MLP_cannonball6

This script implements a type of Artificial Intelligence known as a Multi-Layer Perceptron (MLP), which is a foundational neural network. Its specific purpose in this code is to solve a physics problem: predicting the trajectory of a cannonball (specifically its horizontal and vertical positions) based on the initial speed and angle provided.

Here is a breakdown of the logic used by the script:

1. Data Preparation

The program begins by generating a large synthetic dataset. It creates two categories of data:

  • Training Data: A set of 500 examples where the inputs (speed and angle) and the corresponding correct positions are known. This acts as the "textbook" from which the AI learns.
  • Test Data: A separate set of 500 examples used to evaluate the AI's performance. These are used to see if the AI can accurately predict positions for scenarios it has never seen before.

2. The Neural Network Structure

The script builds a neural network consisting of three main components:

  • Inputs: The raw data points, such as the initial speed and the launch angle.
  • Hidden Layer: An intermediate processing layer where the "learning" happens. It takes the inputs and passes them through a mathematical function (a Sigmoid transfer function) to identify complex patterns between speed, gravity, and distance.
  • Outputs: The final predictions for the X (horizontal) and Y (vertical) coordinates.

3. The Training Process (Learning)

The "learning" happens through a cycle of three steps repeated many times:

  1. Forward Pass: The script feeds training data into the network. The network makes a guess at where the cannonball should land.
  2. Error Calculation: The script compares the AI's guess against the actual known position using a "Mean Squared Error" formula. This calculates how far off the prediction was.
  3. Backward Pass (Backpropagation): This is the most critical step. The script looks at the error and works backward through the network, slightly adjusting the internal "weights" (the strengths of connections between neurons). It uses a "learning rate" to ensure the adjustments are small enough to be effective but large enough to make progress.

4. Momentum and Optimization

The script includes a "momentum" feature. This mimics a physical object moving in a direction; it helps the AI maintain its learning direction even if it encounters small "bumps" or noise in the data, preventing it from getting stuck in suboptimal solutions too easily.

5. Evaluation and Execution

After each iteration of training, the script performs two actions:

  • It records the error rate for both the training set and the test set into external files.
  • It checks if the training error has dropped below a specific minimum threshold. If the AI becomes accurate enough, it stops the training and outputs the final results, showing how many iterations it took to "master" the physics of the cannonball trajectory.
Miscellaneous
Uses files from the file systemIt writes information to file
3 Views
1 Downloads
0 Favorites
MLP_cannonball6
//+------------------------------------------------------------------+
//|                                               MLP_cannonball.mq4 |
//|                      Copyright © 2008, MetaQuotes Software Corp. |
//|                                        http://www.metaquotes.net |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2008, MetaQuotes Software Corp."
#property link      "http://www.metaquotes.net"
/* This program implements a simple Multi Layer Perceptron to solve the canonball problem (regression)
   Adapted by Sebastien Marcel (2003-2004) from D. Collobert
   The goal is to estimate the position X of a bullet at time t (fixed) given the initial speed (v) and angle (a)

   y

  / \
   |
   |
   |
   |               . X
   |            .
   |          .
   |        .
   |      .
   |     .
   |    .
   |   .
   |  .
   | .
   |.   (v,a)
   --------------------------> x

*/

#define PI 3.14159265358979323846
#define RAND_MAX 32767.0

//
// Datasets
#define N_PATTERNS_TRAIN 500
#define N_PATTERNS_TEST 500
#define N_PATTERNS_TRAIN_TEST 1000 //N_PATTERNS_TRAIN + N_PATTERNS_TEST

