Technical Overview: T3 TRIX Indicator Logic
The script provides a specialized financial analysis tool designed to smooth out market price fluctuations and calculate the rate of change (momentum) of a specific asset. It functions by layering multiple smoothing techniques to filter out "market noise," allowing for a clearer view of the underlying trend.
Core Mathematical Components
The logic is built upon two primary components:
1. The T3 Smoothing Algorithm Unlike standard moving averages which can be slow to react or prone to lagging significantly, this script utilizes the T3 formula. This is a sophisticated smoothing method that balances responsiveness with smoothness. It uses a "hot" parameter (coefficient) to determine how much weight to give to recent price action versus historical data. By applying this specific mathematical curve, the indicator aims to provide a more accurate representation of price momentum without the typical delays found in standard indicators.
2. The Rate of Change (ROC) Mechanism Once the price is smoothed via the T3 method, the script calculates the "Rate of Change." Essentially, it measures how much the smoothed value has increased or decreased relative to its previous position. Instead of just looking at the price, it looks at the speed and velocity of the movement.
Operational Logic
The script processes data through two parallel calculation streams:
- Primary Stream (A): Uses a user-defined period to smooth the market data.
- Secondary Stream (B): Uses a different, often shorter, period to capture faster fluctuations.
For every price point on the chart, the script performs the following steps:
- It identifies whether to use the "Open" or "Close" price of a candle based on user settings.
- It applies the T3 smoothing coefficients across multiple layers of data.
- It calculates the percentage difference between the current smoothed value and the previous value.
- It outputs these values into two distinct visual buffers (lines).
User Configuration Impact
The logic can be adjusted by the user through several key variables:
- Periods: Adjusting the "A" and "B" periods allows the user to choose between identifying long-term trends or short-term price swings.
- Price Type: The user can toggle whether the calculation relies on the starting price of a candle (Open) or the finishing price (Close).
- Differential Mode: This determines how the two streams are presented. Depending on this setting, the script will either show the independent momentum of both streams or combine them into a single cumulative value.
Summary for the Trader
Essentially, this tool doesn't just tell you where the price is; it tells you how fast the price is moving in a specific direction after filtering out unnecessary market volatility. By looking at the resulting lines, a trader can identify when momentum is accelerating, decelerating, or reversing.
//+------------------------------------------------------------------+
//| T3 TRIX (ROC of T6).mq4 |
//| convert FinGeR Alex orginal by Luis Damiani |
//| |
//+------------------------------------------------------------------+
#property copyright "convert FinGeR Alex orginal by Luis Damiani"
#property link ""
#property indicator_separate_window
#property indicator_buffers 2
#property indicator_color1 DeepSkyBlue
#property indicator_color2 Blue
//---- input parameters
extern int A_t3_period=18;
extern int num_bars=350;
extern int is_A_open_price=0;
extern int B_t3_period_ac=10;
