DFC Next_v2

Technical Logic Overview

This script is designed as a specialized visual indicator for the MetaTrader 4 platform. Its primary purpose is to identify and project dynamic price channels based on specific historical price extremes and mathematical ratios. Rather than simply drawing static lines, it calculates "high" and "low" boundaries that adapt to the market's structural behavior.

The core logic can be broken down into the following key components:

1. Timeframe Awareness and Period Detection

The script is intelligent regarding timeframes. It contains a built-in logic system that recognizes specific chart periods (such as 15 minutes, 1 hour, or Daily) and identifies their corresponding "parent" intervals. This allows the tool to stay consistent with higher-level market structures.

2. Boundary Identification (Delimiters)

A significant part of the logic revolves around identifying "Delimiters." These are specific points in time where a new structural period begins (for example, the start of a new day, week, or a specific 4-hour block). The script scans the history to find these transition points, ensuring that the price channels are anchored to significant market sessions rather than moving randomly.

3. Price Extreme Calculation

Once a delimiter is identified, the script looks back over a user-defined number of periods (the "Channel Period"). It calculates:

  • The Highest High: The peak price reached within that timeframe.
  • The Lowest Low: The bottom price reached within that timeframe.
  • The Pivot Value: A weighted average calculation involving the high, the low, and the closing price of the period.

4. Fibonacci-Based Channel Projection

Using the highest and lowest points found above, the script calculates a dynamic range. It applies a specific "Ratio" (defaulting to 0.786) to project two distinct boundaries:

  • Upper Boundary (MaH): The top limit of the projected channel.
  • Lower Boundary (MaL): The bottom limit of the projected channel.

These boundaries provide a visual "corridor" that helps traders understand the potential range of price action based on previous volatility.

5. Dynamic Projection and Smoothing

The script offers two modes for how these channels are displayed:

  • Sectional Mode: By default, the lines appear as distinct sections linked to specific time delimiters.
  • Continuous Mode (SetAllBars): If enabled, the script uses linear interpolation logic. It calculates the "slope" between the start and end of a period and draws a continuous, moving line that connects the boundaries smoothly across the chart.

6. Real-Time Execution

The script constantly updates the current price action (the "Null Bar"). As each new candle forms, it re-calculates the current extremes and adjusts the projected channel immediately, ensuring that the visual data remains relevant to live market movements.

Miscellaneous
Implements a curve of type %1
15 Views
0 Downloads
0 Favorites
DFC Next_v2
/*-----------------------------+
|			       |
| Shared by www.Aptrafx.com    |
|			       |
+------------------------------*/

//+------------------------------------------------------------------------------------+
//|                                                Din_fibo_Next.mq4                   |
//|                                 unknown author, get from kaizer, conversed by Rosh |
//| link to kaizer: http://forum.alpari-idc.ru/profile.php?mode=viewprofile&u=4196161  |
//|                                              http://forexsystems.ru/phpBB/index.php|
//+------------------------------------------------------------------------------------+
#property copyright "unknown author, get from kaizer, conversed by Rosh"
#property link      "http://forexsystems.ru/phpBB/index.php"

#property indicator_chart_window
#property indicator_buffers 2
#property indicator_color1 Red
#property indicator_color2 Red
//---- input parameters
extern int       Fibo_Channel_Period=3;
extern double    Ratio=0.786;
extern bool      SetAllBars=false;
//---- buffers
double ExtMapBuffer1[];
double ExtMapBuffer2[];
double tvBuffer[];
int hh,ll,first,counterPeriod;
double tv,MaH,MaL;
//+------------------------------------------------------------------+
//| Ïîëó÷èì ñëåäóþùèé ïåðèîä                                         |
//+------------------------------------------------------------------+
string GetNextPeriod(int _Period)
  {
  string nextPeriod="";
//----
  switch (_Period)
   {
   case 5: nextPeriod="H1"; break;
   case 15: nextPeriod="H1"; break;
   case 30: nextPeriod="H4"; break;
   case 60: nextPeriod="H4"; break;
   case 240: nextPeriod="D1"; break;
   case 1440: nextPeriod="W1"; break;
   case 10080: nextPeriod="M"; break;
   default: Print("Íåäîïóñòèìûé ïåðèîä!!!");
   }
//----
   return(nextPeriod);
  }
//+------------------------------------------------------------------+
//| Ïðîâåðèì - ðàçäåëèòåëü äèàïàçîíà èëè íåò                         |
//+------------------------------------------------------------------+
bool isDelimeter(int _Period, int _shift)
  {
  bool result=false;
//----
  switch (_Period)
   {
   case 5:result=(TimeMinute(Time[_shift])==0); break;
   case 15:result=(TimeMinute(Time[_shift])==0); break;
   case 30:result=(TimeMinute(Time[_shift])==0)&& MathMod(TimeHour(Time[_shift]),4.0)==0.0; break;
   case 60:result=(TimeMinute(Time[_shift])==0)&& MathMod(TimeHour(Time[_shift]),4.0)==0.0;break;
   case 240:result=(TimeMinute(Time[_shift])==0)&&(TimeHour(Time[_shift])==0); break;
   case 1440:result=(TimeDayOfWeek(Time[_shift])==1)&&(TimeHour(Time[_shift])==0); break;
   case 10080:result=(TimeDay(Time[_shift])==1)||((TimeDay(Time[_shift])==2 && TimeDay(Time[_shift+1])!=1))||((TimeDay(Time[_shift])==3 && TimeDay(Time[_shift+1])!=2)); break;
   default: Print("Íåäîïóñòèìûé ïåðèîä!!!");
   }
//----
   return(result);
  }