//  w1[N_HU1][IN1]=>w1[4][3]
//     H  In
//     |  |
//  w1[0][0] w1[0][1] w1[0][2]
//  w1[1][0] w1[1][1] w1[1][2]
//  w1[2][0] w1[2][1] w1[2][2]
//  w1[3][0] w1[3][1] w1[3][2]
//  forward train:
//  aHidden[0] = xBias;
//  aHidden[1] = xBias*w1[1][0] + (In0)*w1[1][1] + (In1)*w1[1][2];
//  aHidden[2] = xBias*w1[2][0] + (In0)*w1[2][1] + (In1)*w1[2][2];
//  aHidden[3] = xBias*w1[3][0] + (In0)*w1[3][1] + (In1)*w1[3][2];
//  yHidden[0] = xBias;
//  yHidden[1] = f(aHidden[1]);
//  yHidden[2] = f(aHidden[2]);
//  yHidden[3] = f(aHidden[3]);
//
//  w2[OUT][N_HU1]=>w2[2][4]
//
//  w2[0][0] w2[0][1] w2[0][2] w2[0][3]
//  w2[1][0] w2[1][1] w2[1][2] w2[1][3]
//     |  |
//    Out H
// forward train:
//	aOutput[0] = 0.0;
//	aOutput[1] = 0.0;
//	aOutput[0] = aOutput[0] + yHidden[0]*w2[0][0];
//	aOutput[1] = aOutput[1] + yHidden[0]*w2[1][0];
//	aOutput[0] = aOutput[0] + yHidden[1]*w2[0][1];
//	aOutput[1] = aOutput[1] + yHidden[1]*w2[1][1];
//	aOutput[0] = aOutput[0] + yHidden[2]*w2[0][2];
//	aOutput[1] = aOutput[1] + yHidden[2]*w2[1][2];
//	aOutput[0] = aOutput[0] + yHidden[3]*w2[0][3];
//	aOutput[1] = aOutput[1] + yHidden[3]*w2[1][3];
//

//	out0 = f(aOutput[0]);
//	out1 = f(aOutput[1]);

#define IN 8
#define IN1 9 //IN+1
#define OUT 2
#define N_HU 12
#define N_HU1 13 //N_HU + 1
//*****************************
// Inputs
//
	double DataIn0[N_PATTERNS_TRAIN_TEST]; // speed of bullet
	double DataIn1[N_PATTERNS_TRAIN_TEST]; // angle of bullet
	double DataIn2[N_PATTERNS_TRAIN_TEST]; // speed of bullet
	double DataIn3[N_PATTERNS_TRAIN_TEST]; // angle of bullet
	double DataIn4[N_PATTERNS_TRAIN_TEST]; // speed of bullet
	double DataIn5[N_PATTERNS_TRAIN_TEST]; // angle of bullet
	double DataIn6[N_PATTERNS_TRAIN_TEST]; // speed of bullet
	double DataIn7[N_PATTERNS_TRAIN_TEST]; // angle of bullet
// X[N_PATTERNS_TRAIN + N_PATTERNS_TEST];
//*****************************
// Targets
//
	double DataOut0[N_PATTERNS_TRAIN_TEST]; // x position at time t
	double DataOut1[N_PATTERNS_TRAIN_TEST]; // y position at time t
// Y[N_PATTERNS_TRAIN + N_PATTERNS_TEST];

//*****************************
// to create the data
//
double vmax;
double gravity;

//*****************************
// to train the MLP
//
double lambda =  0.01;     // learning rate
double mu = 0.6;           // inertia momentum rate
double mse_min = 0.001;    // minimum Mean Squared Error
int max_iterations = 500; // maximum number of iterations

//*****************************
// MLP data


// weights between hidden neurons and inputs
double w1[N_HU1][IN1];
double w1old[N_HU1][IN1];

// weights between outputs and hidden neurons
double w2[OUT][N_HU1];
double w2old[OUT][N_HU1];

// values of integration function
double aHidden[N_HU1];
double aOutput[OUT];

// values of transfert function
double yHidden[N_HU1];

// constant value of bias
double xBias = 1.0;


int init()
{
  vmax = 1.0/10;
  gravity = 1.0/200;

  return(0);
}
//+------------------------------------------------------------------+
//| script program start function                                    |
//+------------------------------------------------------------------+
int start()
  {
//----
   initrand();
   main();
//----
   return(0);
  }
//+------------------------------------------------------------------+

//*****************************
// Sigmoid transfer function
//
double f(double x)
{
	return (1.0 /(1.0 + MathExp(-x)));
}

//*****************************
// Derivative of Sigmoid
//
double f_prime(double x)
{
   double z = MathExp(-x);
	double one_plus_z = 1.0 + z;

	return (z / (one_plus_z * one_plus_z));
}



//*****************************
// Compute the x position of bullet at time t
//
double xpos(double t, double v, double teta)
{
	return( v * t * MathCos(teta*PI/180.0));
}

