MLP_cannonball3

This script demonstrates a fundamental application of Artificial Intelligence known as a Multi-Layer Perceptron (MLP). In plain terms, it builds and trains a basic "neural network" to solve a physics problem: predicting the landing position of a cannonball.

The Objective

The goal of this logic is to teach the computer to predict two specific coordinates—the horizontal distance ($x$) and the vertical height ($y$)—of a bullet at a specific point in time. To do this, the system is given two pieces of information (inputs): the initial speed of the bullet and the angle at which it was fired.

How the Logic Works

The script follows a structured "learning" process similar to how a student might study for an exam:

1. Data Preparation (The Study Material) Before learning begins, the script generates a large dataset. It calculates thousands of examples of where a bullet should land based on various speeds and angles using standard physics formulas. It splits this data into two groups:

  • Training Set: Used to teach the network.
  • Testing Set: Used to see if the network actually learned or just memorized the answers.

2. The Neural Network Structure (The Brain) The script builds a simple brain structure consisting of:

  • Inputs: The speed and angle.
  • Hidden Layer: An intermediate processing area where the data is weighed and transformed.
  • Outputs: The predicted $x$ and $y$ coordinates.

Every connection in this "brain" has a weight. At the start, these weights are completely random, meaning the initial guesses of the computer will be incorrect.

3. The Learning Loop (The Training) This is the core of the script. It performs a repetitive cycle of three steps:

  • Forward Pass: The program takes an input (speed and angle), passes it through the network's weights, and produces a guess.
  • Error Calculation: The program compares its guess against the known correct answer from the physics formulas to see how far off it was. This difference is called the "Mean Squared Error."
  • Backward Pass (Back-propagation): This is where the learning happens. The script looks at the error and works backward through the network, slightly adjusting the weights of the connections to reduce the mistake for next time. It uses a "learning rate" to ensure the adjustments aren't too drastic.

4. Evaluation The script repeats this training loop hundreds of times. After each round, it pauses to check its progress on the "Testing Set"—data it hasn't used for learning yet. If the error (MSE) drops below a certain threshold, the program considers itself "trained."

Final Output

Once finished, the script provides a summary of its performance, showing how many iterations it took to learn and how accurate the final results were on both the training data and the hidden test data.

Miscellaneous
Uses files from the file systemIt writes information to file
1 Views
1 Downloads
0 Favorites
MLP_cannonball3
//+------------------------------------------------------------------+
//|                                               MLP_cannonball.mq4 |
//|                      Copyright © 2008, MetaQuotes Software Corp. |
//|                                        http://www.metaquotes.net |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2008, MetaQuotes Software Corp."
#property link      "http://www.metaquotes.net"
/* This program implements a simple Multi Layer Perceptron to solve the canonball problem (regression)
   Adapted by Sebastien Marcel (2003-2004) from D. Collobert
   The goal is to estimate the position X of a bullet at time t (fixed) given the initial speed (v) and angle (a)

   y

  / \
   |
   |
   |
   |               . X
   |            .
   |          .
   |        .
   |      .
   |     .
   |    .
   |   .
   |  .
   | .
   |.   (v,a)
   --------------------------> x

*/

#define PI 3.14159265358979323846
#define RAND_MAX 32767.0

//
// Datasets
#define N_PATTERNS_TRAIN 500
#define N_PATTERNS_TEST 500
#define N_PATTERNS_TRAIN_TEST 1000 //N_PATTERNS_TRAIN + N_PATTERNS_TEST

