FisherCyberCycle
Download script
The Fisher Cyber Cycle is a sophisticated technical analysis tool designed to identify cyclical trends and momentum shifts in financial markets. Based on the principles of cybernetics—the study of complex systems and feedback loops—this indicator aims to filter out "market noise" to reveal the underlying rhythms of price movement.
How the Logic Works
The script processes market data through a multi-stage mathematical pipeline to produce a clear visual signal for traders. Here is the step-by-step breakdown of that logic:
1. Price Averaging (Smoothing) The process begins by looking at the high and low prices of each candle to determine a median value. Instead of reacting to every tiny price tick, the script applies a smoothing formula. This stabilizes the data, ensuring that the resulting indicator reflects a broader trend rather than erratic, momentary fluctuations.
2. Cycle Identification Once the price is smoothed, the logic employs a recursive calculation to identify "cycles." It looks at the relationship between current values and previous ones to detect repeating patterns. By analyzing these cycles, the tool can distinguish between a steady move in one direction and a cyclical wave that might be about to turn.
3. Range Normalization To make the data easier to read, the script evaluates the highest highs and lowest lows over a specific period (defined by the user). It then calculates where the current price sits within that range as a percentage. This "normalizes" the data, allowing the indicator to operate on a consistent scale regardless of how high or low the actual asset price is trading.
4. Fisher Transformation The final stage applies a specific mathematical transformation known as the Fisher Cycle. This step converts the normalized values into a specialized curve that highlights changes in momentum.
- The Main Line: Represents the primary smoothed cycle.
- The Trigger Line: Acts as a delayed reference point (the previous value of the main line).
How to Interpret the Results
By observing the relationship between the two lines on your chart, you can identify momentum shifts:
- Trend Detection: When the lines move in a specific direction, they indicate the prevailing cycle of the market.
- Momentum Shifts: When the main line crosses the trigger line, it often signals a potential change in the cycle's direction. Because this is based on cybernetic cycles, these crossings are intended to highlight moments where the market momentum is losing steam or gaining strength before a major reversal occurs.
//+------------------------------------------------------------------+
//| FisherCyberCycle.mq4 |
//| |
//| Fisher Stochastic Cyber Cycle |
//| |
//| Algorithm taken from book |
//| "Cybernetics Analysis for Stock and Futures" |
//| by John F. Ehlers |
//| |
//| contact@mqlsoft.com |
//| http://www.mqlsoft.com/ |
//+------------------------------------------------------------------+
#property copyright "Coded by Witold Wozniak"
#property link "www.mqlsoft.com"
#property indicator_separate_window
#property indicator_buffers 2
#property indicator_color1 Red
#property indicator_color2 Blue
#property indicator_level1 0
double FisherCC[];
double Trigger[];
double Smooth[];
double Cycle[];
double Value1[];
extern double Alpha4 = 0.07;
extern int Length4 = 8;
int buffers = 0;
int drawBegin = 0;
int init() {
drawBegin = Length4;
initBuffer(FisherCC, "Fisher Cyber Cycle", DRAW_LINE);
initBuffer(Trigger, "Trigger", DRAW_LINE);
initBuffer(Smooth);
initBuffer(Cycle);
initBuffer(Value1);
IndicatorBuffers(buffers);
IndicatorShortName("Fisher Cyber Cycle [" + DoubleToStr(Alpha4, 2) + ", " + Length4 + "]");
return (0);
}
int start() {
if (Bars <= drawBegin) return (0);
int countedBars = IndicatorCounted();
if (countedBars < 0) return (-1);
if (countedBars > 0) countedBars--;
int s, limit = Bars - countedBars - 1;
for (s = limit; s >= 0; s--) {
Smooth[s] = (P(s) + 2.0 * P(s + 1) + 2.0 * P(s + 2) + P(s + 3)) / 6.0;
Cycle[s] = (1.0 - 0.5 * Alpha4) * (1.0 - 0.5 * Alpha4) * (Smooth[s] - 2.0 * Smooth[s + 1] + Smooth[s + 2])
+ 2.0 * (1.0 - Alpha4) * Cycle[s + 1]
- (1.0 - Alpha4) * (1.0 - Alpha4) * Cycle[s + 2];
if (s > Bars - 8) {
Cycle[s] = (P(s) - 2.0 * P(s + 1) + P(s + 2)) / 4.0;
}
double hh = Cycle[s], ll = Cycle[s];
for (int i = 0; i < Length4; i++) {
double tmp = Cycle[s + i];
hh = MathMax(hh, tmp);
ll = MathMin(ll, tmp);
}
Value1[s] = 0.0;
if (hh != ll) {
Value1[s] = (Cycle[s] - ll) / (hh - ll);
}
FisherCC[s] = (4.0 * Value1[s] + 3.0 * Value1[s + 1] + 2.0 * Value1[s + 2] + Value1[s + 3]) / 10.0;
FisherCC[s] = 0.5 * MathLog((1.0 + 1.98 * (FisherCC[s] - 0.5)) / (1.0 - 1.98 * (FisherCC[s] - 0.5)));
Trigger[s] = FisherCC[s + 1];
}
return (0);
}
double P(int index) {
return ((High[index] + Low[index]) / 2.0);
}
void initBuffer(double array[], string label = "", int type = DRAW_NONE, int arrow = 0, int style = EMPTY, int width = EMPTY, color clr = CLR_NONE) {
SetIndexBuffer(buffers, array);
SetIndexLabel(buffers, label);
SetIndexEmptyValue(buffers, EMPTY_VALUE);
SetIndexDrawBegin(buffers, drawBegin);
SetIndexShift(buffers, 0);
SetIndexStyle(buffers, type, style, width);
SetIndexArrow(buffers, arrow);
buffers++;
}