//*****************************
// Compute the y position of bullet at time t
//
double ypos(double t, double v, double teta)
{
	return( -0.5 * gravity * t * t + v * t * MathSin(teta*PI/180.0));
}

//*****************************
// Compute the MSE
//
double MSE(
            double a0,
            double a1,
            double b0,
            double b1
          )
{
	return (0.5*((a0 - b0)*(a0 - b0) + (a1 - b1)*(a1 - b1)));
}

//*****************************
// Create the MLP
//
void createMLP()
{
	int i, j;
	// weights between hidden neurons and inputs
	for (i = 0; i<IN1; i++)
	{
		for (j = 0; j< N_HU1; j++)
		{
			w1[j][i] = Random(-1.0, 1.0);
			w1old[j][i] = w1[j][i];
		}
	}
   // weights between outputs and hidden neurons
	for (i = 0; i<OUT; i++)
	{
		for (j = 0; j< N_HU1; j++)
		{
			w2[i][j] = Random(-1.0, 1.0);
			w2old[i][j] = w2[i][j];
		}
	}
}

//*****************************
// Create the datasets
//
void createDatasets()
{
	int i;

	i = 0;
	while (i < (N_PATTERNS_TRAIN + N_PATTERNS_TEST))
	{
		DataIn0[i] = (Random(0.0, vmax)) / vmax;
		DataIn1[i] = (Random(0.0, 90.0)) / 90.0;
		DataIn2[i] = (Random(0.0, vmax)) / vmax;
		DataIn3[i] = (Random(0.0, 90.0)) / 90.0;
		DataIn4[i] = (Random(0.0, vmax)) / vmax;
		DataIn5[i] = (Random(0.0, 90.0)) / 90.0;
		DataIn6[i] = (Random(0.0, vmax)) / vmax;
		DataIn7[i] = (Random(0.0, 90.0)) / 90.0;

		DataOut0[i] = xpos(10, DataIn0[i] * vmax, (DataIn1[i])*90.0);
		DataOut1[i] = ypos(10, DataIn0[i] * vmax, (DataIn1[i])*90.0);

		if (DataOut1[i] > 0.0) i = i + 1;
   }
}

//*****************************
// Forward the input in the MLP
//
void forward(
             double In0,
             double In1,
             double In2,
             double In3,
             double In4,
             double In5,
             double In6,
             double In7,
             double &out0,
             double &out1
             )
{
	int i;

	aHidden[0] = xBias;
	yHidden[0] = xBias;

	for (i = 1; i <= N_HU; i++)
	{
		aHidden[i] = xBias*w1[i][0] + (In0)*w1[i][1] +
		                              (In1)*w1[i][2] +
		                              (In2)*w1[i][3] +
		                              (In3)*w1[i][4] +
		                              (In4)*w1[i][5] +
		                              (In5)*w1[i][6] +
		                              (In6)*w1[i][7] +
		                              (In7)*w1[i][8] ;
		yHidden[i] = f(aHidden[i]);
	}

	aOutput[0] = 0.0;
	aOutput[1] = 0.0;

	for (i = 0; i <= N_HU; i++)
	{
		aOutput[0] = aOutput[0] + yHidden[i]*w2[0][i];
		aOutput[1] = aOutput[1] + yHidden[i]*w2[1][i];
	}

	out0 = f(aOutput[0]);
	out1 = f(aOutput[1]);
}

//*****************************
// Backward (back-propagate the gradient of error)
//
void backward(
               double Yestimate0,
               double Yestimate1,
               double Outwant0,
               double Outwant1,
               double In0,
               double In1,
               double In2,
               double In3,
               double In4,
               double In5,
               double In6,
               double In7,
               double lambda,
               double mu
               )
{
	double wnew, Goutput[OUT], Ghidden[N_HU1];
	int i,j;

	//
	Goutput[0] = (Yestimate0 - Outwant0) * f_prime(aOutput[0]);
	Goutput[1] = (Yestimate1 - Outwant1) * f_prime(aOutput[1]);

	//
	for (i = 0; i<=N_HU; i++)
		Ghidden[i] = (Goutput[0]*w2[0][i] + Goutput[1]*w2[1][i])*f_prime(aHidden[i]);