//  w1[N_HU1][IN1]=>w1[4][3]
//     H  In
//     |  |
//  w1[0][0] w1[0][1] w1[0][2]
//  w1[1][0] w1[1][1] w1[1][2]
//  w1[2][0] w1[2][1] w1[2][2]
//  w1[3][0] w1[3][1] w1[3][2]
//  forward train:
//  aHidden[0] = xBias;
//  aHidden[1] = xBias*w1[1][0] + (In0)*w1[1][1] + (In1)*w1[1][2];
//  aHidden[2] = xBias*w1[2][0] + (In0)*w1[2][1] + (In1)*w1[2][2];
//  aHidden[3] = xBias*w1[3][0] + (In0)*w1[3][1] + (In1)*w1[3][2];
//  yHidden[0] = xBias;
//  yHidden[1] = f(aHidden[1]);
//  yHidden[2] = f(aHidden[2]);
//  yHidden[3] = f(aHidden[3]);
//
//  w2[OUT][N_HU1]=>w2[2][4]
//
//  w2[0][0] w2[0][1] w2[0][2] w2[0][3]
//  w2[1][0] w2[1][1] w2[1][2] w2[1][3]
//     |  |
//    Out H
// forward train:
//	aOutput[0] = 0.0;
//	aOutput[1] = 0.0;
//	aOutput[0] = aOutput[0] + yHidden[0]*w2[0][0];
//	aOutput[1] = aOutput[1] + yHidden[0]*w2[1][0];
//	aOutput[0] = aOutput[0] + yHidden[1]*w2[0][1];
//	aOutput[1] = aOutput[1] + yHidden[1]*w2[1][1];
//	aOutput[0] = aOutput[0] + yHidden[2]*w2[0][2];
//	aOutput[1] = aOutput[1] + yHidden[2]*w2[1][2];
//	aOutput[0] = aOutput[0] + yHidden[3]*w2[0][3];
//	aOutput[1] = aOutput[1] + yHidden[3]*w2[1][3];
//

//	out0 = f(aOutput[0]);
//	out1 = f(aOutput[1]);

#define IN 2
#define IN1 3 //IN+1
#define OUT 2
#define N_HU 3
#define N_HU1 4 //N_HU + 1
//*****************************
// Inputs
//
	double DataIn0[N_PATTERNS_TRAIN_TEST]; // speed of bullet
	double DataIn1[N_PATTERNS_TRAIN_TEST]; // angle of bullet
// X[N_PATTERNS_TRAIN + N_PATTERNS_TEST];
//*****************************
// Targets
//
	double DataOut0[N_PATTERNS_TRAIN_TEST]; // x position at time t
	double DataOut1[N_PATTERNS_TRAIN_TEST]; // y position at time t
// Y[N_PATTERNS_TRAIN + N_PATTERNS_TEST];

//*****************************
// to create the data
//
double vmax;
double gravity;

//*****************************
// to train the MLP
//
double lambda =  0.01;     // learning rate
double mu = 0.6;           // inertia momentum rate
double mse_min = 0.001;    // minimum Mean Squared Error
int max_iterations = 500; // maximum number of iterations

//*****************************
// MLP data


// weights between hidden neurons and inputs
double w1[N_HU1][IN1];
double w1old[N_HU1][IN1];

// weights between outputs and hidden neurons
double w2[OUT][N_HU1];
double w2old[OUT][N_HU1];

// values of integration function
double aHidden[N_HU1];
double aOutput[OUT];

// values of transfert function
double yHidden[N_HU1];

// constant value of bias
double xBias = 1.0;


int init()
{
  vmax = 1.0/10;
  gravity = 1.0/200;

  return(0);
}
//+------------------------------------------------------------------+
//| script program start function                                    |
//+------------------------------------------------------------------+
int start()
  {
//----
   initrand();
   main();
//----
   return(0);
  }
//+------------------------------------------------------------------+

//*****************************
// Sigmoid transfer function
//
double f(double x)
{
	return (1.0 /(1.0 + MathExp(-x)));
}

//*****************************
// Derivative of Sigmoid
//
double f_prime(double x)
{
   double z = MathExp(-x);
	double one_plus_z = 1.0 + z;

	return (z / (one_plus_z * one_plus_z));
}



//*****************************
// Compute the x position of bullet at time t
//
double xpos(double t, double v, double teta)
{
	return( v * t * MathCos(teta*PI/180.0));
}

//*****************************
// Compute the y position of bullet at time t
//
double ypos(double t, double v, double teta)
{
	return( -0.5 * gravity * t * t + v * t * MathSin(teta*PI/180.0));
}

//*****************************
// Compute the MSE
//
double MSE(
            double a0,
            double a1,
            double b0,
            double b1
          )
{
	return (0.5*((a0 - b0)*(a0 - b0) + (a1 - b1)*(a1 - b1)));
}