//+------------------------------------------------------------------+
//| Óñòàíîâèì MaH è MaL íà ãðàíèöå äèàïàçîíà                         |
//+------------------------------------------------------------------+
void SetHnL(int _shift)
  {
//----
   int i=_shift+1;
   counterPeriod=0;
   first=0;
   while (counterPeriod<Fibo_Channel_Period)
      {
      while (tvBuffer[i]==0.0 && i<Bars) i++;
      if (first==0) first=i;
      counterPeriod++;
      i++;
      }
   i--;
   hh=Highest(NULL,0,MODE_HIGH,i-_shift,_shift+1);
   ll=Lowest(NULL,0,MODE_LOW,i-_shift,_shift+1);
   tv=NormalizeDouble((High[hh]+Low[ll]+Close[_shift+1])/3.0,Digits);
   MaH=tv+NormalizeDouble((High[hh]-Low[ll])/2.0*Ratio,Digits);
   MaL=tv-NormalizeDouble((High[hh]-Low[ll])/2.0*Ratio,Digits);
   tvBuffer[_shift]=tv;
   ExtMapBuffer1[_shift]=MaH;
   ExtMapBuffer2[_shift]=MaL;
   if (SetAllBars) SetMovingHnL(first, _shift);

//----
   return;
  }
//+------------------------------------------------------------------+
//| Óñòàíîâèì MaH è MaL âíóòðè äèàïàçîíà                             |
//+------------------------------------------------------------------+
void SetMovingHnL(int _DelimeterBar,int CurBar)
  {
   int m_cnt;
   double deltaH,deltaL;
//----
   deltaH=(ExtMapBuffer1[_DelimeterBar]-ExtMapBuffer1[CurBar])/(_DelimeterBar-CurBar);
   deltaL=(ExtMapBuffer2[_DelimeterBar]-ExtMapBuffer2[CurBar])/(_DelimeterBar-CurBar);
   for (m_cnt=_DelimeterBar-1;m_cnt>CurBar;m_cnt--)
      {
      ExtMapBuffer1[m_cnt]=ExtMapBuffer1[m_cnt+1]-deltaH;
      ExtMapBuffer2[m_cnt]=ExtMapBuffer2[m_cnt+1]-deltaL;
      }
   for (m_cnt=_DelimeterBar-1;m_cnt>CurBar;m_cnt--)
      {
      ExtMapBuffer1[m_cnt]=NormalizeDouble(ExtMapBuffer1[m_cnt],Digits);
      ExtMapBuffer2[m_cnt]=NormalizeDouble(ExtMapBuffer2[m_cnt],Digits);
      }
//----
   return;
  }
//+------------------------------------------------------------------+
//| Óñòàíîâèì MaH è MaL íà ïðàâîì êðàþ                               |
//+------------------------------------------------------------------+
void SetValuesNullBar(int _shift)
  {
//----
   int i=_shift;
   while (tvBuffer[i]==0.0) i++;
   for (int j=i-1;j>_shift;j--)
      {
      ExtMapBuffer1[j]=0.0;
      ExtMapBuffer2[j]=0.0;
      }
   first=0;
   i=_shift;
   counterPeriod=0;
   while (counterPeriod<Fibo_Channel_Period)
      {
      while (tvBuffer[i]==0.0 && i<Bars) i++;
      if (first==0) first=i;
      counterPeriod++;
      i++;
      }
   i--;
   hh=Highest(NULL,0,MODE_HIGH,i-_shift,_shift);
   ll=Lowest(NULL,0,MODE_LOW,i-_shift,_shift);
   tv=NormalizeDouble((High[hh]+Low[ll]+Close[_shift])/3.0,Digits);
   MaH=tv+NormalizeDouble((High[hh]-Low[ll])/2.0*Ratio,Digits);
   MaL=tv-NormalizeDouble((High[hh]-Low[ll])/2.0*Ratio,Digits);
   ExtMapBuffer1[_shift]=MaH;
   ExtMapBuffer2[_shift]=MaL;
   if (SetAllBars) SetMovingHnL(first,_shift);
//----
   return;
  }//-------------------------------------------------------------------+
//| Custom indicator initialization function                         |
//+------------------------------------------------------------------+
int init()
  {
//---- indicators
   IndicatorBuffers(3);
   string label;
   if (SetAllBars)
      {
      SetIndexStyle(0,DRAW_LINE);
      SetIndexBuffer(0,ExtMapBuffer1);
      label="DFC Next "+GetNextPeriod(Period())+"("+Fibo_Channel_Period+") MaH";
      SetIndexLabel(0,label);
      SetIndexEmptyValue(0,0.0);