	//
	for (j = 0; j<OUT;j++)
	{
		for (i = 0; i<=N_HU; i++)
		{
			wnew = w2[j][i] - lambda * yHidden[i] * Goutput[j] + mu * (w2[j][i] - w2old[j][i]);
			w2old[j][i] = w2[j][i];
			w2[j][i] = wnew;
		}
	}

	//
	for (i = 0; i<=N_HU; i++)
	{
		wnew = w1[i][0] - lambda * xBias * Ghidden[i] + mu * (w1[i][0] - w1old[i][0]);
		w1old[i][0] = w1[i][0];
		w1[i][0] = wnew;

		wnew = w1[i][1] - lambda * In0 * Ghidden[i] + mu * (w1[i][1] - w1old[i][1]);
		w1old[i][1] = w1[i][1];
		w1[i][1] = wnew;

		wnew = w1[i][2] - lambda * In1 * Ghidden[i] + mu * (w1[i][2] - w1old[i][2]);
		w1old[i][2] = w1[i][2];
		w1[i][2] = wnew;

		wnew = w1[i][3] - lambda * In2 * Ghidden[i] + mu * (w1[i][3] - w1old[i][3]);
		w1old[i][3] = w1[i][3];
		w1[i][3] = wnew;

		wnew = w1[i][4] - lambda * In3 * Ghidden[i] + mu * (w1[i][4] - w1old[i][4]);
		w1old[i][4] = w1[i][4];
		w1[i][4] = wnew;

		wnew = w1[i][5] - lambda * In4 * Ghidden[i] + mu * (w1[i][5] - w1old[i][5]);
		w1old[i][5] = w1[i][5];
		w1[i][5] = wnew;

		wnew = w1[i][6] - lambda * In5 * Ghidden[i] + mu * (w1[i][6] - w1old[i][6]);
		w1old[i][6] = w1[i][6];
		w1[i][6] = wnew;

		wnew = w1[i][7] - lambda * In6 * Ghidden[i] + mu * (w1[i][7] - w1old[i][7]);
		w1old[i][7] = w1[i][7];
		w1[i][7] = wnew;

		wnew = w1[i][8] - lambda * In7 * Ghidden[i] + mu * (w1[i][8] - w1old[i][8]);
		w1old[i][8] = w1[i][8];
		w1[i][8] = wnew;
	}
}

//*****************************
// Stochastic gradient training
//
double train(int P)
{
   double Yestimate0;
   double Yestimate1;
	double mse_;
	double mse_total;

	mse_total = 0.0;

	// For each train patterns
	for(int p = 0 ; p < P ; p++)
	{
		// Forward current train pattern into the MLP
		forward(
		          //X[p],
               DataIn0[p],
               DataIn1[p],
               DataIn2[p],
               DataIn3[p],
               DataIn4[p],
               DataIn5[p],
               DataIn6[p],
               DataIn7[p],
		          //&Yestimate
               Yestimate0,
               Yestimate1
		        );

		// Computes the MSE
		mse_ = MSE(
		             //Y[p],
            DataOut0[p],
            DataOut1[p],
		             //Yestimate
            Yestimate0,
            Yestimate1
		          );

		// Accumulate the MSE
		mse_total = mse_total + mse_;

		// Backward MSE gradient
		backward(
		          //Yestimate,
                Yestimate0,
                Yestimate1,
		          //Y[p],
                DataOut0[p], //Outwant
                DataOut1[p], //Outwant
		          //X[p],
                DataIn0[p],
                DataIn1[p],
                DataIn2[p],
                DataIn3[p],
                DataIn4[p],
                DataIn5[p],
                DataIn6[p],
                DataIn7[p],
		          lambda,
		          mu
		          );
	}