//*****************************
// Create the MLP
//
void createMLP()
{
	int i, j;
	// weights between hidden neurons and inputs
	for (i = 0; i<IN1; i++)
	{
		for (j = 0; j< N_HU1; j++)
		{
			w1[j][i] = Random(-1.0, 1.0);
			w1old[j][i] = w1[j][i];
		}
	}
   // weights between outputs and hidden neurons
	for (i = 0; i<OUT; i++)
	{
		for (j = 0; j< N_HU1; j++)
		{
			w2[i][j] = Random(-1.0, 1.0);
			w2old[i][j] = w2[i][j];
		}
	}
}

//*****************************
// Create the datasets
//
void createDatasets()
{
	int i;

	i = 0;
	while (i < (N_PATTERNS_TRAIN + N_PATTERNS_TEST))
	{
		DataIn0[i] = (Random(0.0, vmax)) / vmax;
		DataIn1[i] = (Random(0.0, 90.0)) / 90.0;

		DataOut0[i] = xpos(10, DataIn0[i] * vmax, (DataIn1[i])*90.0);
		DataOut1[i] = ypos(10, DataIn0[i] * vmax, (DataIn1[i])*90.0);

		if (DataOut1[i] > 0.0) i = i + 1;
   }
}

//*****************************
// Forward the input in the MLP
//
void forward(
             double In0,
             double In1,
             double &out0,
             double &out1
             )
{
	int i;

	aHidden[0] = xBias;
	yHidden[0] = xBias;

	for (i = 1; i <= N_HU; i++)
	{
		aHidden[i] = xBias*w1[i][0] + (In0)*w1[i][1] + (In1)*w1[i][2];
		yHidden[i] = f(aHidden[i]);
	}

	aOutput[0] = 0.0;
	aOutput[1] = 0.0;

	for (i = 0; i <= N_HU; i++)
	{
		aOutput[0] = aOutput[0] + yHidden[i]*w2[0][i];
		aOutput[1] = aOutput[1] + yHidden[i]*w2[1][i];
	}

	out0 = f(aOutput[0]);
	out1 = f(aOutput[1]);
}

//*****************************
// Backward (back-propagate the gradient of error)
//
void backward(
               double Yestimate0,
               double Yestimate1,
               double Outwant0,
               double Outwant1,
               double In0,
               double In1,
               double lambda,
               double mu
               )
{
	double wnew, Goutput[OUT], Ghidden[N_HU1];
	int i,j;

	//
	Goutput[0] = (Yestimate0 - Outwant0) * f_prime(aOutput[0]);
	Goutput[1] = (Yestimate1 - Outwant1) * f_prime(aOutput[1]);

	//
	for (i = 0; i<=N_HU; i++)
		Ghidden[i] = (Goutput[0]*w2[0][i] + Goutput[1]*w2[1][i])*f_prime(aHidden[i]);

	//
	for (j = 0; j<OUT;j++)
	{
		for (i = 0; i<=N_HU; i++)
		{
			wnew = w2[j][i] - lambda * yHidden[i] * Goutput[j] + mu * (w2[j][i] - w2old[j][i]);
			w2old[j][i] = w2[j][i];
			w2[j][i] = wnew;
		}
	}

	//
	for (i = 0; i<=N_HU; i++)
	{
		wnew = w1[i][0] - lambda * xBias * Ghidden[i] + mu * (w1[i][0] - w1old[i][0]);
		w1old[i][0] = w1[i][0];
		w1[i][0] = wnew;

		wnew = w1[i][1] - lambda * In0 * Ghidden[i] + mu * (w1[i][1] - w1old[i][1]);
		w1old[i][1] = w1[i][1];
		w1[i][1] = wnew;

		wnew = w1[i][2] - lambda * In1 * Ghidden[i] + mu * (w1[i][2] - w1old[i][2]);
		w1old[i][2] = w1[i][2];
		w1[i][2] = wnew;
	}
}

//*****************************
// Stochastic gradient training
//
double train(int P)
{
   double Yestimate0;
   double Yestimate1;
	double mse_;
	double mse_total;

	mse_total = 0.0;

	// For each train patterns
	for(int p = 0 ; p < P ; p++)
	{
		// Forward current train pattern into the MLP
		forward(
		          //X[p],
               DataIn0[p],
               DataIn1[p],
		          //&Yestimate
               Yestimate0,
               Yestimate1
		        );