      SetIndexStyle(1,DRAW_LINE);
      SetIndexBuffer(1,ExtMapBuffer2);
      label="DFC Next "+GetNextPeriod(Period())+"("+Fibo_Channel_Period+") MaL";
      SetIndexLabel(1,label);
      SetIndexEmptyValue(1,0.0);
      }
   else
      {
   SetIndexStyle(0,DRAW_SECTION);
   SetIndexBuffer(0,ExtMapBuffer1);
   label="DFC Next "+GetNextPeriod(Period())+"("+Fibo_Channel_Period+") MaH";
   SetIndexLabel(0,label);
   SetIndexEmptyValue(0,0.0);

   SetIndexStyle(1,DRAW_SECTION);
   SetIndexBuffer(1,ExtMapBuffer2);
   label="DFC Next "+GetNextPeriod(Period())+"("+Fibo_Channel_Period+") MaL";
   SetIndexLabel(1,label);
   SetIndexEmptyValue(1,0.0);
      }

   SetIndexBuffer(2,tvBuffer);
   SetIndexEmptyValue(2,0.0);

//----
   return(0);
  }
//+------------------------------------------------------------------+
//| Custor indicator deinitialization function                       |
//+------------------------------------------------------------------+
int deinit()
  {
//----

//----
   return(0);
  }
//+------------------------------------------------------------------+
//| Custom indicator iteration function                              |
//+------------------------------------------------------------------+
int start()
  {
   int    counted_bars=IndicatorCounted();
   int cnt,limit;

//----
   if (Period()==10080) return;
   if (counted_bars<0) return(-1);
   if (counted_bars>0) limit=Bars-counted_bars;
   if (counted_bars==0)
      {
      // íàéòè ïåðâûé è âòîðîé ðàçäåëèòåëü è óñòàíîâèòü limit
      cnt=Bars-1;
      while (!isDelimeter(Period(),cnt)) cnt--;
      first=cnt;
      cnt--;
      counterPeriod=0;
      while (counterPeriod<Fibo_Channel_Period)
         {
         while (!isDelimeter(Period(),cnt)) cnt--;
         cnt--;
         counterPeriod++;
         }
      cnt++;
      hh=Highest(NULL,0,MODE_HIGH,first-cnt,cnt+1);
      ll=Lowest(NULL,0,MODE_LOW,first-cnt,cnt+1);
      tv=NormalizeDouble((High[hh]+Low[ll]+Close[cnt+1])/3.0,Digits);
      MaH=tv+NormalizeDouble((High[hh]-Low[ll])/2.0*Ratio,Digits);
      MaL=tv-NormalizeDouble((High[hh]-Low[ll])/2.0*Ratio,Digits);
      tvBuffer[cnt]=tv;
      ExtMapBuffer1[cnt]=MaH;
      ExtMapBuffer2[cnt]=MaL;
      limit=cnt-1;
      }
//----
   for (int shift=limit;shift>=0;shift--)
      {
      if (isDelimeter(Period(),shift)) SetHnL(shift);// else SetMovingHnL(shift);
      if (shift==0) SetValuesNullBar(shift);
      }

   return(0);
  }
//+------------------------------------------------------------------+