	// Return normalized train MSE
	double P1=P;
	return (mse_total /P1);
}


//
int main()
{
	double mse_train;
	double mse_test;
   double mse_;
   double Yestimate0;
   double Yestimate1;
	//*****************************
	createMLP();
	//*****************************
	createDatasets();
	//*****************************
	//for (int i = 0; i< N_PATTERNS_TRAIN; i++) printf(" TRN: x=[%f %f] y=[%f %f]\n", X[i].v, X[i].a, Y[i].x, Y[i].y);
	//for (int i = N_PATTERNS_TRAIN; i<(N_PATTERNS_TRAIN + N_PATTERNS_TEST); i++) printf(" TST: x=[%f %f] y=[%f %f]\n", X[i].v, X[i].a, Y[i].x, Y[i].y);
	Print("Stochastic gradient training:");
	//
	int pf_train = FileOpen("mse_train_mt4_in8.txt",FILE_CSV|FILE_WRITE,' ');//FileOpen("mse_train.txt", "w");
	int pf_test = FileOpen("mse_test_mt4_in8.txt",FILE_CSV|FILE_WRITE,' ');//FileOpen("mse_test.txt", "w");

	int iter;

	for(iter = 1 ; iter <= max_iterations ; iter++)
	{
		//*****************************
		// train
		//*****************************
		mse_train = train(N_PATTERNS_TRAIN);
		FileWrite(pf_train,mse_train);
		//*****************************
		// test
		//*****************************
		mse_test = 0.0;
		// For each test pattern
		// (N_PATTERNS_TRAIN + N_PATTERNS_TEST)                       N_PATTERNS_TRAIN                            0
		// +-----------------------------------------------------------+------------------------------------------+
		//
		for(int i = N_PATTERNS_TRAIN ; i < (N_PATTERNS_TRAIN + N_PATTERNS_TEST) ; i++)
		{
			Yestimate0 = 0.0;
			Yestimate1 = 0.0;
			// forward current pattern into the MLP
			//forward(X[i], &Yestimate);
		    forward(
		          //X[p],
               DataIn0[i],
               DataIn1[i],
               DataIn2[i],
               DataIn3[i],
               DataIn4[i],
               DataIn5[i],
               DataIn6[i],
               DataIn7[i],
		          //&Yestimate
               Yestimate0,
               Yestimate1
		        );
			// computes MSE
			//mse_ = MSE(Y[i], Yestimate);
			mse_ = MSE(
		             //Y[p],
            DataOut0[i],
            DataOut1[i],
		             //Yestimate
            Yestimate0,
            Yestimate1
		          );
			// accumulate MSE
			mse_test += mse_;
  		}
		// Normalize the MSE
		mse_test /= N_PATTERNS_TEST;
		FileWrite(pf_test,mse_test);
		Print("->",iter);
		//fflush(stdout);
		if (mse_train < mse_min) break;
   }
	//Print("\n");
	//
	FileClose(pf_test);
	FileClose(pf_train);
	//*****************************
	// Print info about training
	//
	Print("Number of iterations = ", iter);
	Print("Final MSE train = ", mse_train);
	Print("Final MSE test = ", mse_test);
	Print("End of program.");

	return (0);
}

//use this first function to seed the random number generator,
//call this before any of the other functions
void initrand()
{
    //srand((unsigned)(time(0)));
    MathSrand(TimeLocal());
}
//generates a psuedo-random double between 0.0 and 0.999...
double randdouble0()
{
    return (MathRand()/((RAND_MAX)+1));
}
//generates a psuedo-random double between min and max
double randdouble2(double min, double max)
{
    if (min>max)
    {
        return (randdouble0()*(min-max)+max);
    }
    else
    {
        return (randdouble0()*(max-min)+min);
    }
}


// Random generator
double Random(double inf, double sup)
{
        return(randdouble2(inf,sup));
}

Similar scripts

MLP_cannonball3

This script implements a Multi-Layer Perceptron (MLP) utilizing stochastic gradient descent and backpropagation to approximate projectile motion trajectories based on initial velocity and angular inputs.

MLP_cannonball8

This script implements a Multi Layer Perceptron (MLP) using back-propagation to regress and predict ballistic projectile coordinates based on initial velocity and launch angles.

MLP_cannonball7

This script implements a Multi-Layer Perceptron neural network using backpropagation to predict ballistic trajectory coordinates based on initial velocity and launch angles.

MLP_cannonball4

This script utilizes a Multi-Layer Perceptron with backpropagation and sigmoid activation to regress ballistic coordinates based on initial velocity and angular trajectories.

MLP_cannonball5

This script employs a Multi-Layer Perceptron neural network to solve nonlinear regression by mapping initial projectile velocity and launch angles to spatial coordinates.

schnick

schnick_demo

Comments