extern int diferential=0;
extern double hot=0.7;
//---- buffers
double ExtMapBuffer1[];
double ExtMapBuffer2[];
//+------------------------------------------------------------------+
//| Custom indicator initialization function |
//+------------------------------------------------------------------+
int init()
{
//---- indicators
SetIndexStyle(0,DRAW_LINE);
SetIndexBuffer(0,ExtMapBuffer1);
SetIndexStyle(1,DRAW_LINE);
SetIndexBuffer(1,ExtMapBuffer2);
//----
return(0);
}
//+------------------------------------------------------------------+
//| Custor indicator deinitialization function |
//+------------------------------------------------------------------+
int deinit()
{
//----
//----
return(0);
}
//+------------------------------------------------------------------+
//| Custom indicator iteration function |
//+------------------------------------------------------------------+
int start()
{
int shift=0;
double A_t3=0,A_t3_1=0,max_per=0;
double B_t3=0,B_t3_1=0;
double e1=0,e2=0,e3=0,e4=0,e5=0,e6=0,c1=0,c2=0,c3=0,c4=0;
double e1x=0,e2x=0,e3x=0,e4x=0,e5x=0,e6x=0;
double d1=0,d2=0,d3=0,d4=0,d5=0,d6=0;
double d1x=0,d2x=0,d3x=0,d4x=0,d5x=0,d6x=0;
double n=0,A_w1=0,A_w2=0,B_w1=0,B_w2=0,b2=0,b3=0;
double init=true;
double bar=0, prevbars=0, start=0, cs=0, prevcs=0,frame=0;
string commodt="nonono";
int counted_bars=IndicatorCounted();
cs = num_bars+A_t3_period+is_A_open_price+B_t3_period_ac+diferential+hot;
if (cs==prevcs && commodt==Symbol() && frame==Time[4]-Time[5] && Bars-prevbars<2)
start=Bars-prevbars;
else start=-1;
commodt=Symbol();
frame=Time[4]-Time[5];
prevbars = Bars;
prevcs = cs;
if (start==1 || start==0) bar=start; else init=true;
if (init==true)
{
b2=hot*hot;
b3=b2*hot;
c1=-b3;
c2=(3*(b2+b3));
c3=-3*(2*b2+hot+b3);
c4=(1+3*hot+b3+3*b2);
n=A_t3_period;
if (n<1) n=1;
n = 1 + 0.5*(n-1);
A_w1 = 2 / (n + 1);
A_w2 = 1 - A_w1;
n=B_t3_period_ac;
if (n<1) n=1;
n = 1 + 0.5*(n-1);
B_w1 = 2 / (n + 1);
B_w2 = 1 - B_w1;
ExtMapBuffer1[num_bars-1]=0;
e1x=0;e2x=0;e3x=0;e4x=0;e5x=0;e6x=0;
ExtMapBuffer2[num_bars-1]=0;
d1x=0;d2x=0;d3x=0;d4x=0;d5x=0;d6x=0;
// max_per=max(A_t3_period,B_t3_period_ac);
bar=num_bars-2;
init=false;
}
//SetLoopCount(0);
shift=bar;
while(shift>=0)
{
if ( is_A_open_price==1 ) d1 = A_w1*Open[shift] + A_w2*d1x;
else d1 = A_w1*Close[shift] + A_w2*d1x;
d2 = A_w1*d1 + A_w2*d2x;
d3 = A_w1*d2 + A_w2*d3x;
d4 = A_w1*d3 + A_w2*d4x;
d5 = A_w1*d4 + A_w2*d5x;
d6 = A_w1*d5 + A_w2*d6x;
A_t3 = c1*d6 + c2*d5 + c3*d4 + c4*d3;
if ((start==1 && shift==1) || start==-1 )
{
d1x=d1;
d2x=d2;
d3x=d3;
d4x=d4;
d5x=d5;
d6x=d6;
}
e1 = B_w1*Close[shift] + B_w2*e1x;
e2 = B_w1*e1 + B_w2*e2x;
e3 = B_w1*e2 + B_w2*e3x;
e4 = B_w1*e3 + B_w2*e4x;
e5 = B_w1*e4 + B_w2*e5x;
e6 = B_w1*e5 + B_w2*e6x;
B_t3 = c1*e6 + c2*e5 + c3*e4 + c4*e3;
if(diferential==1)
{
ExtMapBuffer1[shift]=(A_t3-A_t3_1)/A_t3_1;
ExtMapBuffer2[shift]=(A_t3-A_t3_1)/A_t3_1+(B_t3-B_t3_1)/B_t3_1;
}
else
{
if ( B_t3_1 >0 && A_t3_1>0) {
ExtMapBuffer2[shift]=(B_t3-B_t3_1)/B_t3_1;
ExtMapBuffer1[shift]=(A_t3-A_t3_1)/A_t3_1;
}
//Comment("0");
}
//Comment(" start: ",start," bar: ",bar,"\n",
//"frame: ",frame," num_bars:" ,num_bars," commodity: ",commodt ,"\n",(B_t3-B_t3_1)/B_t3_1);
if ((start==1 && shift==1) || start==-1)
{
//Comment("Bar=ghfghfgh");
A_t3_1=A_t3;
B_t3_1=B_t3;
e1x=e1;
e2x=e2;
e3x=e3;
e4x=e4;
e5x=e5;
e6x=e6;
}
shift--;
//Comment("View !!! NO?????");
}
//----
}
//+------------------------------------------------------------------+----------------------------+
