This tool is designed to help traders visualize momentum and trend direction by analyzing the MACD (Moving Average Convergence Divergence) indicator across different timeframes simultaneously. Instead of looking at a single chart, this script allows you to "peek" into higher time periods to see if the broader market sentiment aligns with your current trading perspective.
How It Works
The core logic of this script revolves around three main functions:
1. Multi-Timeframe Awareness The script features a customizable setting that allows you to choose a specific timeframe (ranging from 1 minute up to monthly charts). This means that even if you are trading on a small, fast-moving chart, the indicator will calculate its data based on the larger trend of your chosen timeframe.
2. Momentum Analysis The script tracks two primary components of the MACD: the "Main" line and the "Signal" line. It compares these two values to determine the strength and direction of price movement. By comparing where the Signal line sits in relation to the Main line, it identifies whether the momentum is currently accelerating or decelerating.
3. Visual Trend Signals The script converts complex mathematical data into four distinct visual bars (histograms) on your chart:
- Bullish Indicators: It identifies specific scenarios where the Signal line is above the Main line, indicating positive momentum.
- Bearish Indicators: It identifies scenarios where the Signal line drops below the Main line, signaling a potential downward shift.
- Contextual Filters: Beyond just comparing the two lines, the script also looks at their position relative to the "Zero Line." This helps differentiate between a strong upward move in an already positive market versus a reversal happening in a negative market.
Summary for the User
Essentially, this tool acts as a filter. It takes the complex movements of a higher timeframe and simplifies them into visual bars on your screen. This allows you to quickly see if the "big picture" market is moving in your favor before you commit to a trade on your current chart.
//+------------------------------------------------------------------+
//| MTF_MACD_Bars.mq4 |
//| Copyright © 2006, MetaQuotes Software Corp. |
//| http://www.metaquotes.net |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2006, MetaQuotes Software Corp."
#property link "http://www.metaquotes.net"
//+------------------------------------------------------------------+
//| FlatTrend.mq4 |
//| Kirk Sloan |
//| http://www.metaquotes.net |
//+------------------------------------------------------------------+
#property copyright "Kirk Sloan"
#property link "http://www.metaquotes.net"
#property link "Modified by cja"
#property indicator_separate_window
#property indicator_minimum -1
#property indicator_maximum 1
#property indicator_buffers 4
#property indicator_color1 Tomato
#property indicator_color2 LightGreen
#property indicator_color3 YellowGreen
#property indicator_color4 Pink
#property indicator_width1 4
#property indicator_width2 4
#property indicator_width3 4
#property indicator_width4 4
//---- input parameters
extern int Minutes=0;
extern int MACD_Fast = 8;
extern int MACD_Slow = 17;
extern int MACD_MA = 9;
//---- buffers
double ExtMapBuffer1[];
double ExtMapBuffer2[];
double ExtMapBuffer3[];
double ExtMapBuffer4[];
/*double Ma;
double hhigh, llow;
double Psar;
double MA1,MA2,MA3;
double PADX,NADX;*/
string TimeFrameStr;
double MACD_Signal,MACD_Main;
//+------------------------------------------------------------------+
//| Custom indicator initialization function |
//+------------------------------------------------------------------+
int init()
{
//---- indicators
SetIndexStyle(0,DRAW_HISTOGRAM,STYLE_SOLID);
SetIndexBuffer(0,ExtMapBuffer1);
SetIndexStyle(1,DRAW_HISTOGRAM,STYLE_SOLID);
SetIndexBuffer(1,ExtMapBuffer2);
SetIndexStyle(2,DRAW_HISTOGRAM,STYLE_SOLID);
SetIndexBuffer(2,ExtMapBuffer3);
SetIndexStyle(3,DRAW_HISTOGRAM,STYLE_SOLID);
SetIndexBuffer(3,ExtMapBuffer4);
switch(Minutes)
{
case 1 : TimeFrameStr="Period_M1"; break;
case 5 : TimeFrameStr="Period_M5"; break;
case 15 : TimeFrameStr="Period_M15"; break;
case 30 : TimeFrameStr="Period_M30"; break;
case 60 : TimeFrameStr="Period_H1"; break;
case 240 : TimeFrameStr="Period_H4"; break;
case 1440 : TimeFrameStr="Period_D1"; break;
case 10080 : TimeFrameStr="Period_W1"; break;
case 43200 : TimeFrameStr="Period_MN1"; break;
default : TimeFrameStr="Current Timeframe"; Minutes=0;
}
IndicatorShortName("MTF_MACD ("+TimeFrameStr+")");
//----
return(0);
}
//+------------------------------------------------------------------+
//| Custom indicator deinitialization function |
//+------------------------------------------------------------------+
int deinit()
{
//----
//----
return(0);
}
//+------------------------------------------------------------------+
//| Custom indicator iteration function |
//+------------------------------------------------------------------+
int start()
{
int counted_bars=IndicatorCounted();
//----
for (int i = 0; i < 300; i++){
ExtMapBuffer1[i]=0;
ExtMapBuffer2[i]=0;
ExtMapBuffer3[i]=0;
ExtMapBuffer4[i]=0;
MACD_Signal=iMACD(NULL,Minutes,MACD_Fast,MACD_Slow,MACD_MA,PRICE_CLOSE,MODE_SIGNAL,i);
MACD_Main =iMACD(NULL,Minutes,MACD_Fast,MACD_Slow,MACD_MA,PRICE_CLOSE,MODE_MAIN,i);
if(MACD_Signal < MACD_Main )ExtMapBuffer2[i] = -1;//Sig Below MACD
if(MACD_Signal > MACD_Main )ExtMapBuffer1[i] = 1;//Sig above MACD
/* if(ExtMapBuffer1[i] == 0 && ExtMapBuffer2[i] == 0)
{ExtMapBuffer3[i] = 1;}*/
if(MACD_Signal < MACD_Main && MACD_Main > 0)ExtMapBuffer3[i] = 1;//Sig below MACD & Above 0
if(MACD_Signal > MACD_Main && MACD_Main < 0)ExtMapBuffer4[i] = -1;//Sig above MACD & Below 0
}
//----
return(0);
}
//+------------------------------------------------------------------+