		// Computes the MSE
		mse_ = MSE(
		             //Y[p],
            DataOut0[p],
            DataOut1[p],
		             //Yestimate
            Yestimate0,
            Yestimate1
		          );

		// Accumulate the MSE
		mse_total = mse_total + mse_;

		// Backward MSE gradient
		backward(
		          //Yestimate,
                Yestimate0,
                Yestimate1,
		          //Y[p],
                DataOut0[p], //Outwant
                DataOut1[p], //Outwant
		          //X[p],
                DataIn0[p],
                DataIn1[p],
		          lambda,
		          mu
		          );
	}

	// Return normalized train MSE
	double P1=P;
	return (mse_total /P1);
}


//
int main()
{
	double mse_train;
	double mse_test;
   double mse_;
   double Yestimate0;
   double Yestimate1;
	//*****************************
	createMLP();
	//*****************************
	createDatasets();
	//*****************************
	//for (int i = 0; i< N_PATTERNS_TRAIN; i++) printf(" TRN: x=[%f %f] y=[%f %f]\n", X[i].v, X[i].a, Y[i].x, Y[i].y);
	//for (int i = N_PATTERNS_TRAIN; i<(N_PATTERNS_TRAIN + N_PATTERNS_TEST); i++) printf(" TST: x=[%f %f] y=[%f %f]\n", X[i].v, X[i].a, Y[i].x, Y[i].y);
	Print("Stochastic gradient training:");
	//
	int pf_train = FileOpen("mse_train_mt4.txt",FILE_CSV|FILE_WRITE,' ');//FileOpen("mse_train.txt", "w");
	int pf_test = FileOpen("mse_test_mt4.txt",FILE_CSV|FILE_WRITE,' ');//FileOpen("mse_test.txt", "w");

	int iter;

	for(iter = 1 ; iter <= max_iterations ; iter++)
	{
		//*****************************
		// train
		//*****************************
		mse_train = train(N_PATTERNS_TRAIN);
		FileWrite(pf_train,mse_train);
		//*****************************
		// test
		//*****************************
		mse_test = 0.0;
		// For each test pattern
		// (N_PATTERNS_TRAIN + N_PATTERNS_TEST)                       N_PATTERNS_TRAIN                            0
		// +-----------------------------------------------------------+------------------------------------------+
		//
		for(int i = N_PATTERNS_TRAIN ; i < (N_PATTERNS_TRAIN + N_PATTERNS_TEST) ; i++)
		{
			Yestimate0 = 0.0;
			Yestimate1 = 0.0;
			// forward current pattern into the MLP
			//forward(X[i], &Yestimate);
		    forward(
		          //X[p],
               DataIn0[i],
               DataIn1[i],
		          //&Yestimate
               Yestimate0,
               Yestimate1
		        );
			// computes MSE
			//mse_ = MSE(Y[i], Yestimate);
			mse_ = MSE(
		             //Y[p],
            DataOut0[i],
            DataOut1[i],
		             //Yestimate
            Yestimate0,
            Yestimate1
		          );
			// accumulate MSE
			mse_test += mse_;
  		}
		// Normalize the MSE
		mse_test /= N_PATTERNS_TEST;
		FileWrite(pf_test,mse_test);
		Print("->",iter);
		//fflush(stdout);
		if (mse_train < mse_min) break;
   }
	//Print("\n");
	//
	FileClose(pf_test);
	FileClose(pf_train);
	//*****************************
	// Print info about training
	//
	Print("Number of iterations = ", iter);
	Print("Final MSE train = ", mse_train);
	Print("Final MSE test = ", mse_test);
	Print("End of program.");

	return (0);
}

//use this first function to seed the random number generator,
//call this before any of the other functions
void initrand()
{
    //srand((unsigned)(time(0)));
    MathSrand(TimeLocal());
}
//generates a psuedo-random double between 0.0 and 0.999...
double randdouble0()
{
    return (MathRand()/((RAND_MAX)+1));
}
//generates a psuedo-random double between min and max
double randdouble2(double min, double max)
{
    if (min>max)
    {
        return (randdouble0()*(min-max)+max);
    }
    else
    {
        return (randdouble0()*(max-min)+min);
    }
}


// Random generator
double Random(double inf, double sup)
{
        return(randdouble2(inf,sup));
}
