA2previous) && (MA1after > MA2after)) {
                   CrossUp[i] = Low[i] - Range*1.5;
                   if (AlertOn && NewBar()) {
                      Alert(AlertPrefix+MA1short_name+" ("+MA1+") "+"crosses UP " + MA2short_name+" ("+MA2+")");
                   }
              	    if (SendAnEmail && NewBar()) {
                      SendMail(AlertPrefix,MA1short_name+" ("+MA1+") "+"crosses UP " + MA2short_name+" ("+MA2+")");
              	    }
      }
      else if ((MA1now < MA2now) && (MA1previous > MA2previous) && (MA1after < MA2after)) {
                   CrossDown[i] = High[i] + Range*1.5;
                   if (AlertOn && NewBar()) {
                      Alert(AlertPrefix+MA1short_name+" ("+MA1+") "+"crosses DOWN " + MA2short_name+" ("+MA2+")");
                   }
              	    if (SendAnEmail && NewBar()) {
                      SendMail(AlertPrefix,MA1short_name+" ("+MA1+") "+"crosses DOWN " + MA2short_name+" ("+MA2+")");
              	    }
      }
   }
   return(0);
}
